Page 1 Installation, Operation, Maintenance Manual NBC™ Belt Narrow Belt Conveyor Accumulation with CRUZcontrol ® & Transportation P/N: 1118140 Revision Date: July 29, 2020...
Page 2: Table Of Contents
3.6: D ............................ 21 EFINITION OF ERMS 3.7: P ..........................22 RODUCT ESCRIPTIONS CHAPTER 4: NBC RECEIVING AND SITE PREPARATION ................23 4.1: P ......................24 ARTS NVENTORY AND DENTIFICATION CHAPTER 5: NBC INSTALLATION DETAILS ...................... 25 5.1: D ......................... 25...
Page 3 ONNECTIONS 10.7: G NBC ........................49 UARDRAIL OUNTING ON 10.8: CRUZ C6 N ......................51 CHANNEL TO IECE CHAPTER 11: NBC AIR SUPPLY REQUIREMENTS ................... 52 11.1: L ..........................53 RESSURE WITCH 11.2: A ................55 EGULATOR ALVE N AND OSITION CHAPTER 12: NBC LOGIC MODULE CONCEPTS ....................
Page 4 NBC™ Flat Belt - IOM 17.8: NBC E ........................123 ULLEY SSEMBLY 17.9: NBC 12 ....................... 124 ONTACT CCUMULATION 17.10: NBC L ......................125 OGIC ODULE OMPONENT 17.11: NBC 12 ................. 126 ONTACT CCUMULATION KEWED OLLERS 17.12: NBC 12 ................. 127...
Page 5: Chapter 1: Iom Introduction
IOM I NTRODUCTION IOM Purpose Manual Structure It is the intent of TGW Systems, through this You s h o u l d receive a separate manual, to provide information that acts as a documentation for each product line of TGW guide in the installation, operation, and Systems implemented in your installation.
Page 6: Chapter 2: Tgw Systems Policies
Consequential damages of any sort are wholly excluded. the TGW warranty on any failed components The liability of TGW Systems will be limited to the that result from these environment issues. replacement cost of any defective part. All freight and...
Page 7: Tgw Recommends Proper Labels For Conveyor Types
NBC™ Flat Belt - IOM 1.1: TGW R ECOMMENDS ROPER ABELS FOR ONVEYOR YPES Shown below are some samples of labels applicable to conveyor standards. P/N: 1118140 Rev: 07/29/2020 Page 7 of 129...
Page 8: Warnings And Safety Instructions
Your TGW Systems conveyor is powered by a motor and can be stopped only by turning off electrical power to the motor. As with all •...
Page 9: Arnings And Afety Nstructions
• Never remove, deface, or paint over WARNING or CAUTION labels. Any damaged label will be replaced by TGW Systems at no cost by contacting Lifetime Services. It is very important to instruct personnel in proper conveyor use including the •...
Page 10 NBC™ Flat Belt - IOM WARNING Before servicing or performing any work in the motor control panel, • disconnect and lock out air and the main incoming service. If only the panel disconnect is off, the incoming side will still be hot.
Page 11: Tgw Systems Conveyor Controls Safety Guidelines
The following basic conveyor control safety guidelines are recommended by TGW Systems even though Business Partner may or may not purchase conveyor controls from TGW Systems. The items listed deal with applications of controls equipment. The actual installation of the equipment must always follow the National Electric Code and all other local codes.
Page 12 NBC™ Flat Belt - IOM An emergency stop should normally stop all conveyors in the system. Very large systems may involve dividing a system into zones of control based on proximity of personnel, safety hazards, walls obstacles, etc. Controls Logic Solid state controls logic devices, such as programmable controllers are used extensively for conveyor control.
Page 13: Chapter 3: Nbc Introduction
The conveyor differences are as follows: Contact Accumulation The NBC contact accumulation zones are 4' long, but operate in such a manner as to allow mixed length product to dense pack accumulate. The products are allowed to touch and bump, but are at zero-pressure accumulation after they stop.
Page 14 NBC Logic Module Assembly Transportation The NBC transportation has the same spring loaded pressure pans as the accumulation versions, but no air diaphragm to disengage the pressure pan. A plastic Cam can be manually activated to lock the pressure pan in the down position for ease of belt installation. However, once the plastic Cam is manually deactivated, the pressure pan always holds the drive belt in contact with the carrier roller.
Page 15: Nbc Guidelines
The conveyor downstream from progressive release NBC must run at a speed which allows it to receive products as fast as they are released from the NBC conveyor. There will not be a gap or means of detecting a specific product, directly on the end of NBC without a downstream speed-up bed.
Page 16 NBC™ Flat Belt - IOM Ambient temperature is +35° to +120°F for Nitta belts. For applications outside this temperature range, contact Applications Engineering. P/N: 1118140 Rev: 07/29/2020 Page 16 of 129...
Page 17: Nbc Technical Applications
