  • Page 1 IGITAL INEMA DP30 REMIERE R9006100 NSTALLATION UIDELINES 17032003 R5976572/00...
  • Page 2 Barco Inc. - USA 3240 Town Point Drive, Kennesaw, GA 30144 Phone: (770) 218-3200 Fax: (770) 218-3250 E-mail: sales.us.bps@barco.com Visit us at the web: www.barco.com Barco nv Digital Cinema Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.84.93 Fax: +32 56.36.88.62 E-mail: info.bdc.bps@barco.com Visit us at the web: www.barco.com...
  • Page 3 The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of compliant, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period.

  • Page 5: Table Of Contents

    Index........................41 R5976572 DCINE PREMIERE DP30 17032003...
  • Page 6 Table of contents R5976572 DCINE PREMIERE DP30 17032003...

  • Page 7: Safety Instructions

    The part number and serial number are located at the left side of the projector in the environment of the power cord. Record these numbers in the spaces provided below. Refer to them whenever you call upon your BARCO dealer regarding this product.

  • Page 8: Electrical Safety

    Warning Risk of Fire: Do Not Place Flammable or Combustible Materials Near Projector ! BARCO large screen projection products are designed and manufactured to meet the most stringent safety regulations. This pro- jector radiates heat on its external surfaces and from ventilation ducts during normal operation, which is both normal and safe.

  • Page 9: Safety On Installation

    If the product exhibits a distinct change in performance, indicating a need for service. Replacement Parts When replacement parts are required, be sure the service technician has used original BARCO replacement parts or authorized replacement parts which have the same characteristics as the BARCO original part. Unauthorized substitutions may result in de- graded performance and reliability, fire, electric shock or other hazards.

  • Page 10: Safety On Cleaning

    Original Shipping package Save the original packing material; they will come in handy if you ever have to ship your projector. For maximum protection, repack your set as it was originally packed at the factory. R5976572 DCINE PREMIERE DP30 17032003...

  • Page 11: Packaging And Dimensions

    • Lens Packaging • Projector Dimensions 2.1 Box Content Content • 1 projector DCine Premiere DP30 • 1 anamorphic lens holder kit for single lens • 1 complete lamp housing with lamp • 1 European and 1 Amerivan power cable •...
  • Page 12 Remove box cover Carton side protection cover Manual and cable box Anamorphic lens holder kit Wooden board Intermediate carton Carton side protection cover projector Image 2-5 Removing the feed Image 2-4 Take off from the palet R5976572 DCINE PREMIERE DP30 17032003...

  • Page 13: Lens Packaging

    Always remove the lens before transporting the projector. 2.3 Lens Packaging Way of Packaging Lenses are supplied as an individual item. They are packed in a carton. 2.4 Projector Dimensions Projector dimensions Dimensions between brackets[] are in inch. R5976572 DCINE PREMIERE DP30 17032003...
  • Page 14 2. Packaging and Dimensions Image 2-7 Side view Image 2-8 Top view R5976572 DCINE PREMIERE DP30 17032003...
  • Page 15 2. Packaging and Dimensions Image 2-9 Front view R5976572 DCINE PREMIERE DP30 17032003...
  • Page 16 2. Packaging and Dimensions R5976572 DCINE PREMIERE DP30 17032003...

  • Page 17: Installation Guidelines

    Special care should be used when DLP projectors are used in the same room as performant laser equipment. Direct or indirect hitting of a laser beam on to the lens can severely damage the Digital Mirror Devices (TM) in which case there is a loss of warranty R5976572 DCINE PREMIERE DP30 17032003...

  • Page 18: Safety Area Arround The Projector

    Front ceiling configuration is the default configuration for a cinema room when projecting from the top of the room to the screen. Rear ceiling is also possible when the projector is installed behind a typical rear projection screen. Image 3-2 Front Table configuration R5976572 DCINE PREMIERE DP30 17032003...

