Stellaris® Intelligent Display Module
Single-Board Computer (IDM-SBC)
Reference Design Kit
User 's Manual
RDK-IDM-SBC-UM-05
Co pyrigh t © 2 009– 201 1 Te xas In strumen ts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stellaris RDK-IDM-SBC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Texas Instruments Stellaris RDK-IDM-SBC

  • Page 1 Stellaris® Intelligent Display Module Single-Board Computer (IDM-SBC) Reference Design Kit User ’s Manual RDK-IDM-SBC-UM-05 Co pyrigh t © 2 009– 201 1 Te xas In strumen ts...
  • Page 2 Copyright Copyright © 2009–2011 Texas Instruments, Inc. All rights reserved. Stellaris and StellarisWare are registered trademarks of Texas Instruments. ARM and Thumb are registered trademarks, and Cortex is a trademark of ARM Limited. Other names and brands may be claimed as the property of others.
  • Page 3: Table Of Contents

    Stellaris® IDM Single-Board Computer Table of Contents Chapter 1: Stellaris® Intelligent Display Module Single-Board Computer RDK Overview ......9 Kit Contents ..............................10 Using the RDK ..............................10 Features................................11 Board Overview ..............................12 Board Specifications ............................. 12 Chapter 2: Hardware Description ........................13 Block Diagram ..............................
  • Page 4 November 28, 2011...
  • Page 5 Stellaris® IDM Single-Board Computer List of Figures Figure 1-1. Intelligent Display Module Single-Board Computer................. 9 Figure 1-2. IDM-SBC Board Overview Diagram ....................12 Figure 2-1. Intelligent Display Module Single-Board Computer Block Diagram ..........13 Figure 2-2. Debug Connection Pinout ......................14 Figure 2-3.
  • Page 6 November 28, 2011...
  • Page 7 Stellaris® IDM Single-Board Computer List of Tables Table 2-1. LCD-Related Signals........................17 Table 2-2. I S Audio-Related Signals......................18 Table 2-3. CAN-Related Signals ........................18 Table 2-4. Serial Flash and microSD-Related Signals ................... 19 Table B-1. RDK-IDM-SBC Bill of Materials (BOM) ..................29 November 28, 2011...
  • Page 8 November 28, 2011...
  • Page 9: Chapter 1: StellarisĀ® Intelligent Display Module Single-Board Computer Rdk Overview

    C H A P T E R 1 Stellaris® Intelligent Display Module Single-Board Computer RDK Overview The Stellaris® Intelligent Display Module Single-Board Computer (RDK-IDM-SBC) is a reference design for a complete QVGA touch-screen user interface for control, automation, and instrumentation applications. The design features the powerful Tempest-class LM3S9B92 microcontroller.
  • Page 10: Kit Contents

    IAR Embedded Workbench Code Sourcery GCC development tools Code Red Technologies development tools Texas Instruments’ Code Composer Studio™ IDE Using the RDK The recommended steps for using the RDK are: Follow the Quickstart guide included in the kit. The Quickstart guide will help get the display module up and running in minutes.
  • Page 11: Features

    – Develop using tools supporting Keil™ RealView® Microcontroller Development Kit (MDK-ARM), IAR Embedded Workbench, Code Sourcery GCC development tools, Code Red Technologies development tools, or Texas Instruments’ Code Composer Studio™ IDE (using a Stellaris evaluation kit or preferred ARM Cortex-M3 debugger) –...
  • Page 12: Board Overview

    Stellaris® Intelligent Display Module Single-Board Computer RDK Overview Board Overview Figure 1-2 shows an overview of the board. Figure 1-2. IDM-SBC Board Overview Diagram Audio Connector Flex cable to LCD Touch Panel I2S Audio CODEC Integrated Power supply Power and Ground Test JTAG/SWD Connector Points...
  • Page 13: Chapter 2: Hardware Description

    C H A P T E R 2 Hardware Description The IDM-SBC design uses a Stellaris® LM39B92 microcontroller to handle display functions, touch-screen control, Ethernet, USB, CAN, and other peripheral functions. Only a few additional ICs are necessary to complete the design. The entire circuit is built on a compact four-layer printed circuit board.
  • Page 14: Functional Description

    Hardware Description Functional Description This section describes the IDM-SBC’s hardware design in detail. Microcontroller The Stellaris LM39B92 is an ARM Cortex-M3-based microcontroller with 256-KB flash memory, 80-MHz operation, Ethernet, USB, EPI and a wide range of peripherals. See the LM39B92 data sheet (order number DS-LM39B92) for complete device details.
  • Page 15: Power And Interface Terminal Block

    Stellaris® IDM Single-Board Computer Power and Interface Terminal Block Power, CAN, and I C interfaces are provided through 3.5 mm pluggable terminal blocks. For convenience, the RDK includes the plugs. See the BOM for complete part numbers. Figure 2-4. Pluggable Terminal Blocks I2C is a short-distance intra-device bus that can be used to add capabilities such as an ADC (for analog measurement) or digital inputs and outputs.
  • Page 16: Power Supplies

    Hardware Description Power Supplies The RDK-SBC has a wide input range switching-power supply that creates a 5V 1A rail for board operation. The LM22672 step-down regulator switches at 500KHz with an efficiency of greater than 90%. Board functions require only about 150 mA with the remaining capability available for external interfaces such as USB host.
  • Page 17: Table 2-1. Lcd-Related Signals

    Stellaris® IDM Single-Board Computer Control Interface The Color LCD module has a built-in controller IC with a multi-mode parallel interface. The EVB uses an 8-bit 8080 type interface with GPIO Port D providing the data bus. Table 2-1. LCD-Related Signals Microcontroller Pin Board Function PE6/ADC1...
  • Page 18: I 2 S Audio