5th logic module to basic. Discharge Zone A function module is provided for the discharge bed prior to shipping. If the NBC line is feeding another NBC line, a release type function module is not required. Horsepower Principles The horsepower required for NBC conveyor is based on the effort (in pounds) to pull the belt through the conveyor (belt pull), turning all the rollers and moving the product at a given speed.
Page 18: Nbc General Cautions
Rollers in the center 4’ zone in all 12’ intermediate beds are designed to skew if required. No • other rollers in the bed can be skewed. Any NBC conveyor that has skewed rollers without proper installation will immediately and permanently VOID ALL TGW WARRANTIES.
Page 19: Alve Pplications
ALVE PPLICATIONS NBC Air Transportation Conveyor NBC Flat Belt Air Transportation is typically used in conjunction with a downstream NBC Flat Belt Contact Accumulation conveyor. Air Pilot Valve NBC Air Transportation should be used when downstream accumulation is full. The air pilot valve receives a signal from the last downstream accumulation zone and disengages the pressure pan assemblies for the entire unit.
Page 20 NBC Contact Accumulation zone clears, a control signal triggers the Solenoid Valve to activate (close or stop the air flow) and the NBC Air Transportation conveyor will activate and convey the product downstream. Review the detail above to determine correct Pilot or Solenoid Valve Kit on the NBC Contact Accumulation conveyor flow.
Page 21: Definition Of Terms
Logic Assembly The logic assembly is used to setup the type of automatic accumulation of product on the conveyor. Air-to-brake (Type of Logic assembly used in NBC conveyors – Normally Open Valve) Function Module The function module provides electrical isolation for external signals used to control a CRUZcontrol system.
Page 22: Product Descriptions
NBC™ Flat Belt - IOM 1.7: P RODUCT ESCRIPTIONS For the most current list of “Product Description” and “Terms and Abbreviations” Log into www.tgw-conveyor.com and select Support/Engineering Support Documents. P/N: 1118140 Rev: 07/29/2020 Page 22 of 129...
Page 23: Chapter 4: Nbc Receiving And Site Preparation
ECEIVING AND REPARATION Receiving TGW Systems NBC flat belt conveyors are shipped in subassemblies. These subassemblies are packaged to guard against damage in shipment when handled properly. Examination immediately following unloading will show if any damage was caused during shipment. If damage is evident, claims for recovery of expenses to repair damaged or replace components must be made against the carrier immediately.
Page 24: Parts Inventory And Identification
NBC™ Flat Belt - IOM 1.8: P ARTS NVENTORY AND DENTIFICATION Each subassembly is shipped completely assembled except typical loose parts, which are in boxes with the subassemblies. Segregate the conveyor subassemblies by types for inventory and ease of locating during installation.
Page 25: Chapter 5: Nbc Installation Details
NBC™ Flat Belt - IOM NBC I NSTALLATION ETAILS NBC General Procedures The following procedures are to be used as guidelines only. Specific installation methods will vary somewhat depending on available equipment on site and each installer's preferences based on past experience.
Page 26 NBC™ Flat Belt - IOM two diagonals, the frame is not square. A “racked” conveyor will skew the rollers, causing the belt to wander off center. The conveyor sections are joined together with welded butt plate connectors. If a conveyor section is determined to be out of square, adjustment must be made before proceeding to the next section.
Page 27: Supports & Connections
Charge and discharge end beds IMPORTANT! Do not make alterations to the equipment without consulting with user’s representative and TGW Systems. Unauthorized modifications to the equipment may impair its functions, create a hazardous condition, affect its useful life and /or void the warranty.
Page 28: Elevations
CAUTION Consult the building architect or a structural engineer regarding ceiling loading or structural limitations of the building if any conveyor section is ceiling hung. TGW is not responsible for permits regarding ceiling load data. 1.15: L TRAIGHTNESS CAUTION Line straightness must be maintained or belt will miss-track and result in damage to the conveyor.
Page 29: Chapter 6: Gear Motor Activation
NBC™ Flat Belt - IOM OTOR CTIVATION PRIOR to systems activiation - Please inspect the gear unit for a vent and if applicable to the product remove the rubber sealing plug to activate. The vent is designed to allow excessive pressure to escape.
Page 30 NBC™ Flat Belt - IOM NOTE: Yellow tags may be tucked out of sight. Please inspect all motors for a vent and remove sealing plug, if present, to activate. The following pictures are examples showing where vent plugs may be located depending on the product line and motor position.
Page 31: Chapter 7: Nbc, Nitta Belt Welding Instructions
Description Item # 1207112 TOOL,NBC-NITTA-RENTAL-WELDER KIT-FULL TGW Rental Kit Include: Finger Punch Press, T-wrench, Heated Weld Press, Pre-setter Mold, Silicone Sheet, Instruction Manuals, and Flash Drive with Instruction Video. Each Press Kit Is Shipped in a Hard Case. NITTA BELT WELDER AND PUNCH HARD CASE...
