vds IRC-320GE Series Manual

Lwir camera (320 x 240 pixels) with integrated image processing and gigabit ethernet output
Table of Contents

Advertisement

Quick Links

LWIR Camera (320 x 240 Pixels)
LWIR Camera (320 x 240 Pixels)
with Integrated Image Processing
with Integrated Image Processing
and Gigabit Ethernet Output
and Gigabit Ethernet Output
This document may not in whole or in part be copied, photocopied or otherwise
This document may not in whole or in part be copied, photocopied or otherwise
reproduced without prior permission of the publisher.
reproduced without prior permission of the publisher.
Technical details are subject to change without notice.
Technical details are subject to change without notice.
Phone +49 (0) 541 / 80084-0 · Telefax +49 (0) 541 / 80084-10
http://www.vdsvossk.de · email: vds@vdsvossk.de
IRC-320GE
IRC-320GE
Manual
Manual
Version 3.0
Version 3.0
Art.-No.: 3143000
Art.-No.: 3143000
Date: March 2010
Date: March 2010
Weiße Breite 7 · D-49084 Osnabrück

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IRC-320GE Series and is the answer not in the manual?

Questions and answers

Summary of Contents for vds IRC-320GE Series

  • Page 1 Date: March 2010 Technical details are subject to change without notice. Technical details are subject to change without notice. Weiße Breite 7 · D-49084 Osnabrück Phone +49 (0) 541 / 80084-0 · Telefax +49 (0) 541 / 80084-10 http://www.vdsvossk.de · email: vds@vdsvossk.de...
  • Page 2: Table Of Contents

    C O N T E N T S INTRODUCTION............................4 ............................4 OMMON EATURES ........................4 TANDARD MODEL VARIANTS TECHNICAL DATA ............................5 ...........................5 PECTRAL RESPONSE ...................6 ROTECTION AGAINST LECTROSTATIC ISCHARGE ........................6 NVIRONMENTAL ONDITIONS ............................6 ARM UP ERIOD MECHANICAL DIMENSIONS........................7 IRC-320 F/1.0 ...................7 IEW OF THE WITH LENS ........................7...
  • Page 3 APPENDIX..............................32 11.1 ..........................32 OMMAND EFERENCE DECLARATION OF CE CONFORMITY ..................40 REVISION HISTORY ...........................41...
  • Page 4: Introduction

    With the IRC-320 line VDS Vosskühler offers infrared cameras based on a microbolometer sensor with 320 x 240 pixels for the LWIR range. As all previous VDS CCD cameras also the IRC-320 provides an excellent image quality. The series IRC-320 is designed as OEM modules with Gigabit Ethernet output for the long-lasting installation.
  • Page 5: Technical Data

    Made in Germany Please note: The correct polarity of the 12 V supply voltage must be assured. The warranty becomes void in case of unauthorized tampering or any manipulations not approved by the manufacturer. 2.1 Spectral response VDS Vosskühler GmbH IRC-320...
  • Page 6: Protection Against Electrostatic Discharge

    In case of simple view applications with low demands, the data are already suitable following an operating period of some minutes. If time stability of the temperature data is required a longer warm up period of at least 20 minutes is recommended. VDS Vosskühler GmbH IRC-320...
  • Page 7: Mechanical Dimensions

    UNC1/4" (2x) and M4 mounting holes are in the center of main body LED’s at the Backside of the Housing Camera is operational Temperature state (off → temperature is OK) Power Power state Trigger (reset) input activity Frame output VDS Vosskühler GmbH IRC-320...
  • Page 8: Start Up

    Microsoft® Windows® deliveries, might be the choice to manually control the camera. The VDS provided software AcquireControl can operate the camera’s serial port over the Pleora iPORT Gigabit Ethernet interface or PC standard COM ports. Type <CTRL>+Y to get a camera control terminal window there.
  • Page 9: Adjust The Image Processing

    > The calibration process needs a few seconds to finish. Please note that during this time no image data is output. Avoid triggering the camera via CC1 or opto coupler input while the calibration is in VDS Vosskühler GmbH IRC-320...
  • Page 10 0 * T Calculate statistics 2 * T 50ms 50ms At all 3,58s 2,68s T = Time for one frame-out (IRC-320: 25ms) N1 = number of data sets (max. 32) N2 = number of integrated images (max. 64) VDS Vosskühler GmbH IRC-320...
  • Page 11: Control Connector (15 Pin Sub-D Jack)

    Additionally, the intensity of the second image may be inaccurate because the microbolometer pixels’ minimal integration time was not reached. Avoid reset events during integration of correction data or execution of the automatic calibration function (k). VDS Vosskühler GmbH IRC-320...
  • Page 12: Sensor Temperature Too Low (Pin 12, 13)

