- Page 1 Combi oven Read instructions before use Convotherm 4 easyDial Operating instructions - Original, ENG...
-
Page 3: Table Of Contents
Table of Contents Table of Contents General Structure of customer documentation Essential reading relating to safety About these operating instructions The easyDial functions A summary of the easyDial functions Selected cooking profiles easyDial layout Overall view of the easyDial layout The buttons for the operating modes The button and display for the cooking temperature The buttons and display for the cooking time and core temperature... - Page 4 Table of Contents The workflow for ConvoClean fully automatic oven cleaning using single-measure dispensing Making settings using easyDial Setting the date, time and temperature display Data import/export Opening and running Import/Export functions Closing the Import/Export functions The workflow for exporting HACCP data The workflow for importing/exporting a cookbook The workflow for importing a cleaning profile The workflow for importing a software update...
-
Page 5: General
1 General 1 General Purpose of this chapter This chapter provides information on how to use these operating instructions. 1.1 Structure of customer documentation Contents of customer documentation The customer documentation for the combi oven includes the following documents: Installation manual ■ User manual ■... -
Page 6: Essential Reading Relating To Safety
1 General 1.2 Essential reading relating to safety Safety information in the customer documentation Safety information relating to the combi oven appears only in the installation manual and the user manual. The installation manual contains the safety information for the tasks covered by the manual and which are performed when moving, setting up and installing the appliance and when putting the appliance into service and removing the appliance from service. -
Page 7: About These Operating Instructions
1 General 1.3 About these operating instructions Purpose These operating instructions are intended to provide all those people who use the combi oven with an overview of easyDial and how to use it, and to enable them to perform essential tasks using easyDial. Who should read this manual Name of target group Tasks... -
Page 8: The Easydial Functions
2 The easyDial functions 2 The easyDial functions Purpose of this chapter easyDial is the combi oven user interface. Using easyDial you can quickly create your own cooking profiles. All the functions for the process are available on one level. This chapter provides a summary of the easyDial functions and a selection of available cooking pro‐ files. - Page 9 2 The easyDial functions Import and Export functions You can use the import/export functions to import or export cookbooks and perform software updates for instance.
-
Page 10: Selected Cooking Profiles
2 The easyDial functions 2.2 Selected cooking profiles Range of cooking profiles Product ACS+ Frozen baguette 170 °C 15 min Baked Potato 180 °C 93 °C Crème Caramel / Royal 80 °C 35 min Fish fingers 210 °C 12 min Proving, Baked goods 35 °C 3 min Roast chicken breast... -
Page 11: Easydial Layout
3 easyDial layout 3 easyDial layout Purpose of this chapter Your combi oven is operated using control-panel buttons and a rotary-encoder control knob, known as the Convotherm dial or C-Dial. All the appliance functions can be selected directly using these buttons, with display selections made using the C-Dial. -
Page 12: The Buttons For The Operating Modes
3 easyDial layout 3.2 The buttons for the operating modes Steam Button for entering a cooking profile containing the Steam operating mode Indicator above the button shows red light when oper‐ ■ ating mode selected Combi-steam Button for entering a cooking profile containing the Combi-steam operating mode Convection Button for entering a cooking profile containing the Con‐... -
Page 13: The Buttons For The Cooking Functions
3 easyDial layout 3.5 The buttons for the cooking functions Fan speed Cooking-function selection button providing 5 levels of control for the flow speed in the cooking chamber Level 1 Minimum flow speed Level 4 Preset Level 5 Maximum flow speed HumidityPro Cooking-function selection button providing 5 levels of control for the humidity in the cooking chamber... -
Page 14: The Prompts
3 easyDial layout 3.6 The prompts Rinse aid low Indicator flashes red when rinse aid must be topped up (fully automatic oven cleaning only) Cleaning agent low Indicator flashes red when cleaning agent must be top‐ ped up (fully automatic oven cleaning only) Low water Indicator flashes red when there is no connection to the water supply... -
Page 15: The Program Area
3 easyDial layout 3.7 The program area Cookbook Cookbook button for managing up to 99 cooking profiles See page 32 Cookbook with USB Buttons for the Import/Export functions stick inserted See page 51 Cleaning Buttons for the oven cleaning profiles See page 39 Display Indicates the: Actual oven temperature or core temperature... -
Page 16: The C-Dial Functions
3 easyDial layout 3.8 The C-Dial functions Turning the C-Dial Select settings Press the C-Dial Confirm settings ■ briefly Start/end processes ■ See page 26 See page 41 Press and hold the Opens the 'Settings' C-Dial See page 49 Green C-Dial Illuminated Appliance door closed and appliance ready ■... -
Page 17: Cooking Using Easydial
4 Cooking using easyDial 4 Cooking using easyDial Purpose of this chapter In order to cook with your combi oven you need a suitable cooking profile for your product. You can quickly enter a single-step cooking profile using the operating modes in the easyDial user in‐ terface, then simply start it straight away. - Page 18 4 Cooking using easyDial Select the 'Fan speed' level you require. See page 13 Result: you have finished entering the cooking pro‐ file. Further steps: Preheat/cool down the cooking chamber following a prompt; see page 25 to find out how ■...