Page 32 NBC™ Flat Belt - IOM CAUTION Never field splice NBC Nitta blue urethane belt (TGW P/N 1205548) with mechanical lacing, as the belt fabric is not designed to hold lacing. Replacement Parts - Nitta belt WeldIng TGW NITTA BELT FULL WELD & PUNCH KITS...
Page 33: Chapter 8: Threading The Belt
POWER to the logic modules. This will depress the pressure pans and open up a belt path. Without air, all the rollers are engaged as NBC is a spring-to-drive system and it will be extremely difficult to thread the belt.
Page 34 NBC™ Flat Belt - IOM Step 3 Remove bottom guard on drive to have access for belt threading (250-AT30 drive guard shown – the 500-AT bottom guard is a flat plate). Step 4 Uncoil the new belt. With the air pressure ON the logic, and the logic module power OFF, attach a sheet metal splint or the belt threading tool (attached to each drive from factory P/N 1118104) with tape to the end of the belt.
Page 35 Remove the Duct tape. Before cutting the belt to length, make sure there is 18” overlap for NBC 250-AT30 and for NBC 500-AT 36” overlap. The overlap is to compensate for belt loss in the finger splice process.
Page 36 NBC™ Flat Belt - IOM Step 5 Remove rollers at each end and insert the splint with belt attached. Push belt into conveyor. It will be necessary to remove sections of rollers every 30' or 40' to help pull / push the belt through.
Page 37 Form more NBC applications TGW recommends the following IOM’s at https://www.tgw- conveyor.com/technologies/belt-driven-roller-conveyor/nbc-manual TGW Also recommends NBC maintenance videos for tracking the NBC belt and NBC belt alignment https://www.tgw-conveyor.com/media-center/maintenance-videos/82-belt-driven-live-roller P/N: 1118140 Rev: 07/29/2020...
Page 38: Threading Belt In Nbc Transportation Conveyor
RANSPORTATION ONVEYOR Step 1 NBC transportation conveyor is spring to drive with no air. To open a belt path, two Cams under each pressure pan must be rotated to the high side of the Cam. Rotate to high side of Cam 3/4”...
Page 39: Chapter 9: Nbc Air Take-Up
NBC™ Flat Belt - IOM NBC A 1.18: 500 LB.-AT. 250-AT30 D RIVE ENSIONING Step 1 With primary air pressure on and belt installed, slide air shutoff switch forward to engage the air tension on the belt (shown). The belt tension will automatically adjust.
Page 40 NBC™ Flat Belt - IOM Wiring (Optional) Proximity Switch - 500-AT Drive Air Take-up There is a location for wiring a proximity switch in the air take-up. This can be used to shut off the drive should the belt stretch to the point of bottoming out the take-up or if a belt would break.
Page 41: Nbc Cross Sections
NBC™ Flat Belt - IOM 1.19: NBC C ROSS ECTIONS NBC accumulation with CRUZchannel rollers low NBC transportation with C6 channel rollers high P/N: 1118140 Rev: 07/29/2020 Page 41 of 129...
Page 42: Chapter 10: Nbc Skewing Nbc Rollers
KEWING OLLERS Skewing rollers is required on NBC if you are using contact accumulation and if the between frame (BF) dimension of your conveyor is double the width of the smallest product. The normal method of skewing is to install a factory skew bed at the charge end of your conveyor. If your conveyor line is over 100' long and you have small product on it, you may want to add a maintenance skew bed midway down the conveyor to preserve the product alignment.
Page 43 NBC™ Flat Belt - IOM 12' Skew Bed Installation TGW Systems' dedicated 12' skew bed typically is installed as the first 12' bed section in a NBC conveyor line, starting from the charge end. The rollers are factory skewed to the requested side and the installation is the same as any other NBC intermediate bed section.
Page 44: Maintenance Skew Section
4’ skew area. Maintenance skew beds are typically used in contact accumulation NBC lines over 80' which have small product on them. After initial alignment by a charge skew bed, maintenance skew beds keep products aligned.
Page 45: Roller Centers 2
NBC™ Flat Belt - IOM 1.22: I NSTALLATION TEPS FOR IELD NSTALLED KEWED AINTENANCE RESSURE SSEMBLIES NOTE: The required parts and instructions to add a maintenance skew zone are included in zippered bag attached to the conveyor side channel and located on the inside face of the channel on the opposite side of the belt.
Page 46 NBC™ Flat Belt - IOM Step 2 Install belt guard in 9/32" dia. hole provided. Belt guard provides support of small product at the formation of the skewed zone. New Style Finger Guard Step 3 Skew rollers 3/4" to direct the product to the alignment side.
Page 47: Roller Centers
NBC™ Flat Belt - IOM 1.24: R 3” OLLER ENTERS Step 1 Select the conveyor section in which the rollers are to be skewed. Determine the direction of skew desired. All rollers in the middle zone are used for skewing.
Page 48: Cruz ® Xrol ® C C
NBC™ Flat Belt - IOM 1.25: CRUZ ® ® CHANNEL TO HANNEL ONNECTIONS ALIGN INSIDE SURFACES OF SIDE CHANNELS 4-7/8 4-1/2 7-1/2 6-3/8 1-1/2 P/N 80700119 3/8 HARDWARE (TYP) KIT,CHANNEL CONN P/N 92300004 4to7ChannelConn-89003 ALIGN INSIDE SURFACES OF SIDE CHANNELS...
