Summary of Contents for GDU GTIR800
- Page 1 Copyright ©2020 GDU-Tech Co., Ltd All Rights Reserved. www.gdu-tech.com INFRARED CAMERA GIMBAL USER MANUAL V1.0 If you have any questions about this document , please contact GDU GTIR800 after-sales center (+86 400-040-0266).
-
Page 2: Table Of Contents
Index Disclaimer.................1 Product.Features................1 Product.Installation..............2 Camera..................3 GDU.Flight.APP................4 Maintenance................8 Safety.Instructions..............9 Technical.Data................9... -
Page 3: Disclaimer
Product.Features Dual.Light.Source.-.Infrared.+.Visible.Light The GTIR800 Infrared camera can shoot using two different types of light. It supports light switching and picture in picture mode. Visible light can be used to guide the aircraft and infrared can be used to take pictures of the setting. -
Page 4: Product.installation
Camera Product Installation The GTIR800 infrared camera can be used with the GDU SAGA series 1) Please install the stands on 2 ) P l e a s e r e m o v e t h e l e n s the aircraft. -
Page 5: Gdu.flight.app
App. Use this product with the App. Camera.Interface Press "start shooting" to enter the camera interface. GDU Flight App requires systems with iOS 8.0 or above or Android 5.0 or above. Connecting.to.the.App Connect the mobile device to the remote with an USB cable. Turn on the remote and aircraft then run the app. - Page 6 GTIR800 User Manual GTIR800 User Manual ①.Manual.focus.adjustment Display.mode: infrared, visible light in infrared, visible light, infrared in visible light. Press +/- to adjust the focus distance. Image.style: white-hot, fulgurite, iron red, hot iron, medical, arctic, ②.One.click.focus rainbow 1, rainbow 2, tint, black-hot.
-
Page 7: Maintenance
• People under the age of 18 are not allowed to use this product. • Do not place the product within the reach range of children. • When using this product together with GDU aircrafts, please strictly follow the flight and use safety instructions of GDU aircraft. - Page 8 GTIR800 User Manual Maximum turn speed Greater than 30° /s Stabilization Stabilization ≤ 0.02° performance accuracy The yaw angle follows the angle of the Flight path movement aircraft, pitch axis and roll axis stabilization. Camera Infrared 800×600 Resolution Visible light 1280×720...
