- Page 1 ASSEMBLY & OPERATING INSTRUCTIONS Semi-Electric Forklift HSE1000/3 Read and observe the operating instructions and warnings before using the truck...
-
Page 2: Table Of Contents
CONTENT GENERAL Preface Structural Data Form Safety Guidance Maintenance How to charge storage battery Control Panel Troubles Shooting PART LIST Part 1 6 – 7 8 – 9 Part 2 +44(0)20 - 78 94 15 16 info @ topregal.com www.topregal.com... -
Page 3: General
GENERAL PREFACE Congratulations on the purchase of your new HSE1000/3 semi-electric forklift truck, this easy to use truck is made of high quality materials, specially designed for long lasting and reliable operation. For your own safety and for the correct operation of the truck, please read and follow these operating instructions before using the truck. -
Page 4: Maintenance
GENERAL MAINTENANCE Hydraulic oil Please check the oil level every six months. The oil can be hydraulic oil: ISO VG32, its viscosity should be 32cSt at 40oC, total volume is about 4.0lt. Daily check and maintenance Check the truck daily before use, paying particular attention to the wheels and axles. Foreign objects such as cloths/cloths, etc. -
Page 5: Troubles Shooting
GENERAL TROUBLES SHOOTING Trouble Clause Fixing Methods • The hydraulic oil is not sufficient. • Fill up with oil. The forks cannot be lifted to the maximum height. • No hydraulic oil. • Fill up with oil. The forks cannot be lifted. (engine running) •... - Page 6 PARTS LIST PART 1 +44(0)20 - 78 94 15 16 info @ topregal.com www.topregal.com...
- Page 7 PARTS LIST Code No. Name Qty. SPN10.0-6 Protective cover splint GB/T 818-2000 Cross recess pan head screw M6× 20 SPN10.0-4B Protective cover SPN10.0-4C Protective cover SPN10.9-2 Electrical cover GB/T 96.2-2002 Large (big) plain washer ø 6 GB 2674-86 Allen cup head screws M10×...
- Page 8 PARTS LIST PART 2 +44(0)20 - 78 94 15 16 info @ topregal.com www.topregal.com...
- Page 9 PARTS LIST Code No. Name Qty. SPN10.0-2 Oil cylinder hoop SPN10.7-3 Stent PN10.7-1 Nylon guide wheel SPN10.7-2 Pin roll GB/T 70.1-2000 Hexagon socket cap screws M8× 16 SPN10.8-6 Oil connection GB/T 70.1-2000 Hexagon socket cap screws M10× 25 GB/T 97.1-2002 Flat washer ø...
- Page 10 TOPREGALL GmbH, Industriestrasse 3, 70794 Filderstadt, Germany Telephone +44(0)20 - 78 94 15 16 Email info @ topregal.com, Website www.topregal.com...