Page 49: Guardrail Mounting On Nbc
UARDRAIL OUNTING ON NBC can be supplied with rollers low which uses the CRUZ side channel 1 ½” high guardrail. If C6 channel is supplied, any of several height angle guardrail can be used. CRUZchannel side frame acts as a guardrail Use 1-1/2"...
Page 50 NBC™ Flat Belt - IOM Adjustable guard single high and double high Flared lead-in section for adjustable channel guardrail. Use part #117657 at the entrance of all adjustable channel guardrail P/N: 1118140 Rev: 07/29/2020 Page 50 of 129...
Page 51: Cruz Channel To C6 Nose Piece
NBC™ Flat Belt - IOM 1.27: CRUZ C6 N CHANNEL TO IECE A CRUZchannel to C6 nosepiece provides a smooth transition for products moving from rollers high conveyor to rollers low conveyor. Kit #1125371 C6 to CRUZ nosepiece P/N: 1118140...
Page 52: Chapter 11: Nbc Air Supply Requirements
Air Drops TGW Systems recommends using at least 3/4" pipe on air drops for high flow and low pressure loss. The drop is terminated with a drain at the bottom. A tee located prior to the drain branches off to the conveyor.
Page 53: Low Pressure Switch
CAUTION Loss of conveyor control will occur if air pressure is not maintained. A pressure switch is required to be installed into the pneumatic circuit feeding an NBC conveyor system to detect a drop in air pressure below operating limits.
Page 54 1. Compressor HP = total CFM ÷ 3.55 2. Air tank size = approx. 1 gallon per CFM The formulas to determine air consumption follows: SCFM = .0019 x number of zones x releases per minute for NBC contact accumulation. P/N: 1118140 Rev: 07/29/2020...
Page 55: Ir Egulator Ock Ut Alven And Ff Osition
NBC™ Flat Belt - IOM 1.29: A EGULATOR ALVE N AND OSITION NOTE: • The air regulator valve label details the on and off positions. • For air pressure regulations please see detailed instruction in this manual. WARNING Do not remove and install sleeve valve to infeed side of regulator. Back feeding through the regulator will cause damage and void the warranty.
Page 56: Chapter 12: Nbc Logic Module Concepts
NBC. It is the intent of TGW Systems, through this manual, to provide information that acts as a guide in the installation, operation, and maintenance of TGW Systems conveyors featuring CRUZcontrol Logic.
Page 57 The CRUZcontrol product line is a set of off the shelf components used to setup accumulation and discharge on NBC conveyor. It consists of logic modules that detect product which control accumulation, function modules that release product, and 24 VDC power supplies. There are also accessories such as sensors and cables to ease installation and interfacing.
Page 58: Setting Logic Modules
NBC™ Flat Belt - IOM 1.31: S ETTING OGIC ODULES After mechanical and electrical installation is complete and there is air to the system, the logic modules may need to be reset. All logic modules are factory set in the basic mode indicated by the green light. This logic mode may be adequate for your conveyor system.
Page 59: Basic And Progressive Logic
ASIC AND ROGRESSIVE OGIC Every NBC accumulation conveyor is equipped with logic modules that can be switched from basic to progressive logic with a manually activated toggle switch. A green light indicates basic mode and an amber light progressive mode.
Page 60 NBC™ Flat Belt - IOM Basic Logic Operation Basic Logic functions such that when any two successive photoelectric sensors are blocked, the upstream zone is set to accumulate (stop driving). In the above example: The discharge zone, Zone 6, is shown stopped, signifying that release from the zone is being •...
Page 61 NBC™ Flat Belt - IOM Progressive Logic Operation Progressive accumulation functions such that no zones are set to accumulate unless ALL the downstream electronic sensors are blocked, meaning that all downstream zones hold accumulated product. In the above example, the discharge zone, Zone 6, is shown stopped which is the result of the release from the zone being inhibited (receiving conveyor is stopped) and the Zone 6 sensor being blocked.
Page 62 NBC™ Flat Belt - IOM CAUTION CRUZcontrol Logic Assemblies are designed to be fail-safe. A loss of module power, a disconnected or severed cable, or a dirty or failed photoelectric sensor will all result in the stopping of a zone, initiating accumulation beginning from the affected zone assuming that air pressure is present.
Page 63: Application - Cruz ® Logic
Logic Modules and Release Rates Your NBC conveyor comes with a field switchable logic module for every zone. All the logic modules are shipped in the basic mode. This will be indicated by a green light when the 24VDC power is activated.
Page 64 Failures to follow the 4:1 logic module rule will result in voiding the factory warranty. NBC Releasing Accessories Two items are always required at the discharge end of an NBC accumulation conveyor: 1. A signal to release or accumulate product 2.
Page 65 A signal to release or accumulate product This is normally a 24V signal from the system PLC to the release function module of the NBC. These Function Modules will accept 115 VAC control inputs. There are some cautions that must be observed to avoid Function Module hardware failure.
