A D V A N C E D
7 ½' AURORA MUSIC AND LIGHT SHOW TREE
model no. 151-8410-6 | Toll-free number: 1-866-827-4985
IMPORTANT: Please read this manual carefully before assembly and save it for reference.
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new Aurora Music and Light Show with 10 Pre-set Options.
This tree comes with an automatic power pole lighting system, allowing you to set up your tree and light it up in minutes!
Carefully follow the instructions below to quickly and technology, allowing up your new tree.
1. Choose a level surface near a wall outlet.
2. Assemble the tree stand. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 1
3. Identify all tree sections (See Fig. B) by the stickers on them, and start assembling from bottom to top.
4. Open the protective cap of pole, and insert the pole into the stand. Allow all branches to fall down into place. Check to make
sure that all wires are free from branch hinges.
TM
MC
Click
Tree Top
Section 2
Retain carton for storage purposes
Swivel the legs of the stand until they snap
into position. The legs should be evenly
spaced once this step is complete. Place the
tree stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120 V, 60 H, 0.83 A
Output: 24 V DC, 2 A
Do Not Tamper
With Internal Parts
Open the
cap cover
Align both arrows
in a straight line
before sliding
down to insert
Foot Pedal
Insert Green
On/Off Switch
Label Extension
Cord into Adaptor
Instruction Manual
For indoor use only
Advertisement
Table of Contents
Related Manuals for Polygroup NOMA ADVANCED 151-8410-6
Summary of Contents for Polygroup NOMA ADVANCED 151-8410-6
- Page 1 A D V A N C E D Instruction Manual For indoor use only 7 ½' AURORA MUSIC AND LIGHT SHOW TREE Retain carton for storage purposes model no. 151-8410-6 | Toll-free number: 1-866-827-4985 IMPORTANT: Please read this manual carefully before assembly and save it for reference. TREE ASSEMBLY INSTRUCTIONS Congratulations on purchasing your new Aurora Music and Light Show with 10 Pre-set Options.
- Page 2 5. Shape the tree section one branch at a time. Start with the tips closest to the pole and move outwards. Fan all the tips out in alternating directions, and slightly upsweep them for a natural look. (See Fig. C) Fig.
- Page 3 Aux Outlet Songs can be played via an external speaker. Simply connect the Music Controller Speaker to an external speaker with a 3.5 mm audio cable. Once connected to an external speaker, there will be no sound output from the conductor speaker. To restore the speaker to its factory settings, Music Controller Speaker press the small RESET button located beside...
- Page 4 If Tree Does Not Illuminate / Some Bulbs Do Not Light or Flicker 1. Check to make sure that all plugs and adaptor are properly connected as indicated in Fig. B. (If the tree comes with a foot pedal, try stepping on the ON/OFF button.) 2.