    45°C. 5.7 Frame-Sync Output (Pin 15) 1 line (80 µs) 5 Vss (no load) 312 lines (24.96 ms) The frame-sync output (active low) supplies approx. 900 mV at a termination with 75 Ohms. VDS Vosskühler GmbH IRC-320...
  • Page 13: Data Interface

    FVAL, LVAL, FVAL, LVAL, DVAL, SP DVAL, SP Port A, B, C Port A, B, C (3 x 8 Bits) (3 x 8 Bits) CLKX CLKX PCLK PCLK DS90CR287 SerTFG SerTFG SerTFG SerTFG SerTC SerTC SerTC SerTC VDS Vosskühler GmbH IRC-320...
  • Page 14: Trigger (Reset) Input (Cc1)

    1 Camera Link clock (47.6 ns / 21 MHz) Blanking 320 pixels (60.95 µs) 100 Pixels (19.05 µs) LVAL 420 pixels (80 µs) DVAL Blanking 240 lines (19.2 m 72 l ines (5.76 ms) FVAL 312 lines (24.96 ms) LVAL VDS Vosskühler GmbH IRC-320...
  • Page 15: Output Data Specification

    For the IRC-320 the following relation can be used: with: : 12-bit Digital value (Pixel data) : Temperature value [°C] : Resolution (for the IRC-320 standard version: 0.03°C) : offset for DN=0 (for the IRC-320 standard version: -30°C) The following diagram shows the result. VDS Vosskühler GmbH IRC-320...
  • Page 16: Consideration Of The Emission Ratio

    Ethernet models of this camera internally use Camera Link signals, so many of the facts mentioned in the chapter 6.1 are also valid for the Gigabit Ethernet interface option. For details one can refer to the Pleora iPORT PT1000-VB Documentation. VDS Vosskühler GmbH IRC-320...
  • Page 17 6 Data Interface 17 / 41 Front view of the Gigabit Ethernet jack. 8 ..1 Signal D1– D4– VDS Vosskühler GmbH IRC-320...
  • Page 18: Parameters Of Image Processing

    – the background correction – the image quality can additionally be enhanced. The shutter is closed to acquire a temporary background correction image. This image is subtracted from the two point corrected image data to reduce the remaining fixed pattern noise. VDS Vosskühler GmbH IRC-320...
  • Page 19: File System

    Ex factory the camera is usually already equipped with several files, containing system and correction data. The IRC-320 don’t use the whole 64MByte, so that a customer can also use this memory for own data. Refer to chapter 10.10 “Upload a File to Flash ( Q )” for details. VDS Vosskühler GmbH IRC-320...
  • Page 20: Introduction To The Two Point Correction (A, B, E, J, K, N)

    I.e. diverse correction images ( A , B ) including the according set values ( J , K ) may exist for the two point correction, being loaded during the camera start-up to the correction memory. VDS Vosskühler GmbH IRC-320...
  • Page 21: Basic Parameters And Commands

    Avoid triggering the camera while the calibration is in progress. Depending on the camera model and current j parameter configuration, the actions accomplished by the k command and its output at the serial interface may vary. Refer to the corresponding command reference in appendix 11.1 for details. VDS Vosskühler GmbH IRC-320...
  • Page 22: Electromechanical Shutter (I)

    The command ?=1 shows a command reference text at the serial terminal. It lists a short description for each command available in the firmware. Please note that not every command is useful in conjunction to the IRC-320 camera heads. VDS Vosskühler GmbH IRC-320...
  • Page 23: Advanced Parameters And Commands

    S (see chapter 9.1, p. 21) actually being activated. Following the storage ( X=1 ) and a re-start of the camera all file numbers following A VDS Vosskühler GmbH IRC-320...
  • Page 24 From the registers J and K actually only the higher 12 (IRC-320) or 14 (IRC-640) bits are used. The lower bits are reserved for prospective extensions and should always be set to zero: Bit position Value (12bit) Value (14bit) VDS Vosskühler GmbH IRC-320...
  • Page 25: Background Correction (U, M)

    Command sequence: >U=1A[CR] ...wait for at least 34 image cycles (32 + 2 frames jitter buffer, 0.85 seconds at 40 images / sec.) or poll the state of bit group c with U[CR] ... >U=1[CR] VDS Vosskühler GmbH IRC-320...
  • Page 26: Bad Pixel Correction (C, F)