Page 66: A Method Of Stopping The Coasting Product
For speeds up to 129 FPM, a brake with six coated rollers is sufficient. Standard brake kits are available for NBC. For speeds from 130 FPM to 230 FPM, a stop is recommended at the discharge end of NBC to stop the coasting product and begin accumulation. Standard stop assemblies are available for NBC.
Page 67 NBC™ Flat Belt - IOM A belt unit downstream can be used in place of either a brake or a stop. If this belt option is selected, use the CRUZ ® belt 4 series. P/N: 1118140 Rev: 07/29/2020 Page 67 of 129...
Page 68: Nbc Components
The photoelectric sensor will function reliably on conveyor widths up to 34" between frames. The sensor is polarized, and is not affected by shiny surfaces. On NBC applications, the reflector is mounted with a 6 inch offset from the photoelectric sensor, so that the sensor scans across the conveyor on a slight angle.
Page 69 NBC™ Flat Belt - IOM Logic Assembly Types The CRUZcontrol Logic Assembly 1114947 provides an “air to brake” logic output utilizing a normally open pneumatic valve. The pneumatic valve is energized for a zone to be running. Logic Assembly Functions The CRUZcontrol Logic Assembly comes with a momentary button on the front of the housing allowing for selection of either Basic Logic or Progressive Logic mode.
Page 70: Function Modules
NBC™ Flat Belt - IOM 1.36: F UNCTION ODULES The Function Module provides electrical isolation for external controls and creates controllable zones to facilitate CRUZcontrol applications. Function Module Types There are two different Function Modules, each providing a set of functions: Full Function Module (1116731) and Release Function Module (1116732).
Page 71 NBC™ Flat Belt - IOM Slug Release Definition The slug line is turned on. All Logic Assemblies that are connected in one continuous string will release at the same time regardless of zone status. Configuration When using TB2; JP1, 1-2 and JP2, 1-2 to release all Logic Assemblies.
Page 72 NBC™ Flat Belt - IOM Slug Interrupt Downstream Definition Downstream slug line is disconnected. Logic Assemblies downstream will not slug release when the Slug Release signal goes high. Configuration JP1, 2-3 all other jumper terminals should be on pins 1-2.
Page 73: Terminal Block Descriptions
NBC™ Flat Belt - IOM 1.37: T ERMINAL LOCK ESCRIPTIONS Table 5: Terminal Block Descriptions Terminal Descriptions Single release, Logic interrupt Pulse release. This terminal is an isolated input; it must be used when signal voltage is from a supply that is different than the supply powering CRUZcontrol logic assemblies.
Page 74: Jumper Descriptions
NBC™ Flat Belt - IOM 1.38: J UMPER ESCRIPTIONS Table 6: Jumper Descriptions Jumper Descriptions Downstream slug control Pins 1-2 = slug pass through Pins 2-3 = slug interrupt Pins 3-4 = slug interrupt Pins 4-5 = singulation to slug crossover...
Page 75: Use Of 115 Vac Controls
NBC™ Flat Belt - IOM 1.39: U 115 VAC C SE OF ONTROLS Important information regarding the use of 115 VAC controls: These Function Modules will accept 115 VAC level control inputs. There are some cautions that must be observed to avoid Function Module hardware failure.
Page 76: Function Module Part Numbers
NBC™ Flat Belt - IOM 1.40: F UNCTION ODULE UMBERS Table 7: Function Module Part Numbers Part Number Description 1116731 Full Function Module 1116732 Release Function Module Figure 3: Function Modules P/N: 1118140 Rev: 07/29/2020 Page 76 of 129...
Page 77 NBC™ Flat Belt - IOM Figure 4: Full Function Module Board Layout Figure 5: Full Function Module Circuit P/N: 1118140 Rev: 07/29/2020 Page 77 of 129...
Page 78 NBC™ Flat Belt - IOM Figure 6: Release Function Board Layout Figure 7: Release Function Module Circuit P/N: 1118140 Rev: 07/29/2020 Page 78 of 129...
Page 79: Chapter 13: Nbc Power Supply Requirements
NBC™ Flat Belt - IOM NBC P OWER UPPLY EQUIREMENTS A 24 VDC power supply is needed to power the logic assemblies and the function modules. One power “T” cable is prewired to each power supply. Power supplies are available in 120 VAC or 480 VAC input versions.
Page 80: Power Supply Wiring
NBC™ Flat Belt - IOM 1.42: P OWER UPPLY IRING Connection made between two Logic Assemblies using a T Cable This drawing illustrates a power connection made between two intermediate accumulation zones making use of a “T” Cable. NOTE that all power and control signals, including the Slug and Logic Signals, pass through the “T”...
Page 81 NBC™ Flat Belt - IOM One Power Supply used to power two separate CRUZcontrol sections This drawing illustrates the use of one power supply to power two separate, short CRUZcontrol sections on two different conveyors. A second "T" cable is required to connect the second CRUZcontrol section to the power supply.
