Yardline FAIRFIELD GABLE 10 x 10 Manual

305 x 305 cm
Hide thumbs
Table of Contents

Advertisement

Quick Links

16556
STOP!
STOP!
Call Us First!
DO NOT RETURN TO STORE.
For immediate help with assembly or product information
call our toll free number:
1-800-844-9273
or email:
customerservice@yardline.net
Our staff is ready to provide assistance
April through October M-F 8:00 AM to 4:30 PM EST
Saturday 8:30 AM to 4:30 PM EST
November through March M - F 8:00 AM to 5:00 PM EST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAIRFIELD GABLE 10 x 10 and is the answer not in the manual?

Questions and answers

Related Manuals for Yardline FAIRFIELD GABLE 10 x 10

Summary of Contents for Yardline FAIRFIELD GABLE 10 x 10

  • Page 1 For immediate help with assembly or product information call our toll free number: 1-800-844-9273 or email: customerservice@yardline.net Our staff is ready to provide assistance April through October M-F 8:00 AM to 4:30 PM EST Saturday 8:30 AM to 4:30 PM EST...
  • Page 2 (This page intentionally left blank.)

  • Page 3: Before You Begin

    Inventory all parts listed on pages 4 - 6. Contact our Customer Service Team if any parts are missing or damaged. • ADDITIONAL MATERIALS You will need additional materials to complete your shed. See page 3 for required and optional materials and quantities. - CUSTOMER SERVICE - 800-844-9273 Call: 1- email: customerservice@yardline.net...
  • Page 4 TOOLS Required Optional Phillips Tool Belt/ Utility Knife Screwdriver Nail Pouch Shingle Blades Drill / Driver Caulk Gun 1/8" Drill Bit Tin Snips 1/4" Drill Bit (for drip edge) 5/16" Drill Bit Paint Tools 1/2" Drill Bit Chalk Line #2 Philips Drive Bit Safety Glasses Hammer Nail Gun...

  • Page 5: Additional Materials

    ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • This shed includes a floor. • See the FLOOR LEVELING section on page 7 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site. REINFORCED WOOD FLOOR FRAME (OPTIONAL) IMPORTANT! This floor has been designed for general use.

  • Page 6: Parts List

    PARTS IDENTIFICATION AND SIZES WOOD SIZE CONVERSION CHART Part identification Nominal Board Size Actual Size letters are stamped on some parts. 2" x 4"....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1" x 4"....3/4" x 3-1/2" (1,9 x 8,9 cm) 2" x 3"....1-1/2" x 2-1/2" (3,8 x 6,3 cm) Check these locations for part stamp.
  • Page 7 PARTS LIST continued... 2 x 3 x10-1/8" (5,1 x 7,6 x 25,7 cm) 2 x 4 x 24" (5,1 x 10,2 x 61 cm) 1 x 4 x 23-7/8" (2,5 x 10,2 x 60,6 cm) 1 x 4 x 96" (2,5 x 10,2 x 243,8 cm) 2 x 4 x 96"...
  • Page 8 PARTS LIST continued... FLOOR FRAME 2 x 4 x 24" (5 x 10 x 61 cm) 2 x 4 x 17-1/2" (5 x 10 x 44,5 cm) TREATED TREATED 2 x 4 x 48" (5 x 10 x 122 cm) TREATED Treated lumber is stamped:...
  • Page 9 FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS Support seam. 4x4 Runners (not included). 8" (20,3 cm) 44"...
  • Page 10 CONCRETE FOUNDATION If you choose to install your kit on a concrete slab, refer to the diagram below. Treated Sill Plate Caulk between sill plate and concrete. 3-1/2" (8,9 cm) 4" (10,2 cm) Building Size Actual Size 10'x 10' (305 x 305 cm) 10'x 9'-8-1/2"...

