3. Initial State

Figure 2 shows an initial state of the lab board. 'G' represents the initial state of the drone,
which means the drone is grounded at the beginning.
PA6
PA7
PC0
PC1
PC2
PC3
PC4
PC5
PC6
PC7
PL0
PL1
PL2
PL3
PL4
PL5
PL6
PL7
+5V
LCD CTRL
LCD CTRL
KEYPAD
KEYPAD
KEYPAD
KEYPAD
KEYPAD
KEYPAD
KEYPAD
KEYPAD
LED BAR
LED BAR
LED BAR
LED BAR
LED BAR
LED BAR
LED BAR
LED BAR
MOTOR
E
RS
C3
C2
C1
C0
R3
R2
R1
R0
LED2
LED3
LED4
LED5
LED6
LED7
LED8
LED9
OpE