Page 82 Release Signals as well as 0VDC are connected to pass the signals through uninterrupted. Figure 10: One CRUZcontrol Section with Two Power Supplies Power Supply Part Numbers TGW Systems Part Number Description PWS, 24VDC,3.9A,120VAC, NBC CLASS 2, W/ 2X2 T- 1117972 Kit Part Number CABLE 1117431...
Page 83: Accessories
Appropriate holes are provided for the photoelectric sensor mounting bracket. The discharge end of NBC conveyor is also provided with an additional mounting location for a photoelectric sensor and reflector.
Page 84 NBC™ Flat Belt - IOM Extension Cables The following extension cables are available to meet application requirements where longer zone lengths or skipped zones must be accommodated. Each cable has 4 conductors, with male and female 2X2 connector ends. Part Number...
Page 85 Since every application is different, there will usually be a need to drill mounting holes for the brackets. Table 14: Discharge Logic Assembly Part Number Description 1117859 KIT, NBC DISCHARGE LOGIC 1/2" TOR (½ inch above rollers scan height) 1117860 KIT, NBC DISCHARGE LOGIC 3"TOR (3 inch above rollers scan height) P/N: 1118140...
Page 86: Chapter 14: Cruzcontrol On Site Installation
NBC™ Flat Belt - IOM CRUZ CONTROL ON NSTALLATION Pre-installed on the conveyor The CRUZcontrol Logic Assemblies are installed on the side channel of the conveyor bed. • The air supply tubing (3/8” OD X ¼” ID) for the conveyor is plumbed along the length of the •...
Page 87 NBC™ Flat Belt - IOM Figure 12: Logic Assembly P/N: 1118140 Rev: 07/29/2020 Page 87 of 129...
Page 88: Chapter 15: Conveyor Flow
NBC™ Flat Belt - IOM ONVEYOR The logic assembly wiring is “in-line” for left hand flow conveyors; for right hand flow conveyors the wiring direction will be reversed. Cables will cross under the logic module assembly. Figure 13: Left Hand Flow Conveyor Bed...
Page 89 NBC™ Flat Belt - IOM Example 1: Releasing from CRUZcontrol Releasing from CRUZcontrol Problem Releasing Accumulated Product Solution When using CRUZcontrol the product will automatically accumulate. A signal must be given to the function module to get it to release.
Page 90 NBC™ Flat Belt - IOM Figure 16: Non-Isolated Input Single Release Example 2: Creating a work zone Creating a work zone Problem Creating a work zone in the middle of a section of CRUZcontrol Solution Use the release function module and interrupt the downstream logic to start accumulation.
Page 91 NBC™ Flat Belt - IOM Figure 17: Work Zone Figure 18: Work Zone Using TB Figure 19: Work Zone Using TB1 4 P/N: 1118140 Rev: 07/29/2020 Page 91 of 129...
Page 92 The Discharge Logic Assembly is connected to the Logic Assembly at the discharge end of the NBC conveyor. There is no need for a Function Module to be attached to it. The DLA does not need to be given a release signal. Product blocking that photoelectric sensor will stop release from the NBC discharge zone, until the photoelectric sensor clears again.
Page 93 NBC™ Flat Belt - IOM Example The NBC is running at 180 FPM, feeding the induction conveyor section prior to a pick zone module diverter. Without proper control of the discharge from the NBC, cartons released to the induction conveyor could possibly overdrive it and push past the 90 FPM section onto the 180 FPM section, not permitting product gapping to occur as required for the diverter to function properly.
Page 94 NBC™ Flat Belt - IOM Operation The Product Present Photosensor is connected to a PLC (programmable logic controller). The Photosensor is used to sense if product is accumulated behind the Product Stop, ready to be released. The Photosensor is also used to sense a gap in the flow of product adequate enough to raise the Product Stop after releasing product from the lane.
Page 95 This section describes the development requirements for the TGW CRUZcontrol logic module to be used with NBC. The new modules will be a complete solution that controls product flow through either “basic” and “progressive” accumulation with single or slug release. “Basic” accumulation may also be described as single accumulate where product detection in two consecutive zones will cause the upstream zone to accumulate.
Page 96 NBC™ Flat Belt - IOM Figure 20: TGW Conveyor CRUZ-Channel Figure 21: Logic Module Wiring for over molded 2x2 Daisy Chain Cables Description of Logic Two accumulate modes will be selectable on the module and two release modes will be available via wiring.
Page 97 NBC™ Flat Belt - IOM In accumulation, any two consecutive sensors detecting product will cause the upstream zone of the two consecutive zones to deactivate until the downstream zone is no longer detecting product. The logic signal is passed upstream on Pin 2.
Page 98 NBC™ Flat Belt - IOM Pneumatic Valve The pneumatic valve shall be embedded in the logic module housing and satisfy the requirements outlined in Table 20. Table 17: Pneumatic Valve Specification Operating Pressure Range 0-40 PSI (0-2.75 bar) Flowrate Capacity ≥...
Page 99 NBC™ Flat Belt - IOM M12 Sensor Connection used with WTR style sensors The M12 Sensor Connection module differs from the standard module in that it does not have the sensor hard wired to the module. Instead, a cable with female M12 connector will be provided for connection with standard sensors (i.e.
