- Page 1 TRC4011 4U RACKMOUNT COMPUTER & TVC4403 4U Rackmount Video Display Wall Controller No. TRC4011-xxx / TVC4403-xxx Revision C INSTALLATION GUIDE Publication No. 8404011-09142...
- Page 2 In no event shall Trenton Systems, Inc. be liable for any defect in hardware or software or loss or inadequacy of data of any kind, or for any direct, indirect, incidental or consequential damages arising out of or in connection with the performance or use of the product or information provided.
- Page 3 Systems cannot assume responsibility or liability for actual system use based on the examples and diagrams. No patent liability is assumed by Trenton Systems with respect to the use of the information, components, equipment or software described in this manual. This manual is as complete and factual as possible at the time of publication;...
-
Page 4: Table Of Contents
TRC4011 / TVC4403 Installation Guide Table of Contents HANDLING PRECAUTIONS BEFORE YOU BEGIN NTRODUCTION XTERNAL OWER OURCE IXED – R XTERNAL OWER OURCE EDUNDANT 5V C NTERNAL URRENT IMIT HASSIS OUNTING CHAPTER 1 - SYSTEM OVERVIEW ESCRIPTION , SHB & S... -
Page 5: Handling Precautions
• The TRC4011 and TVC4403 both have a net chassis weight of approximately 30lbs. (13.62kg). This base chassis weight includes the chassis, a system host board, a 14-slot backplane and a rear- mounted, fixed or redundant power supply. Use proper lifting techniques when moving and installing the system. -
Page 6: Before You Begin
4-6 inches (101-152mm) behind the chassis and 1-3 inches (25- 75mm) in front of the chassis. Any front cabinet doors or access aisles must accommodate a TRC4011 / TVC4403 front chassis clearance of at least 4.0” (102mm) in order to provide proper cable clearances for any front panel I/O port connections and to gain access to the system air filter for maintenance. -
Page 7: Chapter 1 - System Overview
Mean-Time-To-Repair (MTTR) times. *Refer to the agency approval section in chapter five and the TRC4011 / TVC4403 / TVC4403 Certificate Of Compliance document in chapter six for a complete listing of the Council Directive: 2004/108/EC-EMC Directive standards to which conformity is declared. - Page 8 TRC4011 / TVC4403 Installation Guide System Model Backplane SHB Model Description of Backplane SHB and System Power Supply Number Model Number Combination TRC4011-020 BPG7087 TSB7053 Backplane: 1 SHB Slot, 4 x16 PCIe, 5 x4 PCIe, 1 x4/x1 PCIe and 1...
-
Page 9: Additional System Elements
• 1 – Fan control kit • 3 – 102CFM system fans Consult with Trenton for available storage drives and optical media drives compatible with the TRC4011 / TVC4403 / TVC4403. SHB B ATTERY CAUTION: Risk of explosion if the system host board battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. -
Page 11: Chapter 2 - Physical Dimensions & Layout Drawings
TRC4011 / TVC4403 Installation Guide Chapter 2 - Physical Dimensions & Layout Drawings AYOUT IMENSION RAWING SHB and option card slot locations Note: Ensure that there is at least 4-6 inches (101-152mm) front and rear chassis clearance for cable connections and airflow. -
Page 13: Chapter 3 - Installation Instructions
The TRC4011 / TVC4403 is designed to be supported in the cabinet with rack slides or placed on a cabinet shelf. The front flanges of the computer are designed to secure the TRC4011 / TVC4403 to the rack cabinet’s front mounting rails... -
Page 14: Slide Rail Installation
LIDE NSTALLATION Trenton offers a slide rail kit to help with the installation of a 4U Trenton Systems’ computer chassis. Here are the installation instructions Trenton 18” Slide Rail kit. Remove slide rails from the box along with the rail frames, optional rack frame mounting brackets and the mounting hardware. - Page 15 TRC4011 / TVC4403 Installation Guide The following steps assume that your 19” instrument rack has round, non-threaded mounting holes for the slide rail frames. The optional rack frame mounting brackets accommodate the side flange rackmount hole placements. If your rack has other mounting hole types or placements, then you may need to consult with your rack supplier to obtain the correct slide rail mounting hardware.
