Electro-Harmonix 22500 Quick Start Manual

22500 FOOT CONTROLLER
Remote Foot Controller for 22500 Dual Stereo Looper
Thank you for purchasing the Electro-Harmonix 22500 FOOT CONTROLLER! The
22500 Foot Controller is a wired remote control for the 22500 Dual Stereo Looper
giving your feet the ability to increment or decrement through the Loop Banks.
The 22500 Looper records and plays in up to 100 Loop Banks per SDHC card. The
Foot Controller makes it easy for your feet to navigate through the 22500's 100
Loop Banks, moving up or down by either 1 or 10 banks at a time.

-CONNECTIONS -

Connect the 22500 Foot Controller (22500 FC) to your 22500 main unit using a
standard 1/4" mono instrument cable. Plug one end of the cable into the jack
labeled FC on the 22500 Looper. The other end of the cable should be inserted into
the 22500 FC's jack at the top of the unit. The Foot Controller is now ready for use.

- FOOTSWITCHES -

LOOP UP/DOWN Footswitches – Press and release the LOOP UP footswitch to
increment the Loop Bank number by 1 on the 22500 main unit. Press and release
the LOOP DOWN footswitch to decrement the Loop Bank number by 1.
Press and hold either footswitch for 1 second or longer to continuously jump up or
down by ten banks at a time. Release the FSW when you get to the Loop Bank
decade you need. It may be helpful to have Bank displayed on the 22500 main unit
while changing banks with the 22500 FC.
The Loop Bank can be changed when the 22500 is either idle (stopped) or playing
back loops. If Loop A, B, or a Rhythm loop are playing at the time you change Loop
Banks, all of the loops stop play upon changing banks.
The 22500 FC footswitch presses are ignored if you press either footswitch while
recording or overdubbing on the 22500.