-
Page 19: Entering A Cooking Profile Using Combi-Steam
4 Cooking using easyDial 4.2 Entering a cooking profile using Combi-steam Area of use Combi-steam is a combination of convection and steam. 'Combi-steam' is the combi oven operating mode in which the food is cooked using combi-steam. The 'Combi-steam' operating mode is suitable for the following cooking methods for example: Roasting Baking... - Page 20 4 Cooking using easyDial Further steps: Preheat/cool down the cooking chamber following a prompt; see page 25 to find out how ■ Start the cooking operation; see page 26 to find out how ■ The workflow for cooking with preheat, see page 27 ■...
-
Page 21: Entering A Cooking Profile Using Convection
4 Cooking using easyDial 4.3 Entering a cooking profile using Convection Area of use 'Convection' is a combi oven operating mode in which the food is cooked using dry heat. The 'Convec‐ tion' operating mode is suitable for the following cooking methods for example: Roasting Baking Gratinate... - Page 22 4 Cooking using easyDial Further steps: Preheat/cool down the cooking chamber following a prompt; see page 25 to find out how ■ Start the cooking operation; see page 26 to find out how ■ The workflow for cooking with preheat, see page 27 ■...
-
Page 23: Entering A Cooking Profile Using Regenerate
4 Cooking using easyDial 4.4 Entering a cooking profile using Regenerate Area of use 'Regenerate' is the combi oven regenerating function, which is used to finish precooked meals, ready to serve. Regenerate is suitable for practically all types of dishes. which are arranged as plated meals for regenerating. -
Page 24: Entering A Cooking Profile Using Core Temperature Control
4 Cooking using easyDial 4.5 Entering a cooking profile using core temperature control Area of use The core temperature control function uses the core temperature inside the product to control the length of the cooking process rather than the time. It can be used with all operating modes. The user manual contains information on handling the core temperature probe safely. -
Page 25: Selecting Preheat Or Cool Down
4 Cooking using easyDial 4.6 Selecting Preheat or Cool down Requirements You have entered a new cooking profile or opened a cooking profile from the 'Cookbook'. ■ The prompt to preheat or cool the cooking chamber prior to cooking is displayed. ■... -
Page 26: Starting A Cooking Operation
4 Cooking using easyDial 4.7 Starting a cooking operation Requirements Before starting the cooking operation, you have familiarized yourself with the rules and hazard ■ warnings given in the user manual that relate to working safely with the appliance, and you follow the instructions given there. -
Page 27: The Workflow For Cooking With Preheat
4 Cooking using easyDial 4.9 The workflow for cooking with preheat Requirements You have entered a new cooking profile or opened a cooking profile from the 'Cookbook'. ■ The oven temperature is too low for the selected cooking profile. ■ The Cooking workflow Oven temperature too low The appliance signals by flashing the 'Preheat' indi‐... - Page 28 4 Cooking using easyDial Cooking finished The C-Dial flashes green when cooking has finish‐ Prompt to remove food A signal beeps while the prompt to 'Open the appli‐ ance door' lights up.
-
Page 29: The Workflow For Cooking With Cool Down
4 Cooking using easyDial 4.10 The workflow for cooking with Cool down Requirements You have entered a new cooking profile or opened a cooking profile from the 'Cookbook'. ■ The oven temperature is too high for the selected cooking profile. ■ The Cooking workflow Oven temperature too high The appliance signals by flashing the 'Cool down'... - Page 30 4 Cooking using easyDial Cooking finished The C-Dial flashes green when cooking has finish‐ Prompt to remove food A signal beeps while the prompt to 'Open the appli‐ ance door' lights up.
