OPERATING INSTRUCTION MANUAL
STS SERIES | TOPSIDE BOLT TENSIONERS
Hi-Force STS series Topside Bolt Tensioners are designed for topside operation, covering a variety of bolt
tensioning applications. STS series bolt tensioners come in a range of sizes, covering imperial bolts
4" in diameter and metric bolt sizes from M16 to M100. Load Capacities range from 234 kN up to 2649 kN,
with a maximum working pressure on all models of 1500 bar (21,750 psi). Interchangeable accessories
allow load cells to be used on multiple stud sizes. This manual applies to Hi-Force STS series topside bolt
tensioners. It contains the latest product information available at the time of publication and approval. For
information relating to the servicing of a topside bolt tensioner, see the servicing instructions, which are
available on the Hi-Force website. Hi-Force reserves the right to make changes to this document at any
time without notice.
Operating Instruction Manual:
OM-STS-01
1
Serial Numbers:
All
" to
¾
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hi-Force STS Series
Summary of Contents for Hi-Force STS Series
- Page 1 1500 bar (21,750 psi). Interchangeable accessories allow load cells to be used on multiple stud sizes. This manual applies to Hi-Force STS series topside bolt tensioners. It contains the latest product information available at the time of publication and approval. For information relating to the servicing of a topside bolt tensioner, see the servicing instructions, which are available on the Hi-Force website.
-
Page 2: Table Of Contents
Operating Instruction Manual: Serial Numbers: OM-STS-01 Table of Contents 1.0 Inspection upon Receipt ..............3 2.0 Safety Precautions ................3 3.0 Declaration of Incorporation / Conformity ........6 4.0 Component Identification ..............7 5.0 Installation/Setup ................8 6.0 Operation ..................12 7.0 Maintenance and Storage .............. -
Page 3: Inspection Upon Receipt
If in doubt on the correct use of any Hi-Force equipment, contact your nearest Hi-Force office or distributor. Only qualified personnel should be allowed to operate hydraulic equipment. If an operator has not been trained on high-pressure hydraulic equipment and its safe usage, consult your local Hi-Force sales office or distributor who can offer training courses for operators. - Page 4 NEVER attempt to solve, or clean up leaks in the system while the system is pressurised. Immediately replace any worn or damaged parts using genuine Hi-Force parts only. DO NOT remove any labels from the product. Replace any damaged or unreadable labels immediately.
- Page 5 A comprehensive bolting sequence and tensioning / de-tensioning procedure should be prepared and overseen by a trained professional with bolting experience. Hi-Force recommends that the entire tensioning / de-tensioning process be read and fully understood prior to tensioning. ...
-
Page 6: Declaration Of Incorporation / Conformity
3.0 Declaration of Incorporation / Conformity Hi-Force declares that this product has been tested and complies with the standards set out in the relevant EU directives. The EU Declaration of Incorporation / Conformity is included as Annex A to this instruction... -
Page 7: Component Identification
Operating Instruction Manual: Serial Numbers: OM-STS-01 4.0 Component Identification Load Cell Male Coupler Bridge Female Coupler Bridge Window Nut Rotating Socket (Optional) Threaded Puller Tommy Bar (Optional) Piston Dust Caps Figure 4.1: Component Identification... -
Page 8: Installation/Setup
Connection to the hydraulic pump must ALWAYS be made to the male coupler on the tensioner. Hi-Force STS tensioners are fitted with dual quick-connect couplers. Connections between couplers (see figure 5.2) are made by [1] pulling back the spring collar on the female coupler. - Page 9 NOTE: The last tensioner in the system will have an unconnected female coupler. This is correct, and it can be left unconnected. Alternatively, this last coupler can be removed, and a suitable high-pressure blanking plug fitted. (Contact your local Hi-Force office or distributor for further details).
- Page 10 Operating Instruction Manual: Serial Numbers: OM-STS-01 Figure 5.3: Bolt Tensioner Installation...
- Page 11 Operating Instruction Manual: Serial Numbers: OM-STS-01 NOTE: The joint is tensioned in 2 Stages. 50% of the studs are tensioned in the first stage. remaining studs tensioned in the second stage. Figure 5.4: Bolt Tensioner Sequence (50% Coverage) Link hose – maximum working pressure = 1500 bar (21,750 psi) SAFETY NOTE:...