  • Page 11: Parts Required

    FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) x28 NOTE: TREATED Look for Stamp. 2 x 4 x 96" (5 x 10 x 244 cm) TREATED TREATED 2 x 4 x 72" (5 x 10 x 183 cm) 2 x 4 x 24" (5 x 10 x 61 cm) TREATED TREATED 2 x 4 x 48"...
  • Page 12 FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) x28 TREATED NOTE: 2 x 4 x 96" (5 x 10 x 244 cm) Look for Stamp. TREATED TREATED 2 x 4 x 93" (5 x 10 x 236,2 cm) 2 x 4 x 24" (5 x 10 x 61 cm) TREATED TREATED 2 x 4 x 72"...
  • Page 13 FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) x28 Attach fl oor sections together as shown using 3" nails. Flush Flush (4) Nails per side, stagger pattern. 116-1/2" (295,9 cm) 120" (305 cm) FINISH You have fi nished your fl oor frame. Proceed to level and square frame.
  • Page 14 LEVEL AND SQUARE FLOOR FRAME Before attaching fl oor decking, it is important to level and square the fl oor frame. A level and square fl oor frame is required to correctly construct your shed. BEGIN See page 7 for the preferred fl oor leveling method. Use level and check the frame is level before applying fl oor panels.
  • Page 15 FLOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 5/8 x 48 x 96" 3/4" GAUGE (1,6 x 121,9 x 243,8 cm) BLOCK Ensure your wall frame is square by installing one panel and squaring frame. Install panels with rough side up (painted grid lines). BEGIN Attach the 48 x 96"...
  • Page 16 FLOOR PANELS PARTS REQUIRED: x138 3/4" GAUGE 2" (5,1 cm) BLOCK 5/8 x 48 x 96" 5/8 x 23-7/8 x 96" 5/8 x 20-1/2 x 96" 5/8 x 20-1/2 x 23-7/8" (1,6 x 122 x 243,8 cm) (1,6 x 60,6 x 243,8 cm) (1,6 x 52,1 x 243,8 cm) (1,6 x 52,1 x 60,6 cm) Continue installing the remaining panels in the following order:...
  • Page 17 IMPORTANT! Check that the floor frame is level after installing floor panels. Re-level if needed. • The floor should be used as a stable work surface for wall construction. • Organize your assembly procedure during the build process HINT: to avoid over-handling of the walls. LEFT WALL BACK WALL RIGHT WALL...

  • Page 18: Rafter Assembly

    RAFTER ASSEMBLY PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 4-7/8" (5,1 x 10,2 x 12,4 cm) You will build a rafter jig using the fl oor and two CLA parts as shown. ¸ BEGIN Secure one CLA fl ush to the fl oor deck using two 3" screws. Measure over 120-3/4"...
  • Page 19 RAFTER ASSEMBLY PARTS REQUIRED: 1-5/8" (4,1 cm) 2" (5,1 cm) GUSSET 6 x 24" (15,2 x 61 cm) 2 x 4 x 75-1/4" (5,1 x 10,2 x 191,1 cm) ¸ BEGIN Place two rafters ECN into the jig as shown. Keep ECN firm against outside CLA's as shown (Fig.A).
  • Page 20 RAFTER ASSEMBLY PARTS REQUIRED: 2" (5,1 cm) 1-5/8" (4,1 cm) GUSSET 6 x 24" (15,2 x 61 cm) 2 x 4 x 75-1/4" (5,1 x 10,2 x 191,1 cm) Gable-end rafter assemblies only have one gusset. Repeat steps to assemble two more rafters with only one gusset. 1/4"...
  • Page 21 FRONT WALL (Door Header) PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 67" (5,1 x 10,2 x 170,2 cm) 7/16 x 3 x 67" (1,1 x 7,6 x 170,2 cm) BEGIN Build Door Header with OSB in the middle, use 3” Nails. Glue both sides of OSB.