    Hardware Description S Audio The IDM-SBC has advanced audio capabilities using an I2S-connected Wolfson WM8510 CODEC. The CODEC’s integrated amplifier can directly drive an 8 Ω speaker. Although the CODEC supports a microphone input, pin count limits on the LM3S9B92 result in this feature being unconnected.
  • Page 19: Table 2-4. Serial Flash And Microsd-Related Signals

    Stellaris® IDM Single-Board Computer (Serial Peripheral Interface) bus. These memories are typically used for data storage and for large code images which are copied into SDRAM for execution. Table 2-4. Serial Flash and microSD-Related Signals Microcontroller Pin Board Function Jumper Name PA2/SSI0CLK Clock from SPI module SCLK...
  • Page 20 Hardware Description November 28, 2011...
  • Page 21: Chapter 3: Software Development

    The source code installation includes directories containing projects and/or makefiles for the following tool-chains: • Keil™ RealView® Microcontroller Development Kit (MDK-ARM) • IAR Embedded Workbench • Code Sourcery GCC development tools • Code Red Technologies development tools • Texas Instruments’ Code Composer Studio™ IDE November 28, 2011...
  • Page 22: Programming The Idm-Sbc

    Software Development Evaluation versions of these tools may be downloaded from www.ti.com/stellaris. Note that, due to code size restrictions, the evaluation versions of the tools may not build all example programs for the IDM. A full license is necessary to re-build or debug all examples. Instructions on installing and using each of the evaluation tools can be found in the Quickstart guides (for example, Quickstart-Keil, Quickstart-IAR) which are available for download from the evaluation kit section of our web site at www.ti.com/stellaris.
  • Page 23 Stellaris® IDM Single-Board Computer To replace the boot loader image or to program example applications into the IDM-SBC using a Stellaris evaluation board to provide JTAG/SWD functionality: 1. Install LM Flash Programmer on a Windows PC. 2. Connect the MDL-ADA2 10-pin to 20-pin adapter (included in the RDK) to the evaluation board ribbon cable.
  • Page 24 Software Development November 28, 2011...
  • Page 25: Appendix A: Schematics

    A P P E N D I X A Schematics This sections contains the schematic diagrams for the Intelligent Display Module Single-Board Computer. IDM-SBC Microcontroller, SDRAM, USB, and Ethernet on page 26 IDM-SBC LCD Panel, Serial Memory, and Audio on page 27 IDM-SBC Power and Interface on page 28 November 28, 2011...
  • Page 26 Schematic page 1 Note: For Rev B1 silicon wire LCD_RDn to +3.3V and Note: Expansion Stellaris Microcontroller PB0 to GND to enable USB Host. UART0 Connections (as shown) are transposed on Rev A PCB. +3.3V I2C_SDA LCD_RDn PA0/U0RX PB1/USB0VBUS I2C_SCL PA1/U0TX PA6/USB0EPEN USB_EPE...
  • Page 27 Schematic page 2 +3.3V +3.3V +3.3V QVGA LCD Panel microSD Card Slot with touch interface 0.1UF 8-bit 8080 mode ILED- SDCARD_CSn LED_K ILED+ SSI0TX +3.3V LED_A 2908-05WB-MG SSI0CLK TOUCH_XP TOUCH_XP SSI0RX TOUCH_YN TOUCH_XN TOUCH_YN TOUCH_YP TOUCH_XN TOUCH_YP 0.01UF 0.01UF 0.01UF 0.01UF +3.3V RESET...
  • Page 28 Schematic page 3 +5V 1A Switching Regulator LED Backlight Controller +VIN ILED+ BOOT 0.01uF ENABLEn NR4018T100M 10uH FYV0704SMTF B82464Z4333M000 Link-0603 4.7UF 50V 33uH 1.0UF BZT52C24 ILED- BLON SHDN 47UF SS26T3G RT/SYNC EXPAD FAN5333B 2.2UF 2.2UF LM22672MR-5.0 61.9K 0.1UF 0.1UF 0.1UF 0.01UF Main +3.3V 300mA Power Supply PQ1LA333MSPQ...
  • Page 29: Appendix B: Bill Of Materials (Bom)

    A P P E N D I X B Bill of Materials (BOM) Table B-1. RDK-IDM-SBC Bill of Materials (BOM) Texas Instruments IDM-SBC Reference Design Rev B Issue 1 Bill Of Materials 3-Nov-09 Item Qty Part Number Description C1, C2, C11, C14, GRM188R71H104KA93D Capacitor, 0.1uF 50V 10% 0603 X7R...
  • Page 30 Table B-1. RDK-IDM-SBC Bill of Materials (BOM) (continued) Item Qty Part Number Description LM22672MRE-5.0/NOP IC, 5V 1A Step-down Switching Reg PSOP8 National TPS2051BDBV IC, Fault protected power switch SOT23-5 FAN5333BSX IC, White LED Driver IC SOT23-5 Fairchild NX5032GA-25.000000MHZ Crystal, 25.00MHz 5.0x3.2mm SMT NX5032GA-16.000000MHZ Crystal, 16.00MHz 5.0x3.2mm SMT BD-IDMSBC-A PCB, FR-4 4-layer ENIG Rev A 2.0"...
  • Page 31: Appendix C: Component Details

    A P P E N D I X C Component Details This appendix contains details on component locations, including: Component placement plot for top (Figure C-1) Figure C-1. Component placement plot for top November 28, 2011...
  • Page 32 November 28, 2011...
  • Page 33 IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete.
  • Page 34 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments RDK-IDM-SBC...
