Page 1
VMB6IN 6-Channel Input Module for VELBUS system Velbus manual VMB6IN– edition 1 – rev.1.0...
Page 2
INDEX Features ............................3 Velbus data ............................ 3 Connection ............................ 4 Use ..............................5 Addressing ..........................5 Termination ..........................5 Reaction time .......................... 6 Operation ..........................6 Velbus manual VMB6IN– edition 1 – rev.1.0...
Page 3
Instructions will be accepted when calling up the module type, the input names and when reading from or writing to the non-volatile memory. The module can respond with the module type, the input name or the contents from the memory. Velbus manual VMB6IN– edition 1 – rev.1.0...
Page 4
These contacts may be placed on a long distance from the module. Connect the contacts between the PB and the COM input. External contacts PB1 PB2PB3 PB4 PB5 PB6 ADDR VMB6IN TWISTED PAIR (0.5mm ) 12V SUPPLY Velbus manual VMB6IN– edition 1 – rev.1.0...
Page 5
Remove the jumper in all other cases. If different cable wiring topologies (tree, star, loop, ...) are used, place a jumper on the end module of the longest cable only, NOT on each end point. Velbus manual VMB6IN– edition 1 – rev.1.0...
Page 6
The way a specific push button controls a specific module is described in the learning mode of the module in question. Make sure the inputs are opened (disconnect if necessary) when activating a learning mode. Use the manual control of the input module to assign a specific input in the learning mode. Velbus manual VMB6IN– edition 1 – rev.1.0...