  • Page 19: Pin Assignment Connectors Input Panel

    Receive Data (RD or RX or RXD) Request to send (RTS) 3 TXC- Transmitted Data (TD or TX or TXD) Clear To Send (CTS) 4TXC+ Data Terminal Ready (DTR) Ring Indicator (RI) 5 GND Signal Ground (GND) R5976572 DCINE PREMIERE DP30 17032003...
  • Page 20 2 RXA- Receive Data (RD or RX or RXD) 3 TXA- Transmitted Data (TD or TX or TXD) 4TXA+ Data Terminal Ready (DTR) 5 GND Signal Ground (GND) RS232/422 IN Image 3-7 D9 Female connector R5976572 DCINE PREMIERE DP30 17032003...
  • Page 21 Projector Good P GPIN 7 N GPIN 7 F GPIN 8 N TCODE- GPIN 8 F TCODE+ GPOUT 1 N GPOUT 1 P TCODE SHIELD GPOUT 2 N GPOUT 2 P GPIN 1 N GPOUT 3 N R5976572 DCINE PREMIERE DP30 17032003...
  • Page 22 BNC Connector A SMPTE 292 IN/B SMPTE 292 IN Image 3-11 BNC connector A SMPTE 292 IN Input A HDSDI B SMPTE 292 IN Input B HDSDI XLR Connector (Female) LTC IN Image 3-12 XLR Female connector Shield Tcode_P Tcode_N R5976572 DCINE PREMIERE DP30 17032003...

  • Page 23: Lenses

    4. Push the lens in the lens block gap horizontally, lining up the motor connector on the lens with the connector on the lens block (B), until the lens clicks in the lens anchor system. R5976572 DCINE PREMIERE DP30 17032003...

  • Page 24: Installation Of The Anamorphic Lens

    3 hex socket screws for anamorphic lens fixation (2x for dual support) Copper ring for anamorphic lens fixation (2x for dual support) 2 hexagon socket screws for lens support fixation G Lens holder support rod R5976572 DCINE PREMIERE DP30 17032003...

  • Page 25: Anamorphic Lens Holder Support Rod Mounting

    4. Secure the rod in the fixation block by tightening the 4 screws. 5. Reinstall the side cover. Image 3-16 Support rod block Image 3-17 Support rod input Image 3-18 Image 3-19 Groove in support rod Insertion in the support rod block R5976572 DCINE PREMIERE DP30 17032003...

  • Page 26: Anamorphic Lens Holder Mounting

    5. Secure the position of the lens support by tightening the 2 hexagon socket screws (B). 6. To rotate the lens support, pull the lens support lock handle (G) and rotate the lens support. (image 3-25) Image 3-20 Lens fixation screws Image 3-21 Insertion lens support fixation bar R5976572 DCINE PREMIERE DP30 17032003...
  • Page 27 Sliding the lens support onto the lens support bar Image 3-24 Lens support position Hexagon socket screws Gap between anamorphic lens and prime lens Prime lens Support rod Anamorphic lens holder Image 3-23 Lens support position R5976572 DCINE PREMIERE DP30 17032003...

  • Page 28: Insertion Of The Anamorphic Lenses Into The Holder

    3. Push the anamorphic lens into the holder in a way the rear side of the lens matches the depth of the lens holder. (image 3-26) 4. Secure the position of the anamorphic lens in the lens support by tightening the copper ring around the lens body by means of the 3 hexagon socket screws (I). R5976572 DCINE PREMIERE DP30 17032003...

  • Page 29: Cleaning The Lens

    Do not use liquid cleaners on the cloth as doing so will contaminate the cloth. Other lenses can also be cleaned safely with this Toraysee cloth. 3.5.4 Lens formulas Formulas Barco delivers 3 prime lenses and 2 anamorphic lenses. R5976572 DCINE PREMIERE DP30 17032003...

  • Page 30: Lamp Installation

    3. Line up the lamp unit guides with the guides on the projector frame (B) and push the unit into the frame until it fits. (image 3-29) 4. Secure the position of the lamp unit with the 3 spacer screws (C). R5976572 DCINE PREMIERE DP30 17032003...