  • Page 22: Front Wall

    FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 24-1/2" (5,1 x 10,2 x 62,2 cm) 2 x 4 x 44-1/2" (5,1 x 10,2 x 113 cm) 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) Pre Assembled Header 2 x 4 x 72"...
  • Page 23 FRONT WALL PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 48 x 76" BLOCK (121,9 x 193 cm) x1 LEFT + x1 RIGHT Install all panels with primed side up. Place left and right 48" x 76" panels onto wall frame flush to top as shown. Secure panels with 2"...
  • Page 24 FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Temporary Support 11-7/8 x 76" 1 x 3 x 72" (1,6 x 7,6 x 182,9 cm) (30,2 x 193 cm) Place 11-7/8" x 76" panels onto wall frame fl ush to top of frame as shown. Secure panel using 2"...
  • Page 25 BACK WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) 2 x 4 x 44-1/2" (5,1 x 10,2 x 113 cm) BEGIN Orient parts on edge on floor.
  • Page 26 BACK WALL PARTS REQUIRED: x122 23-7/8 x 76" 2" (5,1 cm) (60,6 x 193 cm) 48 x 76" 3/4" GAUGE BLOCK (121,9 x 193 cm) Install back wall panels with primed side up as shown. Secure panels to frame using 2" nails 6" apart along edges and 12" apart on inside of panel. BEGIN HERE 3/4"...
  • Page 27 LEFT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 24" (5,1 x 10,2 x 61 cm) 2 x 4 x 20-5/8" (5,1 x 10,2 x 52,4 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) 2 x 4 x 92-5/8"...
  • Page 28 LEFT WALL PARTS REQUIRED: x122 20-5/8 x 76" 2" (5,1 cm) (52,4 x 193 cm) 48 x 76" 3/4" GAUGE BLOCK (121,9 x 193 cm) Install left wall panels with primed side up as shown. Secure panels to frame using 2" nails 6" apart along edges and 12" apart on inside of panel. BEGIN HERE 3/4"...
  • Page 29 RIGHT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 24" (5,1 x 10,2 x 61 cm) 2 x 4 x 20-5/8" (5,1 x 10,2 x 52,4 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) 2 x 4 x 92-5/8"...
  • Page 30 RIGHT WALL PARTS REQUIRED: x122 2" (5,1 cm) 20-5/8 x 76" (52,4 x 193 cm) 48 x 76" 3/4" GAUGE BLOCK (121,9 x 193 cm) Install right wall panels with primed side up as shown. Secure panels to frame using 2" nails 6" apart along edges and 12" apart on inside of panel. BEGIN HERE Flush 3/4"...

  • Page 31: Back Wall Installation

    BACK WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 1-1/2 x 2-1/2 x 69" (3,8 x 6,3 x 175,3 cm) 3" (7,6 cm) 2" (5,1 cm) BEGIN Center back wall assembly on the 120" (304,8 cm) fl oor dimension. Use OO as a temporary brace. Secure with two 3" screws. 3"...
  • Page 32 LEFT WALL INSTALLATION PARTS REQUIRED: 2" (5,1 cm) 2" (5,1 cm) BEGIN Secure back wall to left wall using one 2" screw into left wall top and bottom plates (Fig. A). ENSURE TOP OF WALL FRAMES ARE FLUSH. 2" (3,8 cm) Screw Flush Flush...
  • Page 33 LEFT WALL INSTALLATION PARTS REQUIRED: 1-1/2" (3,8 cm) 3" (7,6 cm) 3" (7,6 cm) Nail back wall panel to left wall stud using 1-1/2" nails 6" apart (Fig. C). Secure back wall top frame 2 x 4 using 3" screw toe-screwed into left wall frame at an angle as shown (Fig. D). Secure left wall to fl oor using 3"...
  • Page 34 RIGHT WALL INSTALLATION PARTS REQUIRED: 2" (5,1 cm) 2" (5,1 cm) BEGIN Secure back wall to right wall using one 2" screw into right wall top and bottom plates (Fig. A). ENSURE TOP AND BOTTOM PLATES ARE FLUSH. 2" (5,1 cm) Screw Flush Fig.
  • Page 35 RIGHT WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 1-1/2" (3,8 cm) 3" (7,6 cm) Nail back wall panel to right wall stud using 1-1/2" nails 6" apart (Fig. C). Secure right and back wall top plates using 3" screw toe-screwed at an angle as shown in (Fig. D). Secure bottom plate to fl oor using 3"...
  • Page 36 FRONT WALL INSTALLATION PARTS REQUIRED: 1-1/2" (3,8 cm) 2" (5,1 cm) BEGIN Center front wall assembly on the fl oor. Panel Flush Secure front wall using one 2" screw into left and right wall top and bottom plates (Fig. A). 2"...
  • Page 37 FRONT WALL INSTALLATION PARTS REQUIRED: 2" (5,1 cm) 3" (7,6 cm) 3" (7,6 cm) Nail lower edge of panels to fl oor frame using 2" nails 6" apart. Angle nail to hit fl oor frame (Fig. B). Secure front wall bottom plates to fl oor using 3" nails (Fig. B). Secure front wall top plate using one 3"...
  • Page 38 RAFTERS PARTS REQUIRED: 3" (7,6 cm) Preassembled Truss Preassembled Truss (2 gusset) (1 gusset) ¸ BEGIN Secure rafters to top plate with two 3" screws above notch, as shown in Fig. A, B. Note the One Gusset Rafters at each end. 24-3/8"...
  • Page 39 DOORS PARTS REQUIRED: 3" (7,6 cm) 1-1/2 x 2-1/2 x 69" (3,8 x 6,3 x 175,3 cm) 1-1/4" (3,2 cm) 1 x 3 x 5" (2,5 x 7,6 x 12,7 cm) Left Door Assembled Right Door Assembled BEGIN Orient parts as shown on flat surface. 3/8"...
  • Page 40 DOORS PARTS REQUIRED: 3" (7,6 cm) 1-1/2 x 2-1/2 x 69" (3,8 x 6,3 x 175,3 cm) BEGIN Attach temporary support OO as a ledger board flush under wall panels for doors to rest on, using three 3" screws (Fig. A). Fig.
  • Page 41 DOORS PARTS REQUIRED: 3/4" (1,9 cm) x11 2" (5,1 cm) Bagged seperately / special coating 19/32 x 2-1/2 x 51" (1,5 x 6,3 x 129,5 cm) 64" Metal Threshold 3/4" (1,9 cm) 19/32 x 2-1/2 x 51" (1,5 x 6,3 x 129,5 cm) 19/32 x 3 x 26-5/8"...
  • Page 42 DOOR STIFFENERS PARTS REQUIRED: 2" (5,1 cm) 1-1/2 x 2-1/2 x 69" (3,8 x 6,3 x 175,3 cm) BEGIN Center OO’s vertically on the left and right doors as shown (Fig. A,B). Secure using (7) 2" screws through outside trim into OO (Fig. B). Fig.

