Network - IKUSI Flow Set-Top-Box Installation Manual

Ikusi Flow STB guide
4.3 Video
It allows to configure the video outout resolution and the Graphic resolution. Also, pushing F1, it allows to select the frame
rate value and to choose between HDMI and DVI output.
4.4 Audio
It allows to configure the initial audio level and the output audio type (mono or stereo). Additionally, pushing F1, it allows to
configure other parameters such as dynamic range compression, operating mode, SPDIF mode and HDMI audio.
4.5 Advanced settings
It allows to modify the advanced settings such as language, time zone, UPnP client and buffer size. also, pushing D1 you will
find other options such as storages access mode, IGMP version and configuration of multicast proxy.
4.6 Keyboard layout
It allows to define the keyboard layout (language) that is being used.
4.7 Network info
It displays the network information associated to the STB.
4.8 Device info
It provides the specific information of the STB, such as model, serial number, MAC address or hardware version.
4.9 Restart portal
It allows to reload the middleware portal. In case of fail, it presents three options: to try again, to launch Embedded portal or
to return to System settings screen.
4.10 Reboot device
It allows to reboot the STB.
4.11 Reset settings
It removes the configuration that have been introduced manually, restoring the factory parameters.
4.12 Clear user data
It deletes all user settings from the device memory: access to e-mail accounts and online services, location for weather fore-
casts, channel lists and favourites, saved web bookmarks, keyboard layouts, lists of network resources, etc.
4.13 Software update
It allows to select the updating method of the STB (HTTP or USB) and to configure it.
4.14 Remote control
It allows to configure the device in order to be controlled remotely. You must define a name and a numeric password.
7
