PROGRAMMABLE LED CONNECTION

Betaflight F7 has an available connection for RGB LEDs. Once connected these LEDs can be programmed to
output a variety of colors. The connection guide below will show you where to connect the power, gnd, and
signal wires if you choose to use this option.

BEEPER CONNECTION

Connecting a beeper to Betaflight F7 couldn't be easier. With very little effort you can help protect your quad
by setting up a switch for those times when you may need a lost model alarm to help you find you quad.
