DCP
Digital Communication Platform
Installation Guide
Ref No MC-xCM10 850 ML Version 4
Part numbers:
2G (RS232): MC-2CM10-100-F-20-000
3G (RS232): MC-3CM10-100-F-20-000
PRODUCT DESCRIPTION
The Digital Communications Platform (DCP) provides an information gateway between
all compatible connected Avire devices in the lift shaft and our online monitoring
platform the Avire Hub. The product is installed as a stand-alone device and doesn't
require connection to the controller panel.
In the Box
+
2G or 3G DCP
+
Antenna
+
P-5 H-2V connector (x1)
+
P-3.5 H-4V connector (x1)
+
P-10 H-2V connector (x1)
+
Grey clamp (x2)
+
Manual
2G (RS422/ 485): MC-2CM10-100-F-40-000
3G (RS422/ 485): MC-3CM10-100-F-40-000
Not Included
+
Screwdriver
+
SIM card
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Memco MC-2CM10-100-F-20-000
Summary of Contents for Memco MC-2CM10-100-F-20-000
- Page 1 Digital Communication Platform Installation Guide Ref No MC-xCM10 850 ML Version 4 Part numbers: 2G (RS422/ 485): MC-2CM10-100-F-40-000 2G (RS232): MC-2CM10-100-F-20-000 3G (RS232): MC-3CM10-100-F-20-000 3G (RS422/ 485): MC-3CM10-100-F-40-000 PRODUCT DESCRIPTION The Digital Communications Platform (DCP) provides an information gateway between all compatible connected Avire devices in the lift shaft and our online monitoring platform the Avire Hub.
- Page 2 ELEVATOR SAFETY Please follow all Health and Safety rules & take all necessary precautions before and during installation. SETTING UP THE DCP Avire SIM cards come activated and ready to be installed. If a non-Avire SIM card is used, please make sure that the SIM card is activated and unlocked. Open the DCP with a PZ1 screwdriver.
- Page 3 LEDs on the front of the DCP unit will show the network signal level Note: The signal scanner will indicate the best location for the device to receive signal, Network coverage will vary based on local conditions. Once finished turn SW1 dipswitch 1 back to OFF. You can check the status of the power supply, battery, connection, coverage or Phone Line (SLIC)
- Page 4 Clamp the power cable using the grey clamp provided inside the box. Place the lid back on the top of the DCP and fasten the lid with the screw. Turn on the power to the DCP. The RUN LED on the DCP should change colour from flashing amber to flashing green when the mains power connection is made.
- Page 5 SIM CARD UNLOCKING Important Note: An Avire SIM card doesn’t have a SIM PIN code; if the SIM LED is flashing red, please make sure that the SIM card has been inserted correctly. The SIM PIN code for other network providers may vary and it can usually be found on the outer plastic case of the SIM card.
- Page 6 SETTING PARAMETERS ON NON AVIRE SIMS OPTION 1 Super settings allow quick and easy configuration of APN settings, depending on the country and network provider. Configure settings for the DCP based on the tables below. Example: Digit 1 Digit 2 Digit 3 Country SIM Network...
- Page 7 OPTION 2 If super settings are not used, then APN settings need to be set up manually: Command Description P060 (P zero six zero) APN address P061 (P zero six one) APN username P062 (P zero six two) APN password P063 (P zero six three) Type of connection These parameters must be configured by sending an SMS to the SIM card number.
- Page 8 Obtaining the CCID number AVIRE SIM CARDS Avire SIM cards come unlocked to be used with our products immediately after plugging them in and setting correct Super settings. You will need to know the CCID number to add this information to the Avire Hub.
- Page 9 AVIRE HUB Please contact your local sales office for access to the Avire Hub. The link to the Avire Hub is http:/ /avirehub.avire-global.com To view installation tutorial videos please go to the “Help” section of the Avire Hub. Click on “Installations” in the menu on the side and then on “Buildings”.
- Page 10 On the other side of the page please enter the number of elevator group you have in this installation and how many elevators you have in the group. As an example, if this is a simplex installation the number of elevator groups will be “1” and the number of elevators will also be “1”.
- Page 11 Click “Save” in the left corner under the General data column. To make sure that everything has been set up correctly click on the green DCP button. The buttons “Access” and “Events” should now be accessible. Click on the “Access” button. Please click on the “Read Parameters”...
- Page 12 ADDITIONAL INFORMATION FOR PROGRAMMING THE DCP SMS COMMANDS All DCP parameters can be remotely configured via SMS sent to the SIM card’s number. Each SMS message should begin with ‘Pin1234’ which is the access code to read or make any changes to the configuration of the DCP.
-
Page 13: Connector Description
Connector Description Description External antenna Battery To access dipswitches and connectors, Power Supply open the DCP case by unfastening the CANBus front screw (using a PZ1 screwdriver) and removing the lid. J9/ J1A Phone line Serial connector Programmable I/O J2 - External antenna - Connect the external antenna delivered with the kit to the J2 connector. - Page 14 J10 CONNECTOR - RS-232 or 422/485 Serial Connector The J10 connector is a standard serial communication port that allows the connection of computers, controls or any other device that needs remote communication through a reliable wireless data channel. The connectivity provided by the port is in real time and acts as a point to point transmitter.
- Page 15 LED INDICATORS The DCP has five indicator LEDs that constantly report the device status. The indicators will be either red, amber or green. Each indicator will be fully on, fully off or flashing. On start-up, you should see the following within 60 seconds: RUN LED flashes in green.
- Page 16 System Architectures Triphony Unit Universal Power PIT Phone Display Digital Audio Unit Induction Loop CAN Bus Splitter Lift car system architecture with DCP, DAU, TOC Triphony Unit, Inductive Loop...
- Page 17 Two lift car system architecture with DCP, Two lift cars with DCP, UPS, CANBus Splitter, DAU, TOC and BOC Triphony Units TOC Triphony Unit, DAU, PIT Phone. Four lift cars with DCP, UPS, CANBus Splitters, DAU, Triphony Units TOC, PIT Phones Note: UPS battery back up only uses H and L wires from DCP...
- Page 18 Installation with a Digital Audio Unit When connecting a Digital Audio Unit (DAU) connect the unit or the CAN Bus Splitter to J8 using a 4-core cable (2 wires for power and 2 for communication) If only connecting 1 device to the DCP (e.g. DAU) set SW1 dipswitch 4 to ON It is recommended to use shielded twisted pair cables If connecting 2 devices to the DCP (e.g.
- Page 19 Installation with a Memcom When connecting a Memcom+ use the analogue phone line connection from J1A or J9. Please refer to the Memcom+ installation guide for full set up of the Memcom+. Connection on Memcom+ Connections on DCP J9 GSM phone J9 GSM line IN...
-
Page 20: Installation
The wiring insulation must comply with the applicable IEC 60332 or IEC 60695/11/21 standards. Avire Trading Ltd Unit 1, The Switchback 01628 540100 Gardner Road 01628 621 947 Maidenhead sales.uk@avire-global.com Memco is a brand of Avire Berkshire www.avire-global.com SL6 7RJ, UK...