-
Page 16: Connecting Ac Power
ONNECTING OWER The TRC4011 / TVC4403 requires a single-phase power source providing 110-240VAC at 50 to 60Hz to the AC input power outlet located at the rear of the chassis. Power must be available at the three-pin AC input receptacle located on the supply at the rear of the system. An over-current protection device shall protect the power cord. -
Page 17: Chapter 4 - Replacing System Components
OOLING The three cooling fans of the TRC4011 / TVC4403 are mounted along the top of the chassis. Each fan is secured to a fan carrier and can be removed by loosing the two thumbscrews and lifting out the assembly. -
Page 18: Air Filter
OWER UPPLY IXED The 860W rear-mounted, fixed power supply option used in the TRC4011 / TVC4403 rackmount computer is shown in the figure below. Rear View The system’s fixed-mount, rear-mounted, fixed power supply should only be removed and replaced by a trained electronics technician. -
Page 19: Preparation For Shipment
REPARATION OR SHIPMENT The TRC4011 / TVC4403 should always be removed from the rack cabinet if the unit must be shipped to another site. If possible, use the original shipping carton to ship the TRC4011 / TVC4403. NOTE: Never ship the TRC4011 / TVC4403 when it is mounted inside a rack; damage to the computer and rack cabinet will likely result. -
Page 21: Chapter 5 - Chassis Specifications
TRC4011 / TVC4403. The reverse can also be true in that a system subcomponent could have a lower operating temperature range that could lower the system’s overall operating temperature range. -
Page 23: Chapter 6 - Ce & Fcc Part 15 Subpart Bcertificates Of Compliance
TRC4011 / TVC4403 Installation Guide Chapter 6 - CE & FCC Part 15 Subpart B Certificates of Compliance TRC4011-000 CE Certificate of Compliance – BXT7059, BPG7087 and Fixed PS Configuration Trenton Systems, Inc. - Page 24 TRC4011 / TVC4403 Installation Guide TRC4011-010 CE Certificate of Compliance – JXT6966, BPG7087 and Fixed PS Configuration Trenton Systems, Inc.
- Page 25 TRC4011 / TVC4403 Installation Guide TRC4011-020 CE Certificate of Compliance – TSB7053, BPG7087 and Fixed PS Configuration Trenton Systems, Inc.
- Page 26 TRC4011 / TVC4403 Installation Guide TRC4011-001 CE Certificate of Compliance – BXT7059, BPG7087 and Redundant PS Configuration Trenton Systems, Inc.
- Page 27 TRC4011 / TVC4403 Installation Guide TRC4011-011 CE Certificate of Compliance – JXT6966, BPG7087 and Redundant PS Configuration Trenton Systems, Inc.
- Page 28 TRC4011 / TVC4403 Installation Guide TRC4011-021 CE Certificate of Compliance – TSB7053, BPG7087 and Redundant PS Configuration Trenton Systems, Inc.
- Page 29 TRC4011 / TVC4403 Installation Guide TRC4011-000 FCC Part 15 Subpart B Certificate of Compliance – BXT7059, BPG7087 and Fixed PS Configuration Trenton Systems, Inc.
- Page 30 TRC4011 / TVC4403 Installation Guide TRC4011-010 FCC Part 15 Subpart B Certificate of Compliance – JXT6966, BPG7087 and Fixed PS Configuration Trenton Systems, Inc.
- Page 31 TRC4011 / TVC4403 Installation Guide TRC4011-020 FCC Part 15 Subpart B Certificate of Compliance – TSB7053, BPG7087 and Fixed PS Configuration Trenton Systems, Inc.
- Page 32 TRC4011 / TVC4403 Installation Guide TRC4011-001 FCC Part 15 Subpart B Certificate of Compliance – BXT7059, BPG7087 and Redundant PS Configuration Trenton Systems, Inc. 6-10...
- Page 33 TRC4011 / TVC4403 Installation Guide TRC4011-011 FCC Part 15 Subpart B Certificate of Compliance – JXT6966, BPG7087 and Redundant PS Configuration 6-11 Trenton Systems, Inc.
- Page 34 TRC4011 / TVC4403 Installation Guide TRC4011-021 FCC Part 15 Subpart B Certificate of Compliance – TSB7053, BPG7087 and Redundant PS Configuration Trenton Systems, Inc. 6-12...