  • Page 43: Door Hardware

    DOOR HARDWARE PARTS REQUIRED: 1/2" (13 mm) Drill Bit 1/4" (6 mm) Drill Bit 3/4" (1,9 cm) BEGIN Measure and mark location of hole on outside of right door as shown (Fig. A) . Pre-drill hole with 1/4" drill. Re-drill hole with 1/2" drill (Fig. A) . Keep drilled hole square to trim to avoid breaking edge of 1-1/2"...
  • Page 44 DOOR HARDWARE PARTS REQUIRED: Handle (locking) with Screws 1-1/4” Secure handle with 1-1/4" screws as shown. 1-1/4" Wood Screw Screw Pre drill for screws...

  • Page 45: Top Plate

    FRONT GABLE PANELS PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 3 x 17-3/16" (5,1 x 10,2 x 43,7 cm) 21-1/2 x 36" 21-1/2 x 36" (54,6 x 121,9 cm) (54,6 x 121,9 cm) BEGIN Measure distance from over-door trim to top plate (Fig. A). Fig.
  • Page 46 FRONT GABLE PANELS PARTS REQUIRED: Place gable center panel (use panel with vent hole) fl ush to installed left panel. Secure panel to BJC using 1-1/2" nails. Place second BJC as shown under center panel as shown. Transfer the measurement from STEP - 1, Fig. A onto the center gable panel. Secure panel to BJC using 1-1/2"...
  • Page 47 FRONT GABLE PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Front Gable Unit BEGIN Center front gable unit on front wall top plate. Secure gable unit with 2” Nails. 2" (5,1 cm) Nails Fig. A TOP PLATE 6" (15,2 cm) Working inside, secure gable unit with 3"...
  • Page 48 BACK GABLE PANELS PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 4 x 17-3/16" (5,1 x 10,2 x 43,7 cm) 21-1/2 x 36" 21-1/2 x 36" (54,6 x 121,9 cm) (54,6 x 121,9 cm) BEGIN Orient BJC on fl at as shown. Place left front gable panel as shown and secure using 1-1/2"...
  • Page 49 BACK GABLE PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Back Gable Unit BEGIN Center back gable unit on front wall top plate. Secure gable unit with 2” Nails. 2" (5,1 cm) Nails Fig. A TOP PLATE 6" (15,2 cm) Working inside, secure gable unit with 3"...
  • Page 50 FRONT GABLE LADDERS PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 4-7/8" (5,1 x 10,2 x 12,4 cm) 2 x 3 x 75-1/4" (5,1 x 7,6 x 191,1 cm) BEGIN You will build two assemblies (Fig. B). Fig. B Arrange, measure and mark locations of four CLA as shown place ECA on top.