-
Page 31: Changing Data While Cooking Is In Progress
4 Cooking using easyDial 4.11 Changing data while cooking is in progress Requirements You have started the cooking operation. ■ Changing data while cooking is in progress Press the 'Cooking temperature' button in order to change the cooking temperature. Turn the C-Dial to set the cooking temperature you require. -
Page 32: Working With The Cookbook
5 Working with the cookbook 5 Working with the cookbook Purpose of this chapter You can open and immediately run an existing cooking profile using the easyDial 'Cookbook'. Before starting a cooking operation, you must always be familiar with the rules and hazard warnings in the user manual that relate to working safely with the appliance, and you must follow the instructions given there. -
Page 33: Running A Cooking Profile From The Cookbook
5 Working with the cookbook 5.2 Running a cooking profile from the cookbook Requirements Before running a cooking profile, you have familiarized yourself with the rules and hazard warnings ■ in the user manual that relate to working safely with the appliance, and you follow the instructions given there. -
Page 34: Creating A New Single-Step Cooking Profile In The Cookbook
5 Working with the cookbook 5.3 Creating a new single-step cooking profile in the cookbook Creating a new single-step cooking profile in the cookbook Press the 'Cookbook' button. Turn the C-Dial to select an available program number for the cooking profile. Yellow C-Dial = program number available Green C-Dial = program number already used Enter the data for the cooking profile. -
Page 35: Creating A Multistep Cooking Profile In The Cookbook
5 Working with the cookbook 5.4 Creating a multistep cooking profile in the cookbook Requirements You are in the 'Cookbook' and have selected a program number. ■ You have already entered and saved the first cooking step of a cooking profile. ■... -
Page 36: Deleting A Cooking Profile From The Cookbook
5 Working with the cookbook 5.5 Deleting a cooking profile from the cookbook Cookbook functions Program number P1 to P99 for cooking profiles Delete the cooking profile Requirements The cooking profile has been saved in the 'Cookbook'. ■ Deleting a cooking profile from the cookbook Press the 'Cookbook' button. -
Page 37: Closing The Cookbook
5 Working with the cookbook 5.6 Closing the Cookbook Requirements The program number for a cooking profile has been selected from the 'Cookbook'. ■ Closing the Cookbook Press the 'Cookbook' button. Result: The 'Cookbook' is closed. -
Page 38: The Workflow For A Multistep Cooking Profile
5 Working with the cookbook 5.7 The workflow for a multistep cooking profile Requirements You have opened a multistep cooking profile from the 'Cookbook'. ■ Following a prompt, you have preheated or cooled down the cooking chamber. ■ You have placed food in the cooking chamber. ■... -
Page 39: Cleaning Using Easydial
6 Cleaning using easyDial 6 Cleaning using easyDial Purpose of this chapter The 'Cleaning' function offers a choice of cleaning profiles for oven cleaning. Before starting a cleaning process, you must always be familiar with the rules and hazard warnings in the user manual that relate to safe working during cleaning, and you must follow the instructions given there. - Page 40 6 Cleaning using easyDial Further steps: Start the cleaning profile; see page 41 to find out how ■ Close cleaning; see page 42 to find out how ■ The workflow for semi-automatic oven cleaning, see page 43 ■ The workflow for oven cleaning without cleaning agent, see page 45 ■...
-
Page 41: Starting The Cleaning Process
6 Cleaning using easyDial 6.2 Starting the cleaning process Requirements Before running a cleaning profile, you have familiarized yourself with the rules and hazard warnings ■ given in the user manual that relate to working safely during cleaning, and you follow the instruc‐ tions given there. -
Page 42: Closing The Cleaning Function
6 Cleaning using easyDial 6.4 Closing the Cleaning function Requirements You have selected a cleaning profile. ■ Closing the Cleaning function Press the 'Clean' button. Result: You have closed the 'cleaning' function. -
Page 43: The Workflow For Semi-Automatic Oven Cleaning
6 Cleaning using easyDial 6.5 The workflow for semi-automatic oven cleaning Requirements The oven door is closed. ■ The cleaning profile for semi-automatic oven cleaning has been selected. ■ The cleaning profile is running. ■ The cleaning workflow Removal of food Before the cleaning process starts for semi-auto‐... - Page 44 6 Cleaning using easyDial Prompt to rinse out with water When cleaning phase 2 has finished, a signal beeps and the prompts to 'Open the appliance door' and 'Rinse with water' light up. Rinse with water While you are rinsing the cooking chamber with water, the prompts to 'Close the appliance door' and 'Rinse with water' are illuminated.
