- Page 1 User Manual This manual contains important information on safety, use, and maintenance of this product. Before using your F.Blumlein Steam Oven, please read this user manual in its entirety and keep in an easily accessible place for future reference. MODEL: JU-3200...
-
Page 2: Table Of Contents
Convection Steam Oven User Manual Table of Contents ............... Important Safety Instructions ....................Unpackaging ..................Cleaning and Care ................Instructions for Children .................. Technical Specifications .................... Package Contents ......................Parts List ....................Control Panel ...................... Overview ....................LCD Panel ................... Oven Functions .................... - Page 3 Convection Steam Oven User Manual Table of Contents Preset Cooking Modes ..................................DIY Recipe Modes Cleaning and Maintenance ................How to Remove the Rear Oven Panel ............. How to Clean the Top of the Oven ................................Cleaning Tips ....................
-
Page 4: Important Safety Instructions
Convection Steam Oven Important Safety User Manual Instructions Please read all instructions carefully before using this product for the first time to avoid the risk of accidents and damage to the appliance. This user manual contains important notes on installation, safety, use and maintenance of this product. F.Blümlein cannot be held liable for non-compliance with these instructions. - Page 5 Convection Steam Oven Warning and Safety User Manual Instructions 11. Steam will be rapidly evaporated and not easily seen if the oven cavity is at a high temperature or just finished using convection modes. This is normal. 12. Do not touch the door and door frame when using the appliance. 13.
- Page 6 Convection Steam Oven Warning and Safety User Manual Instructions 26. Clean dust from the power supply plug on a regular basis. If the product will not be used for a long time, remove the power supply cord. Do not pull the power supply cord but hold the plug to remove it.
- Page 7 Convection Steam Oven Warning and Safety User Manual Instructions 38. If the oven is delivered without a power cable, or if the power cable is damaged, it must only be replaced by a F.Blümlein approved service technician in order to avoid a hazard. 39.
-
Page 8: Unpackaging
Convection Steam Oven Warning and Safety User Manual Instructions 51. Warm steam is emitted from the front ventilation vent. Blocking the outlets will result in damage to the steam oven. 52. Odor will be emitted from the cavity when using different baking functions for the first time. -
Page 9: Instructions For Children
Convection Steam Oven Important Safety User Manual Instructions Try to avoid the interior walls being splashed with food or liquids containing salt. If it does happen, wipe these away thoroughly to avoid corrosion on the stainless steel surface. In areas which may be subject to infestation by cockroaches or other vermin, pay particular attention to keeping the appliance and its surroundings clean at all times. -
Page 10: Technical Specifications
Convection Steam Oven User Manual Technical Specifications Model JU-3200 Rated Voltage and Frequency 120V AC/60Hz Rated Input Power 1550 W Outer Product Dimensions (W × D × H) 20.9'' × 17.9'' × 15.9'' Cooking Area Cavity Dimensions (W × D × H) 15.2'' ×... -
Page 11: Parts List
Convection Steam Oven User Manual Parts List Main parts Accessories Grill Rack LCD Panel Air Outlet Steam Tray (with holes) Oven Light Baking Tray Air Inlet Insulated Gloves Upper Heating Element Sponge Water Tank Steam Outlet Oven Door Drip Tray... -
Page 12: Control Panel
Convection Steam Oven User Manual Control Panel Overview LCD Panel Navigation Setting Oven Light Power Sensor Combi Defrost Sterilize Confirm/Start/Pause Return Child Lock LCD Panel Defrost Sterilize Icon Function Description Timer Display Shows remaining cook time or delayed start time Cooking Time range: 00: 05 - 03: 00 Delay Start range: 00:01 - 23:59 Temperature Setting... - Page 13 Convection Steam Oven User Manual Control Panel Icon Function Description Cavity Temperature Setting When this icon is displayed you are viewing the current temperature inside the steam oven. Memory Code After cooking ends under manual settings, this icon will appear to allow you to save these settings to 1 of 10 DIY Setting slots.
-
Page 14: Oven Functions
Convection Steam Oven User Manual Control Panel Icon Function Description Steam This icon is displayed when using the steam function. Grill This icon is displayed when using the grill function. Convection This icon is displayed when using the convection function. Manual Oven Functions Press this button then use the navigation arrows to scroll through all oven functions. - Page 15 Convection Steam Oven User Manual Control Panel Icon(s) Time/Temp Time/Temp Mode Description Displayed Default Range High Steam cooking prevents moisture loss when using a higher baking temperature. The convection fan circulates Time: 30 mins Time: 5-180 mins steam to ensure even heating Temp: 350°F Temp: 210-450°F when cooking multiple layers...