Page 100: Power Supply
NBC™ Flat Belt - IOM 1.45: P OWER UPPLY A variant of the CRUZcontrol power supply shall be developed with 2x2 connectivity and be UL Listed as Class II. Two input power options will be available: 115/230 VAC, single-phase •...
Page 101 NBC™ Flat Belt - IOM Figure 27: Logic Interrupt Wiring Figure 28: Slug Interrupt Wiring P/N: 1118140 Rev: 07/29/2020 Page 101 of 129...
Page 102 NBC™ Flat Belt - IOM Conveyor Power Supply TGW’s power supplies feature a compact housing design that is designed specifically for use with CRUZcontrol logic modules. These units meet the latest NEC Class II requirements in accordance with UL, EN, IEC standards.
Page 103 NBC™ Flat Belt - IOM Figure 30: TGW P/N 1117432 Connection Diagrams Figure 31: TGW P/N 1117431 Dimensional Diagram Figure 32: TGW P/N 1117431 Connection Diagram P/N: 1118140 Rev: 07/29/2020 Page 103 of 129...
Page 104 NBC™ Flat Belt - IOM Power Supply Technical Data Technical Data PN 1117431 PN 1117432 Input Parameters Input Voltage Range V AC (nominal) 100…120/220…240 V 380…480 V (2 phase) Input Voltage Range V AC (continuous) 85…132/184…264 V 323…552 V (2 phase) Input Frequency 47…63 Hz...
Page 105 NBC™ Flat Belt - IOM Part Number Listing Table 18: Logic Module w/Sensor and 2x2 Daisychain TGW Part # Description 1114947 Basic/Progressive, AtoB 1116736 Sensor/Valve Assembly, N.O. Valve 1116737 Basic/Progressive, AtoB, M12 Sensor Connection Table 19: Accessories w/2x2 Connections TGW Part #...
Page 106 NBC™ Flat Belt - IOM Table 20: Logic Module w/MHL1 Sensor and M12 Daisychain for CRUZcontrol TGW Part Description E0001900A Basic, AtoB E0001901A Basic, AtoD E0001904A Progressive, AtoB E0001905A Progressive, AtoD E0005546 Basic, No Valve E0006229 Sensor/Valve Assembly, N.O. Valve...
Page 107: Chapter 16: Nbc Maintenance & Troubleshooting
NBC™ Flat Belt - IOM NBC M & T AINTENANCE ROUBLESHOOTING 1.46: G ENERAL REVENTIVE AINTENANCE Periodic maintenance intervals shown may vary with load, speed, hours of daily operation, ambient temperature, humidity, etc. Intervals can be established by fairly frequent maintenance at first; then lengthen the intervals as justified by observation of need based on history.
Page 108 Never re-weld over old belt splice. This makes the belt splice weak and brittle. Gearmotors • NBC drive units use gearmotors which are properly filled at the factory with sufficient lubrication for their mounting position. • A synthetic lube is the standard lube supplied. Refer to manufacture for details.
Page 109 NBC™ Flat Belt - IOM Disassembly/assembly procedure as follows 1. Remove necessary guards to access maintenance areas. 2. Disconnect any electrical connection. 3. Remove gearmotor. 4. Perform required maintenance. 5. Reverse procedures for assembly. 6. Replace all guards. Regularly inspect all gearmotors to guarantee maximum performance.
Page 110 NBC™ Flat Belt - IOM Sensing Switches Sensing switches are of two types: • retroreflective photoeye • proximity switch Adjust the retroreflective type as follows 1. Determine what sizes of target the photoeye must sense 2. Adjust for the worst case, usually smallest item, by loosening photoeye mounting nut and aligning while making sure photoeye has unobstructed view of reflector.
Page 111: Troubleshooting Guide - Mechanical /Electrical
NBC™ Flat Belt - IOM 1.47: T – M ROUBLESHOOTING UIDE ECHANICAL LECTRICAL Mechanical Possible Cause Remedy Problem Rollers not turning Check alignment of pressure pan consistently Poor bottom on Improve product convey ability product Overloading of Remove overload product Insufficient drive Check air pressure on take up assembly.
Page 112 NBC™ Flat Belt - IOM Mechanical Possible Cause Remedy Problem Only the brown and blue wires of the T-cable are Improper wiring of used to connect with the Power Supply. If the white T-cable to power and black wires connect in any way… the logic is...
Page 113: Chapter 17: Nbc Replacement Parts Identification
(2) weeks after the order is received. It includes part numbers, description, pricing and recommended quantities to be kept on hand for maintenance. If you are unable to locate this document, another may be obtained by contacting the TGW Lifetime Services at 231-798-4547.
Page 114: Nbc Drive Ssembly
NBC™ Flat Belt - IOM 1.49: NBC D RIVE SSEMBLY NBC 500-AT Drive Assembly Replacement Parts - NBC 500-AT Drive Assembly REPLACEMENT PARTS - NBC 500 LB AT DRIVE DR-ASY,NBC-28BF-500AT-LH Width & Item # Balloon Description 16 BF 22 BF...
Page 115 NBC™ Flat Belt - IOM NBC 250-AT30 Drive Assembly Replacement Parts - NBC 250-AT30 Drive Assembly REPLACEMENT PARTS - NBC 250-AT30 Width & Item # DR-ASY,NBC-_ _BF-250AT30-LH or RH Balloon Description 16 BF 22 BF 28 BF 34 BF PULLEY,ASY 6"DIA W/FLANGE E0002214 E0002214 E0002214 E0002214 CYL,AIR CLIPPARD 2-1/2"BX16"S...
Page 116: Nbc Air Take -U P
