INSTRUCTION BOOKLET
GB
GAS COOKER
SIG 224
Please read this instruction booklet before using the appliance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIG 224 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Parkinson Cowan SIG 224

Summary of Contents for Parkinson Cowan SIG 224

  • Page 1 INSTRUCTION BOOKLET GAS COOKER SIG 224 Please read this instruction booklet before using the appliance...

  • Page 2: Important Safety Information

    Important Safety Information You MUST read these warnings carefully before installing or using the appliance. If you need assistance, contact our Customer Care Department on 08705 950950 Installation Child Safety opening it. Service Environmental Information During Use Keep this instruction book for future reference and ensure it is passed on to any new owner.

  • Page 3: Table Of Contents

    Contents For the User For the Installer Important Safety Information Important Safety Requirements Description of the Cooker Installation Control Panel Electrical connections Accessories Commissioning Operation Conversion from Natural to LPG Gas Gas oven Using the Oven Oven Door Protection Device Before the First Use of the Cooker All our appliances comply with the European safety standards.

  • Page 4: Control Panel

    Control Panel GAS OVEN & NORMAL SIMMER NORMAL RAPID ELECTRIC GRILL 1. Electric Ignition push button 2. Oven Light push button 3. Back left burner control knob (rapid) 4. Front left burner control knob (semi-rapid) 5. Front right burner control knob (auxiliary) 6.

  • Page 5: Operation

    Take care when frying food in hot oil or fat, as the overheated splashes could easily ignite. If the control knobs become difficult to turn, please contact your local Parkinson Cowan Service Centre. Gas oven Oven Function Control Knob l - H...

  • Page 6: Using The Oven

    Before the First Use of the Cooker Remove all packaging, both inside and outside the cooker, before using it. Using the Oven • Always cook with the oven door closed. • Stand clear when opening the drop down oven door. Do not allow it to fall open - support the door using the door handle, until it is fully open.

  • Page 7: Using The Gas Oven

    The effects of dishes Storage Drawer on cooking results Using the Gas oven Before using your oven Oven safety device If the oven burner accidentally goes out, Oven light pushbutton turn the oven knob to " " and wait at least 1 minute before trying to light the burner again.

  • Page 8: Gas Oven Cooking Charts

    Gas Oven Cooking Charts SHELF COOKING FOOD GAS MARK POSITIONS TIME MEAT & POULTRY Beef with bone 2 or 3 20 minutes per lb + 20 minutes Beef without bone 2 or 3 25 minutes per lb + 25 minutes Lamb 2 or 3 20-25 minutes per lb...
  • Page 9 Gas Oven Cooking Charts SHELF COOKING FOOD GAS MARK POSITION TIME PUDDINGS Egg Custard in a Bain Marie 2 or 3 1-1 1/4 hours Pavlova 2 or 3 1 1/2 hours Meringues 2 or 3 1 1/2 hours CAKES Rich Fruit Cake 2 or 3 3 1/2-4 hours Plain Fruit Cake...

  • Page 10: Grilling

    Grilling Grilling must be carried out with the oven Grill Time (Min) door closed. The grill pan handle must be Food removed from the pan. How to Use the Grill lamb pork whole trout/herring fillets plaice/cod lamb/pig lamb/pig Hints and Tips rare medium well...

  • Page 11: Maintenance And Cleaning

    Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the cooker from the electricity supply. The Hob Top The Pan Support The Burners Cleaning the Oven The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan.
  • Page 12 Oven Cavity Oven Shelves Cleaning around the flame spreader FO 0176 UNDER NO CIRCUMSTANCES SHOULD THE FLAME SPREADER BE REMOVED. FO 0177 Oven lamp replacement FO 0424...

  • Page 13: Something Not Working

    Something Not Working SYMPTOM SOLUTION...

  • Page 14: Guarantee Conditions

    Service and Spare Parts CUSTOMER CARE 08705 929 929 Customer Care Department Guarantee Conditions PARKINSON COWAN STANDARD European Guarantee GUARANTEE CONDITIONS 8.30am and 5.30pm premium Exclusions This guarantee does not cover:...
  • Page 15 Parkinson Cowan Service Force To contact your local Parkinson Cowan Service Force Centre telephone 08705 929 929 CHANNEL ISLANDS NORTH EAST ORKNEY Corsie Domestics (M65) 7 King Street GUERNSEY Guernsey Electricity GATESHEAD Unit 356a Kirkwall (M39) Dukesway Court PO Box 4...
  • Page 16 Parkinson Cowan Service Force To contact your local Parkinson Cowan Service Force Centre telephone 08705 929 929 SUNBURY Unit 1a MIDLANDS LONDON & EAST ANGLIA (M63) The Summit Hanworth Road BIRMINGHAM 66 Birch Road East BECKENHAM 11a Gardener Ind. Estate Hanworth Ind.

  • Page 17: Important Safety Requirements

    Instructions for the Installer Dimensions Technical Data Model Number: SIG 224 APPLIANCE CATEGORY APPLIANCE GAS SUPPLY Oven BURNER RAPID SEMI-RAPID AUXILIARY OVEN GRILL (large) (medium) (small) POSITION Important Safety Requirements Provision for Ventilation...

  • Page 18: Installation

    Location of the appliance Positioning the Cooker Installation 1. Positioning the Appliance (Fig. 1) Note A: Note B: FO 1141 Fig. 1 Note C: Note D: Note E:...
  • Page 19 300 mm. WALL FACE BACK OF COOKER ENGAGEMENT EDGE FOR STABILITY BRACKET LEVELLING FEET BASE OF COOKER PENCIL LINE ON THE FLOOR 245 mm. SIDE VIEW PLAN VIEW OF THE COOKER OF THE COOKER FO 2434 Fig. 2 Fitting the Stability Bracket Connecting to Gas (Not supplied) Note:...

  • Page 20: Electrical Connections

    Electrical connections Permanent Connection Any electrical work required to install this cooker should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS COOKER MUST BE EARTHED. The manufacturer declines any liability should these safety measures not be observed.

  • Page 21: Commissioning

    Commissioning Procedure: FO 1032 Pressure Testing...

  • Page 22: Conversion From Natural To Lpg Gas

    Conversion from Natural to LPG Gas Replacement of gas oven IMPORTANT The replacement/conversion of the gas hob should burner nozzle only be undertaken by a CORGI registered engineer. Method TO ADJUST THE GAS RATE Minimum level adjustment of gas oven burner FO 1061...
  • Page 23 Replacement of grill burner nozzle To replace the grill burner nozzle, follow this procedure: a) remove the screws (see fig.); b) take the grill burner out; c) with a socket spanner 7 unscrew and remove the nozzle, situated in the top of the oven, and replace it with the proper one (see Table at page 21);...
