How to Install the Wi-Fi Mini-PIM for SRX Series Services

Gateways

IN THIS GUIDE

Wi-Fi Mini-Physical Interface Module Overview | 1

Wi-Fi Mini-PIM Hardware Specifications | 4

Channels and Frequencies Supported on the Wi-Fi Mini-PIM | 5

Country Codes and Regulatory Domains | 9

RF Specifications for the Wi-Fi Mini-PIM | 18

Installing the Wi-Fi Mini-PIM in an SRX Series Services Gateway | 20

Configuring the Wi-Fi Mini-PIM on an SRX Series Services Gateway | 22

Verify the Status of the Wi-Fi Mini-PIM | 27

Upgrading the Firmware on the Wi-Fi Mini-PIM | 30

Regulatory and Safety Information for the Wi-Fi Mini-PIM | 33

Agency Approvals and Compliance Information | 38

Wi-Fi Mini-Physical Interface Module Overview

The Wi-Fi Mini-Physical Interface Module (Mini-PIM) for branch SRX Series Services Gateways provides a branch-in-a-box

solution (which includes an SRX Series device, LTE, and wi-fi) for retail and small office deployments. The Mini-PIM has

an embedded enterprise-class wireless system-on-chip (SOC) that supports the 802.11ac Wave 2 wireless standards. The

Mini-PIM is backward-compatible with 802.11a, 802.11b, 802.11g, and 802.11n.

The Mini-PIM supports the following key features:

2x2 MU-MIMO—Enables transmission of data to multiple clients simultaneously.

Dual radios—Provides concurrent dual bands of 2.4 GHz and 5 GHz. The radios operate in any one of the supported

radio modes. You can configure each radio to support connectivity from one type of client or different types of clients.

Virtual access points (VAPs)—Allows you to segment the WLAN into multiple broadcast domains that are the wireless

equivalent of Ethernet VLANs. A single access point is segregated into multiple individual VAPs, simulating multiple

access points in a single system.

Need help?

Do you have a question about the SRX-MP-WLAN-US and is the answer not in the manual?

