- Page 1 DTC300 Dual-spectrum Accurate Temperature Measurement Camera Quick Start Guide V1.0.0 IRay Technology Co., Ltd.
- Page 2 DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 ©IRay Technology Co., Ltd. 2018 Reserve all the right. All in this manual including texts, pictures, diagrams and other contents belong to IRay Technology Co.,Ltd (Hereinafter referred to as “Our company”or “IRay Photoelectric”). Without the written permission, no one shall copy, photocopy, translate or disseminate all or part of this manual.
-
Page 3: Table Of Contents
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 Content 1. Overview ........................ - 3 - 2. Product Performance ....................- 4 - 3. Installation Guide ....................- 6 - 3.1 Product and Accessory List ........................- 6 - 3.2 Mounting and Connecting Thermal Camera..................... - 6 - 3.3 Site Layout Solution .......................... -
Page 4: Overview
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 1. Overview DTC300 is a dual-spectrum accurate temperature measurement camera, which is developed for the body temperature screening and has the characteristics of non-touch, high sensitivity and flexible installation etc. It can be used for quick temperature detection, and trigger the alarm system when the pedestrian who has abnormal body temperature passes through the orderly channel in public place (such as hospital, enterprise, school, community, mall and supermarkt etc.), with its integrated high... -
Page 5: Product Performance
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 2. Product Performance Table 1 Parameters of Product Model DTC300 Detector Parameters VOx Uncooled Infrared FPA Detector Detector type Resolution 384× 288 17μm Pixel pitch Response spectrum 8～14μm Lens Parameters Focal length 9.7mm... - Page 6 DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 -10℃~50℃ Operating temperature Storage temperature -20℃～+65℃ no condensation Humidity 5~95%， Software Function Face recognition Support intelligent face recognition Secondary development Provide Windows SDK and development manual Note： (1) ．Please refer to GB/T 19665-2005 for the test conditions without BBS ；...
-
Page 7: Installation Guide
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 3. Installation Guide 3.1 Product and Accessory List Before installation, please make sure that the equipment in the package is intact and all parts are available. Standard package DTC camera × 1 Type-C cable × 1 module connection cable ×... -
Page 8: Mounting And Connecting Thermal Camera
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 3.2 Mounting and Connecting Thermal Camera As shown in figure 2, there is a 1/4-20UNC hole at the bottom of camera, which is used to mount camera to a adapter bracket or quick shoe. -
Page 9: Site Layout Solution
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 Plug the three USB interfaces at the other end to the computer which has installed DTS PC client. As shown in figure 5. Figure 5 Connecting diagram of PC After powering on computer, the camera startup automatically with the sound of shutter working. -
Page 10: Site Installation And Layout Considerations
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 Installation direction and height of camera The installation distance and height of the camera should be arranged according to the actual situation, the recommended distance is 2m, and the installation height should ensure that all of the observed pedestrians can appear in the field of view. - Page 11 DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 2）、Select the right monitoring scenario Avoid using infrared cameras in environments with large areas of high temperature objects (such as electronic billboards, large area light boxes, glass walls that are exposed to the sun, etc.).
-
Page 12: Trouble Shooting
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 5 Trouble Shooting General trouble shooting Fault description Possible Causes Method of exclusion Cable connection loosening Check the cable and connector is Startup failure connected well 1、Camera has not get stable; 1. Make sure the camera has started up 2、... -
Page 13: Cleaning And Maintenance
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 problem, use packing materials to pack the equipment and send it to the agent or return it to the manufacturer for treatment. IRay shall not be responsible for any accidental damage in transit caused by materials other than the original packaging. -
Page 14: After Sales Service
DTC300 Accurate Dual-spectrum Temperature Measurement Camera V1.0.0 7. After Sales Service The DTC300 high-precision temperature measuring infrared camera is developed by our company and has good after-sales service guarantee such as equipment maintenance and repair. If you have any needs, please contact our company.
