pottery barn kids




Date: 8‐Aug‐13

Rev:
FARMHOUSE KITCHEN SINK
www. potterybarnkids.com
































Page 1 of 10


Advertisement

loading
Need help?

Need help?

Do you have a question about the FARMHOUSE KITCHEN SINK and is the answer not in the manual?

Questions and answers

Michael E. McLaughlin
February 7, 2025

Where can we get a new sink for our Farmhouse Kitchen Sink Set?

0
1 comments:
Mr. Anderson
February 11, 2025

You can buy a new Pottery Barn Kids Farmhouse Kitchen Sink Set from GoodBuy Gear.

This answer is automatically generated

0

Related Manuals for pottery barn kids FARMHOUSE KITCHEN SINK

Summary of Contents for pottery barn kids FARMHOUSE KITCHEN SINK

  • Page 1                         FARMHOUSE KITCHEN SINK               Date: 8‐Aug‐13 www. potterybarnkids.com                                              ...
  • Page 2 The use of power tools to aid in assembly is not recommended. Power tools can damage hardware and split wood.  The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions. It may take 1.5 hour or more to assembly your Farmhouse Kitchen Sink. Parts Included: Top Panel Bottom Panel...
  • Page 3   Hardware Included: Flat Washer Spring Washer Bolt Dia. 1/4” x 1” Screw Screw Bolt   25mm 12mm Dia. 1/4” x 1-1/2” Tools Required (included): Tools Required (not included): Allen Key 4mm Phillips Head Screwdriver Assembly Instruction Steps: NOTE:  To follow the direction and position of illustrations could avoid wrong assembly.
  • Page 4   1. Attach Legs (G and H) to Bottom Panel (B) using Bolt (V), Spring Washer (R) and Flat Washer (Q). Loosely tighten the bolts, and then tighten with Allen Key. Dia. 1/4” x 1-1/2”   Arrow to Front 2. Attach Front Panel (E) to the Right Side Panel (D) using the Bolt (S), Spring Washer (R) and Flat Washer (Q). Loosely tighten the bolts, and then tighten with Allen Key.
  • Page 5   3. Attach Left Side Panel (C) to Front Panel (E) using Bolt (S), Spring Washer (R) and Flat Washer (Q). Loosely tighten the bolts, and then tighten with Allen Key.   Dia. 1/4” x 1”          ...
  • Page 6   5. Slide Back Panel (L) into grooves on Side Panels (D and C) and Bottom (B) as shown.   6. Attach Apron (J) to Back Top (K) using Bolt (S), Spring Washer (R) and Flat Washer (Q). Loosely tighten the bolts, and then tighten with Allen Key.
  • Page 7   7. Attach assembly in step 6 to Top Panel (A) using Bolt (S) and Spring Washer (R) and Flat Washer (Q). Loosely tighten the bolts, and then tighten with Allen Key. Secure Back top using Screw (T) with Phillips Head Screwdriver. Countersink hole towards bolt Dia.
  • Page 8   9. Attach assembly in step 8 to assembly in step 5, carefully turn it onto its side lying on ground. Insert Bolts (S), Spring Washer (R) and Flat Washer (Q) as shown. Loosely tighten the bolts, and then tighten with Allen Key. Dia.
  • Page 9   11. Place Sink (I) in cutout on Top Panel (A). 12. Insert the Curtain Rail (F) into the Curtain (P) as shown. Date: 8‐Aug‐13 www. potterybarnkids.com                                               Page 9 of 10  ...
  • Page 10   13. Plug one end of Curtain Rail (F) into the hole at Right Side Panel (D), and then put other end onto the notch on Left Side Panel (C). Adjusting the levelers: Due to an uneven floor, the furniture may not sit level due causing it to wobble. If the furniture wobbles, determine which corner does not touch the ground correctly.
