BDI Vista 9950 Assembly Instructions

Component List
FB FF
HTL
HTR
HBL
HBR
Designed by Louis A. Lara
These distinctive product configurations are protected by US and international
patents, trade dress, and/or copyright laws. "Vista" and BDI are trademarks of
Becker Designed, Inc. All Rights reserved. ©2010, BDI
Made in China. 99509960REV03102010v2
V
i s t a
9 9 5 0 9 9 6 0
a n d
Large Hex Wrench x 1
Small Hex Wrench x 1
A - Base x 1
B - Adjustable Glides x 5
D - Spine x 1
E - 3/8 x 1.25" Flat Head
Screw x 4
FF - Front Panel x 1
FB - Back Cover Panel x 1
G -5/8" Long Phillips Head
Screw x 3
Screen Brackets x 4
I - 5/16 x .75" Pan Head
Screw x 16
L - Washer x 4
M - Nut x 4
a s s e m b l y i n s t r u c t i o n s
®
Your Vista ® Home Theater Furniture is engineered for easy assembly.
Carefully follow this procedure to prevent any damage.

Placement and Maintenance

Vista ® Home Theater Furniture is designed for indoor use on level floors.
Clean glass with glass cleaner and steel parts with a moist cloth.
Step 1

Unpack and Identify

Unpack and identify the components. Note that some components are
shipped inside the cabinet. The assembly workspace should be a non-
marring surface such as carpet. For missing hardware pieces, please
contact BDI Customer Service at customerservice@bdiusa.com. For all
other concerns, please contact your BDI Retailer.
Q
R
1
.
bdiusa com customerservice
N - Shelf Brackets
2 Left + 2 Right with 9960
O - Glass Shelf
x 2 with Model 9960
P - M8 x 1.5" Flat Head Screw
x 4 with 9960
S - Horizontal Mounting Bars x 2
T - Small Spacers x 4
U - Large Spacers x 4
V - Phillips Head Mounting Screws
(various thread sizes) x 32
Q - Wire Management Strap x 3
R - Plastic Fastening Pin x 3
@ .
bdiusa com
