- Page 1 INSTALLATION MANUAL FRAME SCREEN LEONARDO ORIGINAL INSTRUCTIONS IN ITALIAN LANGUAGE Translation into English language This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 2 Contents and map of this manual Warnings Warranty - General information Screen labels FRAME SCREEN DESCRIPTION General description ASSEMBLY 3.1a Leonardo with Oyster surfaces packaging content 3.1b Leonardo with Pvc surfaces packaging content Structural frame assembly Projection cloth mounting 3.3a Oyster surface mounting 3.3b...
-
Page 3: General Information
Installation manual 1.0 GENERAL INFORMATION FRAME SCREEN DESCRIPTION The frame screen LEONARDO is entirely manufactured in Italy, with high quality materials and projection cloths that guarantee to your system excellent quality performances in compliance with CE legislation. The screen is designed specifically for home cinema or professional projections. - Page 4 Mod. LEONARDO Installation manual WARNINGS Before assembling and installing the frame screen read carefully the installation manual. Please, store this installation manual so that you can consult it whenever necessary. When opening the screen packaging, USE VERY CAREFULLY EVENTUAL CUTTERS OR SHARP TOOLS that can damage its content. It is recommended to wear working gloves during the opening of the packaging and the installation of the product.
- Page 5 Mod. LEONARDO Installation manual SCREEN LABELS This screen is equipped with product identification labels that indicate its essential technical specifications. 1.6.1 Label n. 01 1.6.2 Label position This label reports the following Looking at the screen from the information: front it. The label is sticked on...
-
Page 6: General Description
Mod. LEONARDO Installation manual FRAME SCREEN DESCRIPTION GENERAL DESCRIPTION The figures below describe the main elements of the product. Front view Velvet covered bezel Projection surface Rear view Bezel Mounting brackets Structural frame This document is property of Euroscreen Srl. - Page 7 Mod. LEONARDO Installation manual Profiles combination Bezel covered with velvet Bezel aluminium profile Structural frame aluminium profile Projection cloth Mounting bracket This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 8 Mod. LEONARDO Installation manual ASSEMBLY LEONARDO WITH OYSTER SURFACE 3.1a PACKAGING CONTENT: Structural frame segments (A) Bezel segments (B) Pcs. 04 Pcs. 04 Metal corners (C) Projection surface (D) Pcs. 16 Pcs. 01 Rubber bands (E) Projection cloth Pcs. 01 Screws + wall plugs (G) Pcs.
- Page 9 Mod. LEONARDO Installation manual LEONARDO WITH PVC SURFACES 3.1b PACKAGING CONTENT: Pvc surfaces: White, HD Performer, Microperforated, Lumi Grey Microperforated, Lumi Grey Structural frame segments (A) Bezel segments (B) Pcs. 04 Pcs. 04 Metal corners (C) Projection surface (D) Pcs. 16 Pcs.
- Page 10 Mod. LEONARDO Installation manual STRUCTURAL FRAME ASSEMBLY The first step of Leonardo screen installation consists in assembling the structural frame. The slots to be used to insert the metal corners (C) are n. 1 and n. 3 as shown in the drawing on the right. Do not use slot n.
- Page 11 Mod. LEONARDO Installation manual Step 2a Put the short structural frame segments (A) close to the metal corners (C). Step 2b Insert the short structural frame segments (A). This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 12 Mod. LEONARDO Installation manual Step 3a Place the remaining metal corners (C) close to the remaining long structural frame seg- ment. Step 3b Insert the metal corners (C) to this frame segment. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 13 Mod. LEONARDO Installation manual Step 4a Insert the long structural frame segment, in order to complete mounting of the frame. Step 4b Before tightening all the dowels, in order to perfectly close the metal corners to the structural frame segments, check that the measurements L1 and L2 are the same. The maximum tolerance is 2 mm.
- Page 14 Mod. LEONARDO Installation manual For a perfect assembly, it is necessary to check carefully the fixing of the metal corners (C), because, as shown in the figures below, mistakes will compromise the whole installation, causing permanent damages to the cloth.
- Page 15 Mod. LEONARDO Installation manual PROJECTION SURFACE MOUNTING 3.3a OYSTER SURFACE MOUNTING Before fixing the cloth, make sure to have enough moving space for all the operations, as indicated by the figure below. Before laying the projection cloth down, make sure that the floor where you will lay is perfectly clean and smooth.
