- Page 1 WALLBOX EV PORTABLE USER MANUAL INSTALLATION MANUAL...
- Page 2 EV Portable bears the CE mark. The corresponding Declarations of Conformity ara located at WallboxOK This product metes the reuirementes of the ROHS Directive (2011/65/CE). The corresponding Declarations of Conformity ara located at WallboxOK Disposal Information The crossed-out trash container symbol indicates that electric appliances and electronic devices including accessories are to be disposed of separately from general household trash.
-
Page 3: Table Of Contents
SPECIFICATION FOR THE ELECTRICAL CONNECTION ........... 12 Dear Customer, WallboxOk Team want to thank you for buying one of our Electric Vehicle Charging Box. Our passion in design and innovation makes our charging points leaders in technology. Do not hesitate to contact us at info@wallboxok.com if you have any suggestion. -
Page 4: Important Information
Safety instructions Warning! Not observing the safety instructions can result in risk of death, injuries and damage to the device! WALLBOXOK assumes no liability for claims resulting from this! Electrical hazard / fire hazard! Never use damaged, worn or dirty charging plugs. -
Page 5: Intended Used
Intended used EV PORTABLE is a "charging station" for the indoor and outdoor area at which electrically operated vehicles can be charged (e.g. electric automobiles). It can be used portable and allow you to change the maximum Amps rate. The respective national regulations must be observed with regard to the installation and connection of the charging station. -
Page 6: Overview
OVERVIEW WALLBOX EV PORTABLE AMPS RATE BUTTONS LCD DISPLAY WALLBOX PORTABLE Cable IEC 62196 o SAE J1772 INDUSTRIAL CEE PLUG www.wallboxok.com... -
Page 7: Versions
VERSIONS Amps Range 6-32 Amps 6-32 Amps Phase 3F+N+TT 1F+N+TT Max Power 22 kW 7,6 kW Supply CEE Plug www.wallboxok.com... -
Page 8: Using De Charging Station
The charging procedure is ended by unplugging the charging cable at the vehicle. For details, please refer to the instructions of the vehicle manufacturer. Do not use force to pull out a mechanically locked plug! Disconnect the charging cable from the vehicle ("Wait for unplugging"). Disconnect the CEE plug www.wallboxok.com... -
Page 9: Charge Amps Selection
IEC 62196: 11 kW 6-16 Amp. SAE J1772: 3,7 kW CEE 16 AMPS 400V IEC 62196: 3,7 kW 6-16 Amp. SAE J1772: 3,7 kW CEE 16 AMPS 230V IEC 62196: 2,7 kW 6-12 Amp. SAE J1772: 2,7 kW SCHUKO www.wallboxok.com... -
Page 10: Troubleshooting
– end the charging procedure according to the instructions of the vehicle manufacturer. Eventually the plug cannot be unlocked under tension - Push in the plug and connect it again on the vehicle. Then end the charging procedure again. www.wallboxok.com... -
Page 11: Installation Guidelines
Observe the internationally relevant installation standards (e.g. IEC 60364-1 and IEC 60364- 5-52) and follow the applicable national installation standards and regulations. www.wallboxok.com... -
Page 12: Specification For The Electrical Connection
SPECIFICATION FOR THE ELECTRICAL CONNECTION EV Portable is designed for plug it in a CEE Industrial connector (female). You need to choose the amps rate depending on the place where it is installed and the adaptor selected. EV Portable needs to be connected to a main supply line and must be hardwired and correspond to the nationally applicable legal conditions.