Questions and answers

Summary of Contents for Juniper SRX-MP-WLAN-US

Page 1 How to Install the Wi-Fi Mini-PIM for SRX Series Services Gateways IN THIS GUIDE Wi-Fi Mini-Physical Interface Module Overview | 1 Wi-Fi Mini-PIM Hardware Specifications | 4 Channels and Frequencies Supported on the Wi-Fi Mini-PIM | 5 Country Codes and Regulatory Domains | 9 RF Specifications for the Wi-Fi Mini-PIM | 18 Installing the Wi-Fi Mini-PIM in an SRX Series Services Gateway | 20 Configuring the Wi-Fi Mini-PIM on an SRX Series Services Gateway | 22...
Page 2 NOTE: You can configure up to eight VAPs on each radio. Configurable transmit power—Enables you to configure the transmit power for each radio on a percentage basis. By default, the Mini-PIM assigns 100 percent power to each radio at startup to provide maximum coverage. Wireless security for client authentication—The Mini-PIM supports the following authentication methods: Wi-Fi Protected Access (WPA) Personal, which includes AES-CCMP with preshared key authentication.
Page 3 Three models are available based on the regional wireless standards (see Table Table 2: Wi-Fi Mini-PIM Models Model or SKU Supported Region Notes SRX-MP-WLAN-US United States This model is based on the wireless standards supported in the United States. The country code is fixed and cannot be changed. SRX-MP-WLAN-IL Israel This model is based on the wireless standards supported in Israel.
Page 4 Wi-Fi Mini-PIM Hardware Specifications Table 3 provides the hardware specifications for the Mini-PIM. Table 3: Wi-Fi Mini-PIM Hardware Specifications Description Value Dimensions H x W x L: 0.79 in. x 3.70 in. x 5.29 in. (2.0 cm x 9.4 cm x 13.43 cm) Weight 0.29 lb (0.13 kg) Form factor...
Page 5 Table 4: Specifications for the Wi-Fi Mini-PIM Antenna (continued) Specification Value Radiation Omnidirectional Peak gain 5dBi +/-0.5 Polarization Linear Operating temperature –4° F (–20° C) to 149° F (65° C) Connector type RP-SMA Channels and Frequencies Supported on the Wi-Fi Mini-PIM The Wi-Fi Mini-PIM supports channel bandwidths of 20 MHz, 40 MHz, and 80 MHz.
Page 6 Table 5: Channels Supported on the 2.4 GHz Radio (20 MHz and 40 MHz Bandwidth) Band Channel Number Center Frequency (MHz) 2400~2483.5 MHz 2412 2417 2422 2427 2432 2437 2442 2447 2452 2457 2462 2467 2472 Table 6 through Table 8 list the channels supported on the 5 GHz radio.
Page 7 Table 6: Channels Supported on the 5 GHz Radio (20 MHz Bandwidth) (continued) Band Channel Number Center Frequency MHz 5250~5350 5260 5280 5300 5320 5470~5725 5500 5520 5540 5560 5580 5600 5620 5640 5660 5680 5700 5725~5850 5720 5745 5765 5785 5805 5825...
Page 8 Table 7: Channels Supported on the 5 GHz Radio (40 MHz Bandwidth) Band Channel Number Center Frequency MHz 5150~5250 MHz 5190 5230 5250~5350 MHz 5270 5310 5470~5725 MHz 5510 5550 5590 5630 5670 5725~5850 MHz 5710 5755 5795 Table 8: Channels Supported on the 5 GHz Radio (80 MHz Bandwidth) Band Channel Number Center Frequency MHz...
Page 9 Dynamic Frequency Selection Dynamic Frequency Selection (DFS) enables use of 5 GHz frequencies that are typically reserved for radars. In countries where DFS is required, the Wi-Fi card performs appropriate checks for radar. If radar is detected on a channel, the access point selects a radar-free channel and performs a 60-second availability check before operating on that channel.
Page 10 Table 9: Country Codes and Regulatory Domains Country Country Code Model Radio 1 (5 GHz) Radio 2 (2.4 GHz) Regulatory Regulatory Domain Domain (5 GHz) (2.4 GHz) Australia SRX-MP-WLAN-WW FCC6 36, 40, 38, 46, 42, 58, WORLD 1 to 13 1 to 13 (AU) 44, 48,...
Page 11 Table 9: Country Codes and Regulatory Domains (continued) Country Country Code Model Radio 1 (5 GHz) Radio 2 (2.4 GHz) Regulatory Regulatory Domain Domain (5 GHz) (2.4 GHz) China (CN) SRX-MP-WLAN-WW APL14 36, 40, 38, 46, 42, 58, WORLD 1 to 13 1 to 13 44, 48, 54, 62,...
Page 12 Table 9: Country Codes and Regulatory Domains (continued) Country Country Code Model Radio 1 (5 GHz) Radio 2 (2.4 GHz) Regulatory Regulatory Domain Domain (5 GHz) (2.4 GHz) India (IN) SRX-MP-WLAN-WW APL15 36, 40, 38, 46, 42, 58, WORLD 1 to 13 1 to 13 44, 48, 54, 62,...