  • Page 51: End View

    FRONT GABLE LADDERS PARTS REQUIRED: 2" (5,1 cm) 7/16 x 8-5/8 x 27-1/4" 7/16 x 8-5/8 x 48" (1,1 x 21,9 x 69,2 cm) (1,1 x 21,9 x 121,9 cm) Left Ladder Frame Right Ladder Frame Arrange ladders and roof panels as shown (Fig. C) to make a right and a left gable assembly. Attach roof panels using 2"...
  • Page 52 FRONT GABLE OVERHANG PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) BEGIN Place the left gable unit onto rafter as shown (Fig. A). Ensure gable unit is fl ush against gable panel, fl ush at peak (Fig. B). Secure gable unit panel to rafter using 2" nails 6" apart (Fig. A). Flush 2"...
  • Page 53 ROOF PANELS PARTS REQUIRED: x202 2" (5,1 cm) 7/16 x 20-5/8 x 27-1/4" (1,1 x 52,4 x 121,9 cm) 7/16 x 48 x 96" (1,1 x 121,9 x 243,8 cm) Roof panels may cause serious injury until securely fastened. Note: all roof panels need to be installed with the rough side up (painted grid lines). BEGIN Attach a 48"...
  • Page 54 ROOF PANELS PARTS REQUIRED: 7/16 x 27-1/4 x 48" 3/4" GAUGE (1,1 x 69,2 x 121,9 cm) BLOCK Secure top of each lower panel using one 2" nail into each rafter, as shown (Fig. B). Maintain spacing at 24" between the centers of the rafters. Fig.
  • Page 55 ROOF PANELS PARTS REQUIRED: 7/16 x 20-5/8 x 48" 7/16 x 27-1/4 x 48" 3/4" GAUGE (1,1 x 55,6 x 121,9 cm) (1,1 x 69,2 x 121,9 cm) BLOCK Attach another 27-1/4" x 48" roof panel with a 3/4" measurement on the rafter (Fig. C) and flush to the installed panels.
  • Page 56 ROOF PANELS PARTS REQUIRED: Secure top of each lower panel using one 2" nail into each rafter, as shown (Fig. D). Maintain spacing at 24" between the centers of the rafters. Fig. D 20-1/4" 24" 24" 24" 24" (51,4) cm) (61) cm) (61) cm) (61) cm)
  • Page 57 FRONT GABLE SOFFITS PARTS REQUIRED: 2" (5,1 cm) 3/8 x 7-7/8 x 73-5/16" (1 x 20 x 186,2 cm) Ensure soffi t panels are fl ush at seam (Fig. B) and fl ush at peak. BEGIN Position right and left 73-5/16" overhang panels primed side down, fl ush to front wall (Fig. A), centered with gable panel seam (Fig.
  • Page 58 EAVE SIDE SOFFITS PARTS REQUIRED: 2" (5,1 cm) 3/8 x 5-7/8 x 45-3/8" (1 x 14,9 x 115,3 cm) 3/8 x 5-7/8 x 72-3/4" (1 x 14,9 x 184,8 cm) Ensure soffi t panels are fl ush at rafter ends (Fig. B) and fl ush at seam. BEGIN Position 72-3/4"...
  • Page 59 EAVE SIDE FASCIA PARTS REQUIRED: 2" (5,1 cm) 3/8 x 4-3/4 x 45-3/8" (1 x 12,1 x 115,3 cm) 3/8 x 4-3/4 x 80-5/8" (1 x 12,1 x 204,8 cm) Ensure fascia panels are fl ush at seam (Fig. B). BEGIN Position 80-5/8"...
  • Page 60 GABLE TRIM PARTS REQUIRED: SHIM 2" (5,1 cm) 3/8 x 3-1/4 x 5-7/8" (1,0 x 8,3 x 14,9 cm) Painted 3/8 x 4-3/4 x 75-7/8" (1 x 12,1 x 192,7 cm) Painted Green 3/8 x 4-3/4 x 75-7/8" (1 x 12,1 x 192,7 cm) BEGIN Install 3-1/4 x 5-7/8"...
  • Page 61 CORNER TRIM PARTS REQUIRED: 2" (5,1 cm) 3/8 x 1-3/4 x 73-7/8" (1,0 x 4,4 x 187,6 cm) 3/8 x 1-3/4 x 74-1/2" (1,0 x 4,4 x 189,2 cm) ¸ BEGIN Attach corner trim as shown using 2" fi nish nails. 74-1/2"...
  • Page 62 SHELVING PARTS REQUIRED: 2" (5,1 cm) 2 x 3 x10-1/8" (5,1 x 7,6 x 25,7 cm) 3/8 x 8 x 12-1/2" (1 x 20,3 x 31,8 cm) BEGIN Secure AE to bracket panels using three 2" nails. Assemble 6 shelf supports as shown; 5 right-side, 1 left-side. Flush 2"...
  • Page 63 SHELVING PARTS REQUIRED: 2" (5,1 cm) 1-1/4" (3,2 cm) 7/16 x 11-7/8 x 96" (1,1 x 30,2 x 243,8 cm) 7/16 x 11-7/8 x 23-7/8" (1,1 x 30,2 x 60,6 cm) 1 x 4 x 96" (2,5 x 10,2 x 243,8 cm) 1 x 4 x 23-7/8"...
  • Page 64 LOFT PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 24" (5,1 x 10,2 x 61 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) ¸ BEGIN Orient parts TP and RL on a flat surface. Spread glue across RL and TP as shown (Fig. A). Hold parts TP and RL flush and aligned.