    As generally only one file with correction data exists in the camera, it is not necessary to change this parameter. Example: Initialization of the correction data for the bad pixel correction from the file 0x70. >C=70[CR] VDS Vosskühler GmbH IRC-320...
  • Page 27: Temperature Drift Compensation (M, N, O, P)

    The file containing the LUT data is set with parameter D . Ex-factory the LUT is determined one time and stored into the flash. As generally only one LUT exists in the camera, it is not necessary to change this parameter. Example: Initialisation of the LUT with data from file number 0x80. >D=80[CR] VDS Vosskühler GmbH IRC-320...
  • Page 28: Integrator And Image Store (H)

    Note: The Integration is activated by change of the register content of H. In case that e.g. directly following the integration of 64 images a further integration of 64 images is subject to be started another value has to be written into the register first. I.e. e.g.: H=E, H=0, H=E. VDS Vosskühler GmbH IRC-320...
  • Page 29: Baud Rate (S)

    Additionally activate second channel via Pleora device port bulk 0 (MODE:UART). Reserved. Each character received from the host is echoed back to it. No Echo. Example: Set the factory default (115200 Baud and activate serial interface via Camera Link / Gigabit Ethernet). >s=2A[CR] VDS Vosskühler GmbH IRC-320...
  • Page 30: Save Parameters In Flash (X)

    66 (0x42) containing the text “Testtext” as data: >Q=10[CR] N00000007S4200[PAUSE]D5465737474657874 > As from confirmation of the command Q with [CR] the following characters are not echoed back as usual. That means that the control character sequence N00 … has to be send “blind”. VDS Vosskühler GmbH IRC-320...
  • Page 31 Q=<p8> ) until the host received the command prompt character “>”. Doing so will very likely corrupt the file system. In this case the camera has to be returned to VDS Vosskühler for system recovery. To retrieve (view) a file, the command v=<p8> may be used. This command directly outputs the data bytes of the specified file to the serial interface (not in ASCII hexadecimal notation as with Q=<p8>...
  • Page 32 IRC-320 camera. IRC-300CL/GE, IRC-320CL/GE, IRC-600CL/GE, NIR-300(F)(P)CL/GE and NIR-600PCL/PGE Series Command Help =============================================================================== Version....: V1A / 05.02.2009 / VDS Vosskuehler GmbH / JP Referenced Firmware...: V19 / V0110 General Information ------------------- Each command consists of a command letter, optionally followed by an equality sign and a parameter value in hexadecimal number representation.
  • Page 33 00 -> 12 bits slow, first word (e.g. IRC-300/320, NIR-300). 01 -> 12 bits slow, second word (for testing purposes). 10 -> 12 bits fast (e.g. NIR-300F or NIR-600). 11 -> 14 bits multiplex (e.g. VDS Vosskühler GmbH IRC-320...
  • Page 34 +--------f : Bypass the filtering of internally measured temperature. 0 -> Filter is enabled. 1 -> Filter is bypassed. n=<p16> : Slope n of the linear drift compensation term n*T + o. The VDS Vosskühler GmbH IRC-320...
  • Page 35 : File number of the first cold (low) reference image of the two point correction (Gain Offset Correction). Changing this parameter may void ex factory calibration. : No loading of any correction image. The memory content remains uninitialized at VDS Vosskühler GmbH IRC-320...
  • Page 36 In addition the set value K is added as offset to each pixel value. F=<p8> : Operation mode of the bad pixel correction. : Deactivated. Image data is passed through transparently. : Activated. Correction data C is employed. VDS Vosskühler GmbH IRC-320...
  • Page 37 K=<p16> : Define the set value for the warm (high) reference image of the two point correction. It is a 16 bits value of which the 12 (or 14) most significant bits currently are used. For VDS Vosskühler GmbH IRC-320...
  • Page 38 1 -> Successful. |+-------------------c : 0 -> The content of "a" is invalid. 1 -> The content of "a" is valid. +--------------------d : Continuous temperature measurement is enabled (mirrors bit "i" in parameter h). VDS Vosskühler GmbH IRC-320...
  • Page 39 X=1 afterwards. WARNING: The factory default configuration of the firmware usually is not identical to the camera specific ex-factory configuration. Especially individual calibration information may be lost by applying Z=1 followed by X=1! : Show this help text. VDS Vosskühler GmbH IRC-320...
  • Page 40 12 Declaration of CE Conformity 40 / 41 12 Declaration of CE Conformity VDS Vosskühler GmbH IRC-320...
  • Page 41 13 Revision History 41 / 41 13 Revision History Revision Date Description 18.03.2010 Full Updated VDS Vosskühler GmbH IRC-320...
