Wireless Switches & Keyfob
RFWB-20/G
2 Button (Fold)
Single Switch Plate
Dimensions: 86mm x 86mm x 8mm
Supplied with CR2032 battery and sticky pads
2A
Smart Switches (RFWB-20/G & RFWB-40/G) - Installing The Battery
Transmitters required one 3V (CR2032) battery
1. Carefully remove the rocker
button(s) to reveal the PCB
4. Fit the battery ensuring it
is securely in place and
push the PCB back so it
clips in to position
Incorrect battery installation can cause damage to the battery strap and invalidate the warranty
Installation of receiving devices should be carried out by a qualified electrician.
Any device with the signs of damage and/or missing parts should NOT be installed and should be
returned to the seller.
Before attempting installation, ensure all associated circuits and cables have been isolated at the source.
Care should be taken with regards to the location of the radio frequency devices as transmission of the
signal differs through different materials.
Devices are designed to be mounted internally only.
RFWB-40/G
4 Button (Fold)
Single Switch Plate
2. With a screwdriver unclip
the two bottom clips to
allow the PCB to lift up
RF KEY (Black or White)
4 Button (Fold) Keyfob
Dimensions: 65mm x 25mm x 9mm
Supplied with CR2032 battery
3. With the PCB lifted, slide
5. Carefully re-fit rocker
button(s), programme
and install as required
in the battery, ensuring
the correct polarity
