- Page 1 SIMPLE MANUAL RS201 Quick Guide English ver.
-
Page 2: Safety Precautions
1. Safety Precautions Warning · · Do·not·apply·excessive·force·to·the·product,·throw·or·give·impact·to·the·product·using·sharp· objects. · · When· used· by· children,· a· protector· or· a· guardian· should· give· guidance,· and· check· if· safety· precautions·are·being·followed. · · Use· at· the· temperature· range· of· 0°C· -· 40°C.· Do· not· use· in· humid· places.· Use· of· product· at· temperatures·under·0°C·or·in·sealed·places·with·high·temperatures·can·lead·to·failure,·corrosion,·... -
Page 3: List Of Component
2. List of Component 3. Button’s Location and Function Front Side Power·Button·&·Status·LED Volume (Up/Down) Mute (Push) Bluetooth Product Remote Controller Multi-touch·IPS·Wide-view·LCD Headphone Output Rear Side SIMPLE MANUAL Line PreAmp Input Output Reset Output·Speakers·4~16Ω Adapter Power·Cord Manual Micro·SD USB·2.0 Battery·for·Remote Screw·for·SSD Screwdriver Controller Power... -
Page 4: Connection And Operation
4. Connection and Operation Inserting SSD ❶ Loosen·bottom·of·screws(2ea)·· ··❷ Push·OPEN·indicator,·seperate·SSD·cover·· ▶ ▶ Connecting Power Adapter ❸ Put·SSD·on·the·SSD·cover·· ··❹ Fix·SSD·by·screws·in·the·box·· ▶ ▶ ❺ Assemble·the·cover·· ··❻ Push·LOCK·indicator·and·tighten·screws ▶ · · Please·follow·the·procedure·below. ※ SSD is optional, Only 7mm height is supported. ❸ ❶ ❷... - Page 5 · · Menu·Widget·:·Move·on·to·other·menus·by·the·left/right·scrolling Available·to·set·in·the·external·input(· ·). Icon of Menu Incoming·New·Alarm,·check·the·mail·box. Music Play·Music·from·Memory·or·Network. Sleep·timer·setting Radio Listen·to·the·Internet·Radio. Icon·for·headset·connection·status. ROSETube Enjoy·YouTube·contents·without·any·commercial. ROSEPodcast Bluetooth·device·is·connected. Enjoy·Podcast·contents. Video Play·Video·from·Memory·or·Network. DLNA·is·connected,·it·would·be·restart·when·click. (White·:·Booting·/·Gray·:·Connection·off·/·Flickering·:·Connecting) Check·time·and·set·the·Alram. Time Check·location·to·get·weather·information. Airplay·is·connected,·it·would·be·restart·when·click. (White·:·Booting·/·Gray·:·Connection·off·/·Flickering·:·Connecting) Setting Show·RS201·information·and·edit·setting. WiFi·and·Ethernet·Signal·Reception, External input Show·status·of·LOCAL.·OPTICAL.·LINE·INPUT.·Available·to·edit. Move·to·network·setting·when·click. - 6 - - 7 -...
-
Page 6: Internet Connection
Connect·Ethernet·connector·to·the·socket·· ··Click·on·Settings(· ·)·· ··Move·to·Ethernet· ▶ ▶ Settings·· ··Activate·Ethernet·switch(· ·)·· ··Connected ▶ ▶ HiFi Media Player RS201 High Quality Sound Station ROSE RS201 03:27 04:13 Connecting to Home Network 7. Connecting Mobile Devices · · RS201·can·play·files·from·PC·and·NAS. Select·music(· ·)·or·video(· ·)·in·homescreen·· ··Select·Folder·Button·· ··Select ▶... -
Page 7: Specification
Type·A(1Port) RCA·L/R(1Port) Pre Out ROSE Connect (Remote App) Line In RCA·L/R(1Port) USB Type C OTG(1Port) · · Searching·ROSE·Connect(·· ··)·in·App·store,·Google·playstore,·It·is·a·variable·to·download·and·setup. Digital In Optical(1Port) · · RS201·and·the·application·should·be·connected·to·the·same·AP.(Wireless·Network) Digital Out Optical(1Port) Using·ROSE·Connect·can·control·RS201·in·remote. Speaker L+/L-,·R+/R-(MAX·100W) (Music.·Video.·Radio.·ROSETube.·Podcast.·Power.·Volume·and·etc) Input Voltage AC100-240V·50/60Hz Adaptor Out Voltage DC·24V,·5.0A Adapter(1ea).·AC·Power·Code(1ea).·Simple·Manual(1ea).·Bluetooth·Remote·... -
Page 8: Quality Certification
· Name of the company that received the conformity assessment : CITECH·Co.·Ltd · Country of manufacture : South·Korea · Identification code of authenticated person : SYH · Authentication number : R-R-SYH-RS201 Things to check before contacting a service center · · Please·restart·the·product·if·touch·does·not·work·or·if·the·screen·freezes.·If·you·press·and·hold·... - Page 9 Remote App Download (ROSE Connect) Android Download iOS Download www.hifirose.com Made in Korea...
