LOGIC AND MEANINGS

1. Connection with the stove (serial cable)
2. Power input
3. Configuration reset button
4. Green LED - Power
5. Blue LED - Access point
6. Orange LED - Station
7. Orange LED - Cloud
EU DECLARATION
The manufacturer MICRONOVA s.r.l. declares that the following type of radio equipment NAVEL 2.0 complies with the following
directives:
RED 201BNTmcr814/53/EU; ROHS 2011/65/EC; WEEE 2012/19/EU
The complete text of the declaration is available at the following address:
https://www.micronovasrl.com/wp-content/uploads/2016/02/T009_datasheet-PT009_XX.pdf
* The support power supply (as a sample supplied in the kit) must comply with the EN 60950-1 directive and
have the following characteristics:
• SELV Safety Extra-low voltage;
• protected against short circuits and overcurrents;
• Low power source LPS;
16 ENGLISH
