Manual
ION MINI PC
Prepared by
Trenton Systems
1725 MacLeod Dr
Lawrenceville, GA 30043
Date: August 20, 2020
Model Number: MPC1000
Revision: 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ION MPC1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Trenton Systems ION MPC1000

  • Page 1 Manual ION MINI PC Date: August 20, 2020 Prepared by Trenton Systems Model Number: MPC1000 1725 MacLeod Dr Lawrenceville, GA 30043 Revision: 2...
  • Page 2: Table Of Contents

    Section 0 / Table of Contents Table of Contents Preface ................................ 2 About Trenton Systems ..........................3 Warranty & Policies ........................... 4 Handling Precautions ..........................6 Regulatory Compliance ..........................7 What’s in the Box ............................8 System Overview ............................9 Diagrams &...
  • Page 3: Preface

    This product, including software and documentation, is the property of Trenton Systems and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
  • Page 4: About Trenton Systems

    EXPERIENCE Trenton Systems is trusted by the world’s leading technology companies. Some of our happy customers include Boeing, IBM, L3Harris, Northrop Grumman, Lockheed Martin and Raytheon. We also partner with Intel via the Embedded and Communications Alliance, which provides us with access to Intel’s roadmap, as well as with technical support directly from the company.
  • Page 5: Warranty & Policies

    In no event shall Trenton Systems, Inc. be liable for any defect in hardware or software or loss or inadequacy of data of any kind, or for any direct, indirect, incidental or consequential damages arising out of or in connection with the performance or use of the product or information provided.
  • Page 6 This manual is as complete and factual as possible at the time of printing; however, the information in this manual may have been updated since that time. Trenton Systems, Inc. reserves the right to change the functions, features or specifications of their products at any time, without notice.
  • Page 7: Handling Precautions

    WARNING: Risk of explosion if the MPC1000 battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. The MPC1000 uses a Panasonic CR2032 battery available from Trenton. The Trenton Systems part number for a replacement battery is 29-005774-000.
  • Page 8: Regulatory Compliance

    Section 4 / Regulatory Compliance Regulatory Compliance DECLARATION OF CONFORMITY This device complies with part 15 of the FCC rules as a Class A device. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that might cause undesired operation.
  • Page 9: What's In The Box

    Section 4 / What’s in the Box What’s in the Box ION Mini PC: Dimensions of the system measure 7.01” x 7.17” x 1.34” (L x W x H) Power Supply: CUI, Inc. SDI90-12-U Screws: HDD Mounting Screws Optional: Mounting Brackets Last Updated: August 20, 2020 | Manual (Rev 2)
  • Page 10: System Overview

    Section 5 / System Overview System Overview Figure 1: MPC1000 with side brackets - Front Figure 2: MPC1000 with side brackets - Rear Figure 3: MPC1000 Sides with brackets SERIAL NUMBER STICKER LOCATION Figure 4: Serial Number Location Last Updated: August 20, 2020 | Manual (Rev 2)
  • Page 11 Section 5 / System Overview MODEL NUMBER LAN:  o 2x RJ-45 Gigabit Ethernet LAN ports MPC1000 | Form Factor: Mini PC o 1x RJ-45 Shared IPMI LAN port PROCESSOR BOARD Serial: 1x RS232 Serial Port  MXT8288 |Type: Mini-ITX PROCESSOR DIMENSIONS ...
  • Page 12: Diagrams & Layouts

    Section 6 / Diagrams & Layouts Diagrams & Layouts BLOCK DIAGRAM Last Updated: August 20, 2020 | Manual (Rev 2)
  • Page 13 Section 6 / Diagrams & Layouts LAYOUT DRAWING Front Rear A3 A4 ITEM DESCRIPTION Power Connector DisplayPort 3x USB 3.0 Ports 1GbE LAN Port (Management Port) 2x 1GbE LAN Ports VGA Port Serial Port 2.5“ SATA SSD Drive M.2 NVMe x4 PCIe Heatsink over CPU 3x USB 3.0 Ports Audio In/Out...
  • Page 14: Technical Specifications