NBC™ Flat Belt - IOM 1.50: NBC A NBC 500-AT Air Take-Up Replacement Parts - NBC 500-AT Air Take-Up DRIVE ASSEMBLY - NBC 500-AT Air Take-UP DR-ASY,NBC-28BF-500AT-LH Width & Item # Balloon Description 16 BF 22 BF 28 BF 34 BF CYL,CABLE 2.5"B X 28S MOD...
Page 117 1118030 1118030 1118030 LABEL,NBC DRIVE 250 BELT PATH RH 1118031 1118031 1118031 1118031 ASY,SLEEVE VALVE NBC 3/8" IN - 1/4" OUT W/90 ELBOW 1168369 1168369 1168369 1168369 TUBING,1/4"POLYU-95DURO.160ID FREELIN WADE #1B-151-10 E0005539 E0005539 E0005539 E0005539 DWG 165S259 A P/N: 1118140...
Page 118: Nbc Drive Rain
1" 1117690 1117655 SK372.1/90LP 1120871 1" 1214999 1214992 SK572.1/100LP 1191846 1-1/4" NOTE: TOTAL BELT PULL FOR NBC UNIT NOT TO EXCEED 500LBS. 1-HP, 1-1/2-HP, 2-HP, AND 3-HP @ PE. Ref DWG# 165S007 P/N: 1118140 Rev: 07/29/2020 Page 118 of 129...
Page 119 1117798 1 1/2 SK372.1/90SP 1120871 1" 1117783 1117799 SK372.1/90LP 1120871 1" NOTE: TOTAL BELT PULL FOR NBC UNIT NOT TO EXCEED 250LBS. 1-HP, 1-1/2-HP, AND 2-HP @ PE. Ref DWG # 165S008 P/N: 1118140 Rev: 07/29/2020 Page 119 of 129...
Page 120: Nbc Pressure Assembly
NBC™ Flat Belt - IOM 1.52: NBC P RESSURE SSEMBLY Replacement Parts - NBC Pressure Pans Assembly REPLACEMENT PARTS - NBC PRESSURE PAN ASSEMBLY Width & Item # PAN,PRS ASY 3IN-48Z AC NBC Balloon Description 16 BF 22 BF 28 BF...
Page 121: Nbc Skewed Ressure An Ssembly
(LH bed, RH skew shown) Replacement Parts - NBC Skewed Pressure Pan Assembly REPLACEMENT PARTS - NBC SKEWED PRESSURE PAN ASSEMBLY Width & Item # PAN,PRS ASY 2.25CH-48Z AC NBC LH BED, RH SKEW Balloon Description 16 BF 22 BF...
Page 122: Nbc Discharge Rake Ssembly
NBC™ Flat Belt - IOM 1.54: NBC D ISCHARGE RAKE SSEMBLY Replacement Parts - NBC Brake Assembly REPLACEMENT PARTS - NBC BRAKE ASSEMBLY KIT,NBC-_ _BF-3RC OR 2RC-CTD RLR-BRAKE Width & Item # Balloon Description 16 BF 22 BF 28 BF...
Page 123: Nbc End Pulley Assembly
NBC™ Flat Belt - IOM 1.55: NBC E ULLEY SSEMBLY (Charge / Discharge) Replacement Parts- NBC Terminal Pulley REPLACEMENT PARTS - NBC TERMINAL PULLEY Width & Item # ASY,TERMINAL PULLEY NBC Balloon Description 16 BF 22 BF 28 BF 34 BF PULLEY,ASY 6"DIA FLAT FACE...
Page 124: Nbc
BED,NBC-_ _BF-C48-IN-CZ-2rc OR 3RC-LH/RH Width & Item # Balloon Description 16 BF 22 BF 28 BF 34 BF ---- HARNESS,ASY NBC 48" 3 ZONE LH ATB ---- ---- ---- ---- 04/01 LM,ASY AIR TO BRAKE W/PE BRKT & HDWE 1115898 1115898...
Page 125: Nbc Logic Module Component
NBC™ Flat Belt - IOM 1.57: NBC L OGIC ODULE OMPONENT Air to brake logic module - Straight Beds P/N: 1118140 Rev: 07/29/2020 Page 125 of 129...
Page 126: Nbc
1.58: NBC 12 ONTACT CCUMULATION KEWED OLLERS (LH Bed with RH Skew shown) Replacement Parts - NBC 12ft Contact Accumulation Skewed Rollers Replacement Part Numbers for NBC Contact Accumulation Skewed Rollers (LH Bed with RH Skew Shown) BALLOON ROLLERS 16BF...
Page 127: A S R
1.59: NBC 12 ONTACT CCUMULATION KEWED OLLERS (RH Bed with RH Skew shown) Replacement Parts - NBC 12ft Contact Accumulation Skewed Rollers Replacement Part Numbers for NBC Contact Accumulation Skewed Rollers (RH Bed with RH Skew Shown) BALLOON ROLLERS 16BF 22BF...
Page 128: Tgw General Information
NBC™ Flat Belt - IOM TGW G ENERAL NFORMATION TGW Website Link: www.tgw-conveyor.com TGW Maintenance Videos: https://www.tgw-conveyor.com/media-center/maintenance-videos TGW Product Videos: https://www.tgw-conveyor.com/media-center/video-gallery Application and Control Guidelines: https://www.tgw-conveyor.com/support/application-control-guidelines Support & Connections: https://www.tgw-conveyor.com/support/iom-manuals/supports-and-connections TGW IOM Manuals: https://www.tgw-conveyor.com/support/iom-manuals Brochures: https://www.tgw-conveyor.com/support/brochures After Hours, Contact Information: https://tgw-conveyor.com/tgw/guaranteed-product-performance...
Page 129: Tgw Systems Information
TGW SYSTEMS INFORMATION Mission TGW Systems, located in Norton Shores, Michigan, is a leading deliverer of “smart” material handling systems, technologies, products, and services, creating solutions for material flow applications. As a global supplier of conveyor systems and equipment since 1964, TGW Systems provides sorters, conveyors, and accessories to satisfy a broad spectrum of accumulation, transportation, and sortation applications.

TGW NBC Installation, Operation & Maintenance Manual

Chapter 1: Iom Introduction

Chapter 2: Tgw Systems Policies

Chapter 3: Nbc Introduction

Chapter 4: Nbc Receiving and Site Preparation

Chapter 5: Nbc Installation Details

Chapter 6: Gear Motor Activation

Chapter 7: Nbc, Nitta Belt Welding Instructions

Chapter 8: Threading the Belt

Chapter 9: Nbc Air Take-Up

Chapter 10: Nbc Skewing Nbc Rollers

Chapter 11: Nbc Air Supply Requirements

Chapter 12: Nbc Logic Module Concepts

Chapter 13: Nbc Power Supply Requirements

Chapter 14: Cruzcontrol on Site Installation

Chapter 15: Conveyor Flow

Chapter 16: Nbc Maintenance & Troubleshooting

Chapter 17: Nbc Replacement Parts Identification

Tgw General Information

Tgw Systems Information

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for TGW NBC

Summary of Contents for TGW NBC

Table of Contents