  • Page 31: Optical Alignment Of The Lamp

    (A) are anchored by a lock screw (B) and sealed with a warranty label (Destroying the label void the warranty). The Optical adjustment to the Z-axis is recommended every time the lamp is changed or after a lot of run times to guarantee max light output. R5976572 DCINE PREMIERE DP30 17032003...
  • Page 32 4. Carefully adjust the adjustable screw (B), using an Allen key of 3mm, for maximum light fall on the screen. (image 3-32) 5. Lock the adjustable screw by fastening the lock nut (A). 6. Reinstall the side cover. R5976572 DCINE PREMIERE DP30 17032003...
  • Page 33 This procedure is only necessary when installing a new lamp. 1. Put a lightmeter in the center of the screen. 2. Project a full white pattern. 3. Remove the opposite side panel of the power connection. R5976572 DCINE PREMIERE DP30 17032003...
  • Page 34 5. Adjust both screws (B) with an Allen key (turn only a few turns) until maximum light fall on the screen. 6. Secure this position by fastening both securing nuts (A). 7. Reinstall the side cover. Image 3-34 Location of cold mirror Image 3-35 Cold mirror adjustment R5976572 DCINE PREMIERE DP30 17032003...

  • Page 35: Ac Power Requirements

    Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the left of the projector. The power input is 230 VAC. Image 4-1 R5976572 DCINE PREMIERE DP30 17032003...
  • Page 36 4. AC Power Requirements R5976572 DCINE PREMIERE DP30 17032003...

  • Page 37: Maintenance Of The Projector

    2. Pull out the dust filter. Image 5-2 Dust filters top Image 5-1 Dust filter side How to clean the dust filter 1. Brush dust from filter surface with camel-hair brush. 2. Blow remaining dust away with compressed air. R5976572 DCINE PREMIERE DP30 17032003...
  • Page 38 5. Maintenance of the Projector R5976572 DCINE PREMIERE DP30 17032003...

  • Page 39: Key Panel Automation Interface

    If connected to a touch panel, pressing a button causes an interrupt on which the touch panel sends the relay function to the button unit. A.3 In/Output specifications Input specifications Maximum input voltage Vmax=30V Minimum Input resistance Rin>3KOhm R5976572 DCINE PREMIERE DP30 17032003...

  • Page 40: Automation Interface Specifications

    They have an internal pull-up resistor of 10k. Image A-2 Automation interface module Pinning and default configuration: Connector J3 Signal Function Dowser open Signal return Dowser close Signal return Projector+Lamp ON Signal return Projector+Lamp OFF Signal return R5976572 DCINE PREMIERE DP30 17032003...

  • Page 41: Outputs Specifications

    Pinning and default configuration: Connector J1 Signal Function OUT 1: Normal open programmable OUT 1: Common programmable OUT 1: Normal closed programmable OUT 2: Normal open programmable OUT 2: Common programmable OUT 2: Normal closed programmable R5976572 DCINE PREMIERE DP30 17032003...
  • Page 42 Pinning and default configuration: Connector J2 Function Signal OUT 3: Normal open programmable OUT 3: Common programmable OUT 3: Normal closed programmable OUT 4: Normal open programmable OUT 4: Common programmable OUT 4: Normal closed programmable R5976572 DCINE PREMIERE DP30 17032003...

  • Page 43: Blockdiagram In/Outputs

    A. Key Panel Automation Interface A.4.3 Blockdiagram In/Outputs Block diagram Image A-4 Blockdiagram Key panel R5976572 DCINE PREMIERE DP30 17032003...
  • Page 44 A. Key Panel Automation Interface R5976572 DCINE PREMIERE DP30 17032003...

  • Page 45: Index

    Heat and Fire Hazards Input panel On cleaning Pin assignment On Shipping Lens Protection on Servicing Anamorphic Safety Precautions Installation guidelines 14, 26 Safety on Installation Configurations Lamp Installation Safety area Installation Guidelines Temperature Ambient Temperature Ambient R5976572 DCINE PREMIERE DP30 17032003...
  • Page 46 Index R5976572 DCINE PREMIERE DP30 17032003...
  • Page 47 Revision Sheet Barco nv Digital Cinema/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.84.93, Fax: +32 56.36.88.62 E-mail: antoon.dejaegher@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R5976572/00): page wrong correct R5976572 DC DP30 17032003 REMIERE...