- Page 16 Convection Steam Oven User Manual Control Panel Icon(s) Time/Temp Time/Temp Mode Description Displayed Default Range Preheat (Steam) preheats the oven to a preset temperature Time: N/A Time: N/A using steam and the lower Temp: 210°F Temp: 120-230°F (Steam) heating element. Preheat (Grill) preheats the oven to a preset temperature Time: N/A...
-
Page 17: Touch Panel
Convection Steam Oven User Manual Control Panel Touch Panel Icon Function Description Confirm/Start/Pause Used to start/pause cooking or confirm settings. Navigation Arrows Used to navigate through display panel settings, adjust temperature, set cook time, etc. Settings Set a delay on start time: after you have selected an oven function and set your temp and time, before you press , tap the Settings button to set a 00:01-23:59 long delay before your oven starts.. -
Page 18: Operating Instructions
Convection Steam Oven User Manual Operating Instructions Before Your Start When the steam oven is first plugged in a ‘beep’ will be heard and all of the icons on the control panel will light up. After three seconds, the oven will automatically enter standby mode. -
Page 19: Choosing An Oven Function
Convection Steam Oven Choosing an Oven User Manual Function The operating instructions for all of the oven functions are similar. Below you will find a few examples for setting the functions of your steam oven. Some general guidelines are as follows: Use the navigation arrows to select an oven function or cooking mode. -
Page 20: Using Preheat Mode
Convection Steam Oven Choosing an Oven User Manual Function 5. To delay cooking start time, press the Settings button after adjusting the temp and time settings but before pressing 6. If you want to start cooking immediately, press after adjusting the temperature and time settings. -
Page 21: Using Fermentation Mode
Convection Steam Oven Choosing an Oven User Manual Function 5. To delay start time, press the Settings button after adjusting the temp and time settings but before pressing 6. If you want to start cooking immediately, press after adjusting the temperature and time settings. -
Page 22: Using Descale Mode
Convection Steam Oven Choosing an Oven User Manual Function Using Descale Mode Water used during any steam mode may result in limescale or other buildup inside the oven cavity, water tank, or water hoses. Once your steam oven has reached 100 hours of steam-related operation, the Descaling Reminder icon will appear on the LCD panel. -
Page 23: Preset Cooking Modes
Convection Steam Oven Choosing an Oven User Manual Function Preset Cooking Modes Below are 25 pre-programmed cooking modes to get started with using your steam oven. When using these preset modes, you cannot adjust the time or temperature settings. 1. Fill the water tank with cold, filtered tap water to the MAX mark and install (not necessary for Grill or Convection modes.) 2. - Page 24 Convection Steam Oven Choosing an Oven User Manual Function MEATS & POULTRY Code Food Mode Time (min) Note Temp Fish Fillet Steam 210°F Two cooking stages Chicken Breast Steam 180°F (11 mins, 5 mins) Chicken Breast Combi 450°F Hot Dog/Sausage Convection 390°F Whole Chicken...
-
Page 25: Diy Recipe Modes
Convection Steam Oven Choosing an Oven User Manual Function DIY Recipe Modes You can create and save up to 10 of your most-used recipes for later use. You can save the temperature and time for your recipe and set anywhere from one to three cooking stages. -
Page 26: Cleaning And Maintenance
Convection Steam Oven Cleaning and User Manual Maintenance How to Remove the Rear Oven Panel 1. Use an 8mm or 5/16” socket to remove the 2 nuts on either side of the rear oven panel by turning counter-clockwise. 2. Remove the rear oven panel. Clean using a sponge or soft cloth. Use mild detergent as needed. -
Page 27: Cleaning Tips
Convection Steam Oven Cleaning and User Manual Maintenance Cleaning Tips 1. Under normal circumstances, cleaning is the only maintenance required for your steam oven. 2. After each use: i) Empty the black drip tray under the oven door to prevent overflow, splashes, or other messes. -
Page 28: Troubleshooting
Convection Steam Oven User Manual Troubleshooting Normal Conditions Problem Cause The steam oven produces a large amount of steam when Water condensation can using any steam function. Most of the steam will be vented be found around the from the front exhaust vent and some condensation water ventilation vent or oven may be found around the ventilation vent. -
Page 29: Malfunction Codes
Convection Steam Oven User Manual Operating Instructions Problem Possible Causes Solution Oven door is not closed Lots of water or steam Close the oven door tightly tightly can be found during cooking Door seal is damaged Light is damaged Oven light is not working Control board is damage Fan motor is damaged... - Page 30 support@fblumlein.com www.fblumlein.com (866) 782-2547 (10am-5pm PDT, Monday to Friday)
