SymCom MotorSaver Plus 777-P Series Installation Instructions Manual page 2

Recommended
Full Load
Amps
2-2.5
2.5-3
3-3.5
3.5-4
4-5
5-6
6-8
8-12
12-25
25-90
80-110
110-160
160-220
220-320
320-420
400-520
480-600
540-700
560-800
Table 1: Wiring Configuration Based on Motor load Amps
OC Range
(Amps)
2-10
2.2-11.1
2.5-12.5
2.8-14.3
3.3-16.7
4-20.1
5-25.1
6.6-33.5
10-50.3
20-100
80-140
120-210
160-280
240-420
320-560
400-700
480-840
560-980
640-992/FFF 0, 320-992/FFF
Figure 1: Typical Wiring Diagram for FLA of 26-90
# of Passes
UC Range
through each
(Amps)
Window
0, 1-9.8
0, 1.1-10.8
0, 1.2-12.2
0, 1.4-14
0, 1.6-16.3
0, 2-19.6
0, 2.5-24.5
0, 3.3-32.6
0, 5-49
0, 10-98
0, 40-140
0, 60-210
0, 80-280
0, 120-420
0, 160-560
0, 200-700
0, 240-840
0, 280-980
- 2 -
MULT (CT
Ratio)
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
5 100 (100:5)
5 150 (150:5)
5 200 (200:5)
5 300 (300:5)
5 400 (400:5)
5 500 (500:5)
5 600 (600:5)
5 700 (700:5)
5 800 (800:5)
6/07 A1
