- Page 1 IT-E185 Power Meter Fixture User Manual Model: IT-E185 Version: V2.0...
- Page 2 Trademarks A WARNING sign denotes a hazard. any information contained herein. It calls attention to an operating Should ITECh and the user enter Pentium is U.S. registered trademarks procedure or practice that, if not of Intel Corporation. into a separate written agreement...
-
Page 3: Warranty Service
ITECH, and ITECH will be responsible for return freight. If the product is sent to ITECH for warranty service from other countries, the customer will be responsible for all the freight, duties and other taxes. Limitation of Warranty ... -
Page 4: Regulation Tag
10 years. The product can be used safely within the environmental protection period; otherwise, the product should be put into the recycling system. Waste electrical and electronic equipment (WEEE) directive Waste electrical and electronic equipment (WEEE) directive, Copyright © Itech Electronics Co., Ltd. - Page 5 According to the equipment classification in Annex I of the WEEE directive, this instrument belongs to the “Monitoring” product. If you want to return the unnecessary instrument, please contact the nearest sales office of ITECH. Copyright © Itech Electronics Co., Ltd.
-
Page 6: Compliance Information
Connection of the instrument to a test object may produce radiations beyond the specified limit. Use high-performance shielded interface cable to ensure conformity with the EMC standards listed above. Safety Standard IEC 61010-1:2010/ EN 61010-1:2010 Copyright © Itech Electronics Co., Ltd. -
Page 7: Table Of Contents
Waste electrical and electronic equipment (WEEE) directive ................. 2 Compliance Information ............................4 About IT-E185 ............................... 1 Dimension................................1 Introduction of Front Panel and Rear Panel ......................2 Connecting Fixture ..............................2 Application Case ..............................5 Copyright © Itech Electronics Co., Ltd. -
Page 8: About It-E185
IT-E185 User Manual About IT-E185 IT-E185 is an optional accessory for the User of ITECH, which is mainly for convenient wiring during test with IT9121/IT9121E power meter. See the figure below for IT-E185: Dimension IT-E185 dimension figure is as follows: Unit:mm Copyright ©... -
Page 9: Introduction Of Front Panel And Rear Panel
③ Current input terminals Connecting Fixture During AC input power consumption test of AC-DC adapter, the IT-E185 is required to connect IT9121/IT9121E to the adapter and grid lines in series. When the measured current is relatively large, connect the voltage input terminal to the side that is closest to the load. - Page 10 Connecting Method The connection method for measuring the low-current measurement circuit is as follows: Open the current terminal protection covers of the power meter and the device. Protective Cover Protective Cover Copyright © Itech Electronics Co., Ltd.
- Page 11 V+1 suspended when high current is measured. Connect the AC power input socket of the rear panel to the 220 V AC input, as show above. To guarantee personal safety, after the measurement circuit is connected, Copyright © Itech Electronics Co., Ltd.
-
Page 12: Application Case
Use Fixture When the fixture is used, the wiring is simple without damaging the original plug. Wiring steps are as follows: Put the DUT input terminal to the three-core socket on the front panel. Copyright © Itech Electronics Co., Ltd. - Page 13 Connect the corresponding voltage and current terminals to the terminals on IT9121/IT9121E power meter. The rear panel The front panel of IT-E185 of IT-E185 Copyright © Itech Electronics Co., Ltd.
- Page 14 YOUR POWER TESTING SOLUTION Contact US Thank you for purchasing ITECH products.If you have any doubt about this product, please contact us as follow. 1. Please refer to the CD-ROM of related user’s manual in package. 2. Click www.itechate.com or scan the right two-dimension code to visit the ITECH website.
