INSTALLATION MANUAL
HIGH EFFICIENCY SEALED COMBUSTION
DRUM HEAT EXCHANGER SERIES
MODEL: DFAA/DFAH
(Oil and Gas Conversion Burner/
Single Stage Downflow Only)
66 - 84 MBH INPUT
(19.34 - 24.62 KW) INPUT
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
DUCTWORK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
FILTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
OIL PIPING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
ELECTRICAL POWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
VENT/COMBUSTION AIR SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Label Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Air Distribution Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Closet To Door Clearance - 5" or Greater . . . . . . . . . . . . . . . . . . . . . . . . . 7
Furnace To Closet Door Clearance - Less Than 1" . . . . . . . . . . . . . . . . . . 7
Duct Connector Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Recommended Floor Cut-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Duct Connector Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Duct Connector Screw Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Duct Connector Tab Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Anti-Backflow Damper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation of Furnace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Floor Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Furnace Air Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Oil Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
One-Pipe System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Two-Pipe System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Solenoid Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Line Wiring Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Wiring for Heat Only Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Wiring for Electronic Heat-Cool Thermostat . . . . . . . . . . . . . . . . . . . . . . . 14
Wiring for Standard Heat-Cool Thermostat . . . . . . . . . . . . . . . . . . . . . . . 14
Unit Clearances to Combustibles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Minimum Duct Sizing For Proper Airflow . . . . . . . . . . . . . . . . . . . . . . . 6
Round Duct Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
External Static Pressure Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Filter Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Burner Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Burner Rating at Elevation Above Sea Level, gph (l/m) . . . . . . . . . . . 12
Ratings & Physical / Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Roof Jack Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cad Cell Resistance When Sensing Flame . . . . . . . . . . . . . . . . . . . . 22
SECTION I: SAFETY
This is a safety alert symbol. When you see this symbol on
labels or in manuals, be alert to the potential for personal
Understand and pay particular attention to the signal words DANGER,
WARNING, or CAUTION.
DANGER indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if not
avoided may result in minor or moderate injury. It is also used to
alert against unsafe practices and hazards involving only property dam-
age.
LIST OF SECTIONS
SAFETY CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
START-UP AND ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
WIRING DIAGRAM - OIL-FIRED FURNACE . . . . . . . . . . . . . . . . . . . . 27
GAS GUN BURNER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
START-UP AND ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
WIRING DIAGRAM - GAS CONVERSION BURNER . . . . . . . . . . . . . . 38
LIST OF FIGURES
Wiring for Blend Air Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Elbow Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Combustion Air Inlet Pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Combustion Air Inlet Pipe Alternate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Flue Shield Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Roof Jack Attachment to Furnace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Standard Roof Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Roof Jack With Removable Crowns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Installing Roof Jack Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Ceiling Ring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Home Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Electrode Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Oil Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Wiring Diagram for DFAA - Oil-Fired Furnace . . . . . . . . . . . . . . . . . . . . . 27
Wiring Diagram for DFAH - Oil Furnace . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Manual Shut-off Valve/Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Proper Piping Practice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Gas Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Reading Gas Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Electrode Orientation and Gap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Wiring Diagram for DFAA - Gas Conversion Burner . . . . . . . . . . . . . . . . . 38
Wiring Diagram for DFAH - Gas Gun . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
LIST OF TABLES
Timings and Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Burner Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Filter Performance - Pressure Drop Inches W.C. and (kPa) . . . . . . . .24
Blower Performance CFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Replacement Parts - Non Electrical . . . . . . . . . . . . . . . . . . . . . . . . . .26
Gas Line Piping Size and Length . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Length of Standard Pipe Threads in Inches (mm) . . . . . . . . . . . . . . .30
High Altitude Duration Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Gas Burner Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Inlet Gas Pressure Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Nominal Manifold Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Improper installation may create a condition where the operation of
the product could cause personal injury or property damage.
Improper installation, adjustment, alteration, service or mainte-
nance can cause injury or property damage. Refer to this manual
for assistance or for additional information, consult a qualified con-
tractor, installer or service agency.
This product must be installed in strict compliance with the installa-
tion instructions and any applicable local, state, and national codes
including, but not limited to building, electrical, and mechanical
codes.
EFFICIENCY
RATING
CERTIFIED
For Installation In:
1.
Manufactured (Mobile) Homes
2.
Recreational Vehicles & Park Models
3.
Modular Homes & Buildings
107272-UIM-B-1105
ISO 9001
Certified Quality
Management System