- Page 16 Mod. LEONARDO Installation manual After laying the protective cloth, make sure that the projection cloth is not damaged. Moreover, it is advised to leave the cloth layed down for at least 10 minutes, before proceeding with fixing it to the pre-assembled structural frame, as per chapter 3.2.
- Page 17 Mod. LEONARDO Installation manual For an easy installation of the projection cloth to the structural frame, this frame has to be centered in the most precise way, pairing the green centre indicators applied on the cloth and the fixed centre indicator.
- Page 18 Mod. LEONARDO Installation manual Proceed now with fixing the screen to the structural frame. The drawings below describe how to fix the rubber bands. This operation has to be carried out by at least two professional people, taking care that the Oyster surface is very delicate and any damage on it will be permanent.
- Page 19 Mod. LEONARDO Installation manual IMPORTANT: The sequence for fixing the rubber bands is shown below. The first rubber bands that have to be fixed are those necessary for centring the cloth. It is important that fixing is carried simultaneously starting from the opposite sides because this defines the exact central position of the cloth.
- Page 20 Mod. LEONARDO Installation manual After having fixed the cloth to the structural frame, lift the screen in vertical position, as shown by the figure below and check that there are not waves or folds on the projection cloth. If there are waves it is enough to detach and fix again the rubber bands.
- Page 21 Mod. LEONARDO Installation manual PVC SURFACES MOUNTING 3.3 b Before fixing the cloth, make sure to have enough moving space for all the operations, as indicated by the figure below. Before laying the projection cloth down, make sure that the floor where you will lay is perfectly clean and smooth. It is mandatory to lay a protective equipment cloth over the floor, before laying on it the projection cloth.
- Page 22 Mod. LEONARDO Installation manual After laying the protective cloth, make sure that the projection cloth is not damaged. Moreover, it is advised to leave the cloth layed down for at least 10 minutes, before proceeding with fixing it to the pre-assembled structural frame, as per chapter 3.2.
- Page 23 Mod. LEONARDO Installation manual For an easy installation of the projection cloth to the structural frame, this frame has to be centered in the most precise way, pairing the green centre indicators applied on the cloth and the fixed centre indicator.
- Page 24 Mod. LEONARDO Installation manual Proceed now with fixing the screen to the structural frame. The drawings below describe how to fix the rubber bands. This operation has to be carried out by at least two professional people, taking care that the Oyster surface is very delicate and any damage on it will be permanent.
- Page 25 Mod. LEONARDO Installation manual IMPORTANT: The sequence for fixing the rubber bands is shown below. The first rubber bands that have to be fixed are those necessary for centring the cloth. It is important that fixing is carried simultaneously starting from the opposite sides because this defines the exact central position of the cloth.
- Page 26 Mod. LEONARDO Installation manual After having fixed the cloth to the structural frame, lift the screen in vertical position, as shown by the figure below and check that there are not waves or folds on the projection cloth. If there are waves it is enough to detach and fix again the rubber bands.
- Page 27 Mod. LEONARDO Installation manual THIN BEZEL ASSEMBLY Before proceding with mounting the bezel segment (B), loosen the pre-mounted dowels on the structural profile, in order to assemble easily the structural frame to the bezel segments. Depending on the size of the screen, the dowels will always be on the extremities and in the centre of the profile at the distances shown in the figure below.
- Page 28 Mod. LEONARDO Installation manual At this point, proceed with fixing the bezel segments. Take the frame profile rods with the same number and move them close to the structural profile and insert them. To insert them, lift gently the affected side.
- Page 29 Mod. LEONARDO Installation manual Once the short bezel segments are placed and fixed, proceed with taking the bezel long segments and prepare the metal corners (C) to be fixed. Insert the metal corners without tightening them, making sure that the dowel is loose and but not completely unscrewed.
- Page 30 Mod. LEONARDO Installation manual Insert the metal corners carefully to the short sides and place the long bezel profiles close. At this point, screw tightly the dowels. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
-
Page 31: Installation
Mod. LEONARDO Installation manual INSTALLATION WALL MOUNTING The mounting brackets position is shown in the figures below. The mounting brackets are already fixed to the structural profile, in order to ease the installation. Front view Rear view This document is property of Euroscreen Srl. - Page 32 Mod. LEONARDO Installation manual Mounting brackets details. ø6 ø18 This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