    Section 4 / Technical Details Technical Specifications MEMORY & STORAGE TYPE PART NUMBER SIZE 26-504615-001 8 GB 26-504615-002 16 GB 2.5” SSD 263500001521-00 240 GB 2.5” SSD 263500001522-00 480 GB 2.5” SSD 263500001523-00 960 GB 263500001543-00 250 GB 263500001534-00 512 GB 263500001533-00 1 TB This device complies with part 15 of the FCC rules as a Class A device.
  • Page 15 Section 4 / Technical Details i210 LEDs • Activity LED = Orange 10MBs Full Duplex= No LED • 100MBs Full Duplex = Green LED • 1000MBs Full Duplex = Amber LED • i350 LEDs Activity LED = Green • 10MBs Full Duplex= No LED •...
  • Page 16 Section 4 / Technical Details USB3 On-Board Header (USB3-6,7) (8287 only) 12V Jack (8288 only) XDP CONN (60p) (p.53) Front Panel Membrane LED/Switch I2C hdr (3P hdr) (smbxxx_host) BMC Serial (4P hdr) ATX Power (24-pin) (8287 only) Chassis Fan 0 (4P hdr) (8287 only) Chassis Fan 1 (4P hdr) (8287 only) Speaker (2P hdr) (p.22) CPLD/VR Program Hdr (10P .050”)
  • Page 17 Section 4 / Technical Details LED POST CODES BMC LEDs In Development BIOS LEDs *Please look at Layout Drawing A14 for LED Post Codes location on the board. PCH-H I/O MAPPING-PCI PCH PORT (LANE REVERSAL ON DESTINATION PCIE5-8) PCIe5,6 I350 (U6 to P7) (Gen2) PCIe6 AST2500 (Gen2) PCIe7,8...
  • Page 18 Section 4 / Technical Details USB2_11 USB2_P10: to BMC USB2A USB2_12 USB2_P11: to BMC USB2B USB2_13 Not Connected USB2_14 Not Connected USB3_1 USB3_0: P3-Lower (Rear IO Panel) USB3_2 USB3_1: P3-Middle (Rear IO Panel) USB3_3 USB3_2: P3-Upper (Rear IO Panel) USB3_4 USB3_3: P4-Lower (Front I/O Panel) USB3_5 USB3_4: P4-Middle (Front I/O Panel)
  • Page 19 Section 4 / Technical Details 1600 x 900 16:9 1280 x 1024 1152 x 864 1024 x 768 800 x 600 WINDOWS 10 VGA RESOLUTIONS DISPLAYPORT RESOLUTIONS 1440 x 900 1920 x 1080 1360 x 768 1680 x 1050 1280 x 800 1600 x 900 1152 x 864 1400 x 1050...
  • Page 20 Section 4 / Technical Details 2. Wait 15 seconds. 1. Remove the jumper shunt from pins 6 and 4 and use it to short pins 2 and 4 on the header for 5 seconds. 3. Remove the jumper shunt and return it to short pins 6 and 4. ENVIRONMENTALS Operating Temperature: 0ºC to 45ºC (min) ...
  • Page 21: Installation Instructions

    Section 4 / Technical Details Installation Instructions BEFORE STARTING INSTALLATION Read and understand the installation precautions listed in the “Pre-Installation Precautions”  section. Refer to the drawings and specifications in this chapter for:  o Using available screw hole positions o Locating and connecting jumpers and onboard headers PRE-Installation Precautions Wear a grounding strap attached to a grounded device to avoid damage from static...
  • Page 22 Section 4 / Technical Details INSTALLING THE M.2 DRIVE If you have an SSD on top of the M.2 slot, remove the SSD to access the M.2 compartment show on the right. Insert your M.2 card into the M.2 slot. The M.2 card will stick out slightly on one end before you place a screw in place.
  • Page 23 Section 4 / Technical Details Take the screw out of the accessory bag and a philips-head screw driver. Screw down the M.2 into its position. The final position of the M.2 is shown on the right. Last Updated: August 20, 2020 | Manual (Rev 2)
  • Page 24 Section 4 / Technical Details INSTALLING THE 2.5” SATA SSD DRIVE Loosen the right screw on the back-side of the SSD so that they protrude slighty to insert into the screw holes on the SSD plate within the ION Mini PC. Loosen the left screw on the back-side of the SSD so that they protrude slighty to insert into the screw holes on the SSD plate within the ION Mini PC.
  • Page 25 Section 4 / Technical Details Push the SSD into the connector by applying pressure on the top side of the SSD and into the SATA port. Tighten the SSD screw to hold it in place. Make sure that there’s no wiggle of the SSD once you are done fastening the final screw in place.
