- Page 1 User Manual DA16200 AT GUI Tool...
-
Page 2: Table Of Contents
How to Connect ..........................5 USB to Serial Driver ......................5 Setup Serial Terminal Utility ....................6 How to Run GUI for DA16200 Board ................... 7 Board Setup .......................... 7 Board Connection ......................... 8 RF Certification Mode Setup ....................9 3.3.1... -
Page 3: Figures
DA16200 AT GUI Tool Figures Figure 1: Terminal Configuration ......................6 Figure 2: Development Kit connections ....................7 Figure 3: AT GUI ........................... 8 Figure 4: RS232 Setup - Disconnected ....................8 Figure 5: RS232 Setup - Connected ..................... 8 Figure 6: Debug Console - Connected .................... -
Page 4: Terms And Definitions
Universal Serial Bus Microsoft Foundation Class References DA16200, Datasheet, Dialog Semiconductor DA16200, SDK_Programmer_guide, User Manual, Dialog Semiconductor DA16200, EVK_User_Guide, Dialog Semiconductor DA16200, AT Command User Guide, Dialog Semiconductor User Manual Revision 1.0 DRAFT 03-Jul-2019 CFR0012 4 of 20 © 2020 Dialog Semiconductor... -
Page 5: Introduction
The other port (UART0) is for debug console connection. This port is used for firmware update. ● If you want to update with a new DA16200 firmware, please refer to “DA16200 EVK User Guide”. RF certification program was developed by MFC. Therefore, this program may need to install the MFC library package. -
Page 6: Setup Serial Terminal Utility
DA16200 AT GUI Tool Setup Serial Terminal Utility Users can control DA16200 by using a serial terminal tool (e.g. Teraterm or SecureCRT) and the following configurations are required to connect to the console of DA16200. ● Port: Com port number on Windows system ●... -
Page 7: How To Run Gui For Da16200 Board
Here is the program setup sequence. ● DA16200 Development Kit is connected to the host PC over the connector, as shown in Figure 2 Figure 2: Development Kit connections Note) please refer to EVK User Guide to check the port. -
Page 8: Board Connection
DA16200 AT GUI Tool Figure 3: AT GUI Board Connection ● When AT GUI program runs, connection status is red (not connected). If any COM port is not detected by the program, press the R button to refresh COM Port Figure 4: RS232 Setup - Disconnected ●... -
Page 9: Rf Certification Mode Setup
DA16200 AT GUI Tool RF Certification Mode Setup To enable certification mode, check on the mode option on the Chip Setting tab Figure 7: Certification Mode Configuration Alternatively, on the Certification Mode tab. Figure 8: Certification Mote Tab 3.3.1 TX Test Mode ●... -
Page 10: Figure 10: Debug Console - Tx Mode
DA16200 AT GUI Tool ● Check TX Setting parameters and click the Mode Select button. Confirm message will be shown Figure 10. This is a normal state Figure 10: Debug Console - Tx mode ● Have to select Data Rate, Channel, and Power as you want to test. -
Page 11: Figure 11: Start & Stop Tx
DA16200 AT GUI Tool Start TX Stop TX Figure 11: Start & Stop Tx ● Tested setting is 802.11n MCS7, channel 1, 100 bytes packet and power grade 0. ○ When you click the Start TX button, you can see messages as blow. -
Page 12: Rx Test Mode
DA16200 AT GUI Tool 3.3.2 RX Test Mode ● RX Setting ○ Channel: Support CH1 ~ CH13 ○ Test Time: Maximum 3600s (Duration is 1 second fixed) Figure 14: Rx Configuration ● RX Packet Rate ○ FCS + PHY + Overflow packet / Total packet = Error rate Network Mode Setup To enable network mode, check on the mode option on the Chip Setting tab. -
Page 13: Station Mode
Choose the Station Mode and click the Select button on the Mode Select option show in Figure ● Network mode is changed, DA16200 reboots and the station mode setup window will be shown Figure 18 Figure 17: Debug Console - Station Mode ●... -
Page 14: Ap Mode
● Choose the AP Mode and click the Select button on the Mode Select option then network mode is changed, DA16200 reboots and the AP Mode setup window will be shown as Figure 22. Figure 21: Debug Console - AP Mode ●... -
Page 15: Figure 23: Debug Console - Ap Configuration
DA16200 AT GUI Tool Figure 23: Debug Console - AP Configuration ● Configure DHCP server. Set IP addresses and click the Confirm button. When a client is connected, its MAC address will be shown as Figure 24 Figure 24: DHCP Configuration... -
Page 16: Otp Mode Setup
MAC Address setup DA16200 provides 4 slots to store MAC addresses and the 1st slot is written by FCI. The customer can use 3 slots to write their own MAC address. The MAC address written in the OTP must be an even number, it is used for WLAN0 MAC address (for STA interface), and the next number is automatically used for WLAN1 MAC address (for Soft-AP interface). -
Page 17: Regulatory Approval
DA16200 AT GUI Tool Regulatory Approval Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 18: Manual Information To The End User
DA16200 AT GUI Tool 4.1.4 Manual Information to the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. -
Page 19: Revision History
DA16200 AT GUI Tool Revision History Revision Date Description 03-Jul-2019 Preliminary DRAFT Release User Manual Revision 1.0 DRAFT 03-Jul-2019 CFR0012 19 of 20 © 2020 Dialog Semiconductor... - Page 20 Dialog Semiconductor product (or associated software) can reasonably be expected to result in personal injury, death or severe property or environmental damage.
