Model
Battery pack 18 V 2.5 Ah
Battery pack 36 V 2.5 Ah
Download the latest version of this document at
http://www.desouttertools.com/info/6159929680_EN
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
Li-ion Battery Pack 2.5 Ah
Product Instructions
Part number
6158132660
6158132670
WARNING
Printed Matter No. 6159929680_EN
Issue No.
01
Date
11/2020
Page
1 / 12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Desoutter 6158132660
Summary of Contents for Desoutter 6158132660
- Page 1 1 / 12 Li-ion Battery Pack 2.5 Ah Product Instructions Model Part number Battery pack 18 V 2.5 Ah 6158132660 Battery pack 36 V 2.5 Ah 6158132670 Download the latest version of this document at http://www.desouttertools.com/info/6159929680_EN WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Table of Contents Product Information .......................... 3 General Information......................... 3 Warranty.......................... 3 Website .......................... 3 Information about spare parts .................... 3 Battery pack 18 V - dimensions ................... 3 Battery pack 36 V - dimensions ................... 4 Overview ............................ 4 Description ........................... 4 Technical data........................ 4 Accessories.......................... 5 Operation.............................. 6 Operating Instructions ........................ 6 How to use the battery pack.................... 6 How to get more information with CVIMONITOR.............. 7 Automatic switch to Deep sleep mode ................. 7... -
Page 3: Product Information
• Warranty repairs are only performed in Desoutter workshops or by Certified Service Partners. Damage to the bat- tery pack that occurs as a result of maintenance performed by parties other than Desoutter or its Certified Service Partners during the warranty period is not covered by the warranty. -
Page 4: Battery Pack 36 V - Dimensions
4.61 2.99 Overview Description Latch Gauge level Initial start recommendations Technical data Weight Part number 6158132660 0.460 1.01 6158132670 0.770 1.70 Storage and use conditions Charging temperature 0 to +45 °C (32 to +113 F) Storage temperature -20 to +60 °C (-4 to +140 F) Operating temperature 0 to +60 °C (32 to +140 F) -
Page 5: Accessories
Product Information Indoor use only Charging time 85 minutes Accessories Required accessories Battery pack charger 6158132700 Optional accessories eDOCK with battery DATA interface 6158134000 11/2020 5 / 12... -
Page 6: Operation
Operation Operation Operating Instructions How to use the battery pack NOTICE Usage recommendations for battery packs Ensure a longer service life of the battery pack. Unplug the battery pack when the tool is not used. ► Do not leave the battery pack on the charger when the charger power supply is off. WARNING Only use or store the battery pack in an ambient temperature interval stated in chapter Technical data. -
Page 7: How To Get More Information With Cvimonitor
Operation How to get more information with CVIMONITOR Connect the eDOCK kit DATA interface to the battery pack and launch CVIMONITOR. Refer to the Product Instructions (printed matter: 6159929690) available at https://www.desouttertools.com/resource- centre to get more information. Automatic switch to Deep sleep mode The battery pack switches automatically to Deep sleep mode when a timer of 5 days has elapsed. -
Page 8: Service
Service Service Maintenance Instructions Maintenance instructions WARNING Only use or store the battery pack in an ambient temperature interval stated in chapter Technical data. Do not modify or attempt to repair the battery pack. For safety reasons, the battery pack should be serviced only by the manufacturer or authorized service providers. How to store the battery pack Respect the storage temperature given in chapter Technical data [Page 4]. -
Page 9: Trouble-Shooting
Trouble-shooting Trouble-shooting Description Solution The battery pack is not operational: Plug the battery pack to the battery pack charger. - no LED display when pressing the gauge button - no power when connected to a tool The temperature protection has been activated. Let the battery pack cool down. - Page 12 Original instructions Founded in 1914 and headquartered in France, Desoutter Industrial Tools is a global leader in electric and pneumatic assembly tools serving a wide range of assembly and manufacturing operations, including Aerospace, Automotive, Light and Heavy Vehicles, Off-Road, General Industry.