-
Page 12: Operation
OM-STS-01 6.0 Operation Hi-Force STS bolt tensioners are operated by means of a suitable hydraulic pump. Make sure you read this manual in conjunction with the pumps operating instruction manual to ensure correct and safe operation of the hydraulic system. - Page 13 This allows the tensioner to be kept compact, for use in confined spaces. Hi-Force STS tensioners have a maximum stroke indicator in the form of a red band on the piston.
- Page 14 Operating Instruction Manual: Serial Numbers: OM-STS-01 6.4 Setting / Releasing the Nut/s. (Figure 6.2) Once the studs/bolts have been tensioned, and the system pressure is holding stable. Approach the tensioner/s and with a tommy bar, (through the bridge access window) (3) fully tighten the nut/s against the workpiece surface, or loosen the nut/s by rotating them a maximum of 4-flats.
- Page 15 Operating Instruction Manual: Serial Numbers: OM-STS-01 6.6 Removing the tensioner/s. (Figure 6.4) 1. Disconnect all hoses and fit dust caps (not shown) to the couplers. 2. Turn the threaded puller anti-clockwise until it disengages from the threads of the stud [A]. 3.
-
Page 16: Maintenance And Storage
8.1 Oil Specifications Hi-Force cylinders/tools will use 1 of 2 grades of oil, dependant on the pump used. The tools are designed to operate at temperatures between -20°C and 80°C. Details of the oil used can be found in the pumps operating instruction manual, in the section: FILLING OF PUMP WITH OIL. - Page 17 Operating Instruction Manual: Serial Numbers: OM-STS-01 8.2 STS Specifications Refer to the engraved detail on the tensioner for model identification. STS - TOPSIDE BOLT TENSIONERS (METRIC) Bolt Thread Capacity Effective Area Stroke Model Thread Pitch Number (kN) (tonnes) (mm) Size (mm) STS1-M16B1 23.9...
- Page 18 Operating Instruction Manual: Serial Numbers: OM-STS-01 STS - TOPSIDE BOLT TENSIONERS (IMPERIAL) Bolt Capacity Effective Area Stroke Model Threads Thread Number per Inch (kN) (tonnes) (mm) Size ¾” STS1-075B1 23.9 15.6 ⅞” STS1-087B1 23.9 15.6 1” STS1-100B2 23.9 15.6 ⅛ ”...
-
Page 19: Conversion Charts & Tables
Operating Instruction Manual: Serial Numbers: OM-STS-01... - Page 20 Operating Instruction Manual: Serial Numbers: OM-STS-01...
-
Page 21: System Components / Accessories
Operating Instruction Manual: Serial Numbers: OM-STS-01 10.0 System Components / Accessories (Refer to the Hi-Force website or latest Hi-Force catalogue for further details) Tommy Bars for Tensioner Series STS1 - STS6 Optional Bridges for Load Cells STS1, STS3, STS4 & STS6 ... -
Page 22: Troubleshooting
Operating Instruction Manual: Serial Numbers: OM-STS-01 11.0 Troubleshooting Hi-Force STS topside bolt tensioners should be serviced and repaired only by authorised Hi-Force repair centres. The following table gives possible causes and solutions for common problems. TROUBLESHOOTING GUIDE Problem Possible Cause Solution 1. -
Page 23: Contact Details
Operating Instruction Manual: Serial Numbers: OM-STS-01 UK Head Office: Hi-Force Limited Prospect Way, Daventry, Northamptonshire NN11 8PL United Kingdom Tel: + 44 1327 301000 Fax: + 44 1327 706555 Email: daventry@hi-force.com... - Page 24 Baku Milano Azerbaijan Italy Tel: +994 124 474 100 Tel: +39 0257 607 174 Email: baku@hi-force.com Email: italy@hi-force.com Hi-Force Hydraulics (Asia) S.B. Hi-Force Nederland B.V. Selangor Numansdorp Malaysia Netherlands Tel: +603 5525 4203 Tel: +31 85 902 8111 Email: malaysia@hi-force.com Email: holland@hi-force.com...
