NUUO SCB-C08 Installation Manual

Subject:

NUUO IO Installation Guide

Step 1:

Connect between SCB-C08 and SCB-C28.

Step 2:

Install the driver of SCB-C08 in the desktop. Connect between SCB-C08 and

the desktop. (Please refer to "C08_manual_Eng.pdf" in the folder "C08" for

more installation details.)

Step 3:

Open main console. Click Config > Setting > I/O Device.

Converter (C08)

RS485

USB

http://www.nuuo.com

Release Date:

2009.03.25

IO Box

RS485

NUUO

-1-

Rev.: 1.0

Table of Contents

Need help?

Do you have a question about the SCB-C08 and is the answer not in the manual?

Page 1 Rev.: 1.0 Step 1: Connect between SCB-C08 and SCB-C28. Step 2: Install the driver of SCB-C08 in the desktop. Connect between SCB-C08 and the desktop. (Please refer to “C08_manual_Eng.pdf” in the folder “C08” for more installation details.) IO Box Converter (C08)
Page 2 1. Right click on “My computer”, and then click “Manage” > “Computer management” > “Device Manage” > “Ports (COM & LTP)”. 2. The COM port of “Prolific USB-to-Serial Comm Port” is the COM port of this device. NUUO http://www.nuuo.com Copyright © 2009 NUUO Inc.. All rights reserved.
Page 3 1. Right click on the device, and then click “Properties”. Right Click 2. Choose Properties > Port Setting. The value of “Bit per second” is the value of this device’s Baud rate. NUUO http://www.nuuo.com Copyright © 2009 NUUO Inc.. All rights reserved.
Page 4 Step 7: After inserting model name, device model, COM port, and ID, press “Add”. This device will be added into the following list. Step 9 Step 8 Step 10 Step 11 NUUO http://www.nuuo.com Copyright © 2009 NUUO Inc.. All rights reserved.
Page 5 In the “Digital Input Monitor”, the input icon will become red when signal input. Step 11: In the “Digital Output Simulation”, click the icon to send output signal for testing. NUUO http://www.nuuo.com Copyright © 2009 NUUO Inc.. All rights reserved.
