Polygroup TV30P2870K05 Assembly Instructions

NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from Polygroup®!
Carefully follow the instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Place the tree pot on a level surface.(See Fig.A)
Fig. A - Tree Pot
Fig.B - Tree and Light Assembly
3. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and insert it into the assembled pot. Make sure the pole
is firmly inserted and secured into the pot.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Connect the light strings as per the color labels indicated in Fig. B and insert plug into the wall outlet. Your entire tree should now be
lit. If some bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in
order to maintain the performance and life expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one to
the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TV30P2870K05
1-888-919-0070
OR
Tree top
Section 1
Side view
Insert Green
Label Extension
Cord into Adapter
1
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120V, 60Hz, 0.08A
Output: 29V DC 0.107A
Adapter
To Be Plugged
Into Wall
Outlet