Page 13 Table 9: Country Codes and Regulatory Domains (continued) Country Country Code Model Radio 1 (5 GHz) Radio 2 (2.4 GHz) Regulatory Regulatory Domain Domain (5 GHz) (2.4 GHz) Malaysia SRX-MP-WLAN-WW FCC11 36, 40, 38, 46, 42, 58, WORLD 1 to 13 1 to 13 (MY) 44, 48,...
Page 14 Table 9: Country Codes and Regulatory Domains (continued) Country Country Code Model Radio 1 (5 GHz) Radio 2 (2.4 GHz) Regulatory Regulatory Domain Domain (5 GHz) (2.4 GHz) Mexico SRX-MP-WLAN-WW FCC3 36, 40, 38, 46, 42, 58, ETSIC 1 to 13 1 to 13 (MX) 44, 48,...
Page 15 Table 9: Country Codes and Regulatory Domains (continued) Country Country Code Model Radio 1 (5 GHz) Radio 2 (2.4 GHz) Regulatory Regulatory Domain Domain (5 GHz) (2.4 GHz) SRX-MP-WLAN-WW FCC3 36, 40, 38, 46, 42, 58, ETSIC 1 to 13 1 to 13 Zealand 44, 48,...
Page 16 Table 9: Country Codes and Regulatory Domains (continued) Country Country Code Model Radio 1 (5 GHz) Radio 2 (2.4 GHz) Regulatory Regulatory Domain Domain (5 GHz) (2.4 GHz) South Korea SRX-MP-WLAN-WW APL9 36, 40, 38, 46, 42, 58, WORLD 1 to 13 1 to 13 (KR) 44, 48,...
Page 17 Code Model Radio 1 (5 GHz) Radio 2 (2.4 GHz) Regulatory Regulatory Domain Domain (5 GHz) (2.4 GHz) United SRX-MP-WLAN-US FCC8 36, 40, 38, 46, 42, 58, FCCA 1 to 11 1 to 11 States (US) 44, 48, 54, 62,...
Page 18 Table 9: Country Codes and Regulatory Domains (continued) Country Country Code Model Radio 1 (5 GHz) Radio 2 (2.4 GHz) Regulatory Regulatory Domain Domain (5 GHz) (2.4 GHz) Vietnam SRX-MP-WLAN-WW FCC3 36, 40, 38, 46, 42, 58, WORLD 1 to 13 1 to 13 (VN) 44, 48,...
Page 19 Table 10: RF Specifications for the Wi-Fi Mini-PIM (continued) Receive Sensitivity (+/-2 Target Power (+/-2 Operating Mode Data Rate dBm) Per Chain dBm) Per Chain 802.11ac (VHT40) MCS0 MCS9 802.11ac (VHT80) MCS0 15.5 MCS9 10.5 802.11a 6 Mbps 16.5 54 Mbps 802.11b 1 Mbps 11 Mbps...
Page 20 Installing the Wi-Fi Mini-PIM in an SRX Series Services Gateway You can install the Mini-PIM in any of the Mini-PIM slots on the services gateway. NOTE: You can install only one Wi-Fi Mini-PIM in a services gateway. To install the Mini-PIM in a services gateway: 1.
Page 21 Figure 3: Attaching the Antennas (Direct Mounting) Using an external antenna base—Attach the antennas to the antenna base. Connect the cables from each antenna base to the RP-SMA connectors on the front panel (see Figure Figure 4: Attaching the Antennas Using an Antenna Base (Rack Mounting) For SRX320 Services Gateways, which can be mounted on a wall, you can mount the antennas on a wall as shown Figure...
Page 22 Figure 5: Attaching the Antennas Using an Antenna Base (Wall Mounting) > 11 in. (27.9 cm) 5. Power on the services gateway. Configuring the Wi-Fi Mini-PIM on an SRX Series Services Gateway IN THIS SECTION Wi-FI Mini-PIM Configuration Overview | 23 Radio Configuration Overview | 23 Virtual Access Point Configuration Overview | 24 Configure the Wi-Fi Mini-PIM | 25...
Page 23 Wi-FI Mini-PIM Configuration Overview Before you configure the Mini-PIM, configure the network settings on the SRX Series device and connect the device to your network. For details, see the Hardware Guide for your SRX Series device. Configure the following settings for the access point: Name for the access point Interface—The interface name for the AP is denoted as wl-x/0/0, where x is the slot on the services gateway in which the Mini-PIM is installed.
Page 24 To increase the network capacity, place access points closer together and reduce the value of the transmit power. This helps reduce overlap and interference among access points. A lower transmit power setting can also keep your network more secure because weaker wireless signals are less likely to propagate outside the physical location of your network. Virtual Access Point Configuration Overview Virtual access points (VAPs) allow different security mechanisms for different clients on the same access point.
Page 25 NOTE: If you do not set the country code for the SRX-MP-WLAN-WW models, the Mini-PIM considers the country code as US. You cannot set the country code for the SRX-MP-WLAN-US and SRX-MP-WLAN-IL models. c. Set the location: user@host# set wlan access-point name location location d.
Page 26 NOTE: Changing the radio settings can cause the access point to stop and restart system processes. If this occurs, wireless clients that are connected to the access point will temporarily lose connectivity. We recommend that you change radio settings when WLAN traffic is low. a.