  • Page 65 LOFT PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 24" (5,1 x 10,2 x 61 cm) (NOT ACTUAL SIZE) 3/8" x5-1/2" (1 cm x 14 cm) Hex Bolt 3/8" (1 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) Flat Washer Pre-Assembled Loft Joist 3/8"...
  • Page 66 LOFT PARTS REQUIRED: 2" (5,1 cm) 20-1/2" x 96" (52,1 x 243,8 cm) Install loft panel centered over loft joists. Secure with 2" nails 8" apart. There will be a gap of approximately 8-1/2" on either side. 2" (5,1 cm) 8 "...
  • Page 67 COLLAR TIE PARTS REQUIRED: 2" (5,1 cm) 1 x 3 x 72" (2,5 x 7,6 x 182,9 cm) BEGIN Position and level collar tie on 3rd rafter from back. HINT: For best appearance install collar tie on rafter facing away from door opening. Attach with 2"...
  • Page 68 TRANSOM WINDOW PARTS REQUIRED: 3/4" (1,9 cm) Transom Window ¸ BEGIN Seal window behind fl ange edges with high-quality exterior-grade caulk before installing (Fig. A). Ensure window is level and centered. Place transom window in gable opening. Transom Window Fig. A HINT: Caulk behind frame near edge...
  • Page 69 TRANSOM WINDOW PARTS REQUIRED: 2" (5 cm) 19/32 x 2-1/2 x 9" (1,5 x 6,3 x 22,8 cm) 19/32 x 2-1/2 x 32-3/4" (1,5 x 6,3 x 83,1 cm) Mark centers and install window trim over transom window using 2" fi nish nails. 2"...
  • Page 70 WALL VENT PARTS REQUIRED: 1/2" (1,3 cm) 8 x 16" (20,3 x 35,6 cm) BEGIN Choose walls for vent locations. Measure and mark vent hole in wall as shown. Cut out marked opening. Caulk behind vent fl anges. • For best ventilation install one vent low and the other high.
  • Page 71 PAINT & CAULK - NOT INCLUDED - • Use acrylic latex caulk that is paintable. Caulk at all horizontal and vertical seams, between the trim and walls, and all around the door trim. • Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: •...
  • Page 72 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2" 1" Sealing Strip 1" (1,3 cm) (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS.
  • Page 73 SHINGLES continued... Beginning at front of shed, install first row of shingles with notch at 1" past roof edge or flush with drip edge. Roof Deck FRONT OF BACK OF SHED SHED 1" (2,5 cm) Flush with starter row. Notch - or - Drip Edge Flush with starter row.
  • Page 74 SHINGLES continued... Continue installing rows of shingles to the peak. At the peak make sure there is a maximum of 5" or less to the rain slot, as shown below. If shingles overlap at ridge cut to peak with a utility knife. 5"...
  • Page 75 SHINGLES - RIDGE CAP • You will finish off the top of the roof with a ridge cap made from shingles. BEGIN Cut shingles into THREE pieces. Hint: Use cut-off pieces first. 2" 2" (5 cm) (5 cm 2" 2" 2"...
  • Page 76 SHINGLES - RIDGE CAP continued... Continue installing ridge cap to back of roof. Make sure there is 4" between the shingle-color and edge of shingles. 4" (10 cm) Trim cap off fl ush to shingles When you have 4" minimum of shingle color cut one piece to cap your roof. Cut at top of rain slot.
  • Page 77 (This page intentionally left blank.)

  • Page 78: Warranty Registration

    WARRANTY REGISTRATION Please complete your warranty registration to properly validate your warranty. Register your product online at:www.OnlineWarranty.net. LIMITED CONDITIONAL WARRANTY* Backyard Storage Solutions, LLC warrants the following: Every product is warranted from defects in workmanship and manufacturing for 1 year. All accessories, hardware and metal components are warranted for 2 years.