-
Page 45: The Workflow For Oven Cleaning Without Cleaning Agent
6 Cleaning using easyDial 6.6 The workflow for oven cleaning without cleaning agent Requirements The appliance door is closed. ■ The cleaning profile for oven cleaning without cleaning agent has been selected. ■ The cleaning profile is running. ■ The cleaning workflow Removal of food Before the cleaning process starts for oven clean‐... -
Page 46: The Workflow For Convoclean Fully Automatic Oven Cleaning
6 Cleaning using easyDial 6.7 The workflow for ConvoClean fully automatic oven cleaning Requirements The appliance door is closed. ■ A cleaning profile for ConvoClean fully automatic oven cleaning has been selected. ■ The cleaning profile is running. ■ The cleaning workflow Removal of food Before the cleaning process for ConvoClean fully automatic oven cleaning begins, all food must be... -
Page 47: The Workflow For Convoclean Fully Automatic Oven Cleaning Using Single-Measure
6 Cleaning using easyDial 6.8 The workflow for ConvoClean fully automatic oven cleaning using single- measure dispensing Requirements The appliance door is closed. ■ A cleaning profile for ConvoClean fully automatic oven cleaning has been selected. ■ The cleaning profile is running. ■... - Page 48 6 Cleaning using easyDial Cleaning phase 2 Cleaning phase 2 (washing cycle) of ConvoClean fully automatic oven cleaning using single-measure dispensing begins after you close the appliance door. The remaining cleaning time is displayed. The C-Dial shows a yellow light. Prompt to add the rinse aid When cleaning phase 2 has finished, a signal beeps and the prompt to 'Open the appliance door'...
-
Page 49: Making Settings Using Easydial
7 Making settings using easyDial 7 Making settings using easyDial Purpose of this chapter You can use the 'Settings' function to make various appliance settings for your combi oven. This chap‐ ter contains step-by-step instructions for making essential 'Settings'. 7.1 Setting the date, time and temperature display Setting the date, time, temperature display and volume Press and hold the C-Dial until 'Adj' and 'd' for day appears in the display. - Page 50 7 Making settings using easyDial Press the C-Dial briefly to close the 'Settings' func‐ tion. Result: The 'Settings' are saved.
-
Page 51: Data Import/Export
8 Data import/export 8 Data import/export Purpose of this chapter You can use the Import/Export functions to make various appliance settings for your combi oven. You need the USB port on your combi oven to import and/or export data. This is located on the easyDial control panel. -
Page 52: Closing The Import/Export Functions
8 Data import/export Opening and running Import/Export functions Press the 'Cookbook' button. Turn the C-Dial to select one of the Import/Export functions, e.g. 'Pro In'. Press the C-Dial to run the selected Import/Export function, e.g. 'Pro In'. 8.2 Closing the Import/Export functions Requirements The USB stick is inserted. -
Page 53: The Workflow For Exporting Haccp Data
8 Data import/export 8.3 The workflow for exporting HACCP data Requirements The USB stick is inserted. ■ The function has been opened and is running. ■ The export workflow HACCP data are exported The appliance starts exporting the HACCP data to the USB stick. -
Page 54: The Workflow For Importing/Exporting A Cookbook
8 Data import/export 8.4 The workflow for importing/exporting a cookbook Requirements The USB stick is inserted. ■ The Import/Export function has been opened and is running. ■ The import/export workflow Data in the cookbook is imported/exported The appliance starts importing/exporting the data. The C-Dial flashes blue. -
Page 55: The Workflow For Importing A Cleaning Profile
8 Data import/export 8.5 The workflow for importing a cleaning profile Requirements The USB stick is inserted. ■ The Import function has been opened and is running. ■ The import workflow The cleaning profile data is imported The appliance starts importing the data for the se‐ lected cleaning profile. -
Page 56: The Workflow For Importing A Software Update
8 Data import/export 8.6 The workflow for importing a software update Requirements The USB stick is inserted. ■ The update function has been opened and is running. ■ The workflow for a software update The software update is performed The appliance starts the software update and im‐ ports the data from the USB stick. - Page 58 Item no. Order no. Additional technical documentation can be found in the download center at : www.convotherm.com Welbilt off ers fully-integrated kitchen systems and our products are ® backed by KitchenCare aftermarket parts and service. Welbilt’s portfolio of award-winning brands includes Cleveland™, Convotherm , Delfi...