Page 27 user@host# set wlan access-point name radio [1|2] virtual-access-point id security wpa-enterprise radius-key secret-key user@host# set wlan access-point name radio [1|2] virtual-access-point id security wpa-enterprise wpa-version wpa-personal—The device uses preshared keys (PSKs) or a passphrase for authentication and encryption. Keys are stored on the device and on all wireless clients. You do not need to configure a separate authentication server. user@host# set wlan access-point name radio [1|2] virtual-access-point id security wpa-personal cipher-suites ccmp user@host# set wlan access-point name radio [1|2] virtual-access-point id security wpa-personal key-type...
Page 28 Table 12: Commands to Verify and Monitor the Status of the Wi-Fi Mini-PIM Command Purpose show wlan access-points ap-name Displays the status of the specific access point. detail Sample output: Active access point detail information Access Point : wap3 Type : Internal Location : Default Location...
Page 29 Table 12: Commands to Verify and Monitor the Status of the Wi-Fi Mini-PIM (continued) Command Purpose show wlan access-points ap-name Displays the details about the clients connected to the access point. client-associations Access point client associations information Access point: wap3 Client MAC Address Auth Packets Rx/Tx...
Page 30 Table 12: Commands to Verify and Monitor the Status of the Wi-Fi Mini-PIM (continued) Command Purpose VAP2: SSID : 5g_vap2 MAC Address : 00:00:5e:00:53:12 Maximum Station : 100 Broadcast SSID : Enable Station Isolation : Disable Upload Limit : Disable Download Limit : Disable VLAN ID...
Page 31 The Current version field in the output displays the firmware version that is currently installed on the Mini-PIM. If there is a newer version of the firmware at https://www.juniper.net/support/downloads/?p=junos-srx#sw, then proceed to the next step to download the latest firmware.
Page 32 PIC 0 MWAP_FW 1.1.8 1.2.1 Perform indicated firmware upgrade ? [yes,no] (no) yes Firmware upgrade initiated, use "show system firmware" to monitor status. 5. Verify that the firmware is upgraded successfully. The status should show OK. user@host > show system firmware Part Type Tag Current...
Page 33 Part Type Tag Current Available Status version version FPC 2 PIC 0 MWAP_FW 1.2.1 1.2.1 Routing Engine 0 RE BIOS Routing Engine 0 RE BIOS Backup The device reboots after the firmware is upgraded. Note that if you issue the show system firmware command after the reboot, the Current Version field shows the latest firmware version and the Available Version field shows zero(0).
Page 34 For products available in the USA/Canada markets, only channels 1–11 can be operated. Selection of other channels is not possible. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body.
Page 35 Industry Canada Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
Page 36 not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device. Cet émetteur radio [4558A-MPWAPUS] a été approuvé par Innovation, Sciences et Développement économique Canada pour fonctionner avec les types d’antennes énumérés ci-dessous, avec le gain maximal admissible indiqué.
Page 37 L'utilisateur final doit également être informé du fait que tout changement ou modification non expressément approuvé par le fabricant pourrait annuler son droit d'utiliser cet équipement. Son utilisation est soumise aux deux conditions suivantes: (1) cet appareil ne doit pas causer d'interférences nuisibles (2) cet appareil doit accepter toutes les interférences reçues, y compris celles pouvant entraîner un fonctionnement indésirable.
Page 38 Japan Statement 5 GHz band (W52, W53): Indoor use only Agency Approvals and Compliance Information The interface module complies with the following standards: Safety CAN/CSA-C22.2 No. 60950-1 Information Technology Equipment - Safety CAN/CSA C22.2 No. 62368-1-2014, Audio/Video, Information and Communication Technology Equipment – Safety UL 60950-1 (2nd Edition) Information Technology Equipment - Safety UL 62368-1, Audio/Video, Information and Communication Technology Equipment –...
Page 39 EN55024/CISPR24 EN300-386 Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.
