Merak MMk-736 Installation Manual

Gsm/m2m gateway for lifts
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION
MANUAL
MMk-736
GSM/M2M
Gateway
for Lifts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMk-736 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Merak MMk-736

Summary of Contents for Merak MMk-736

  • Page 1 INSTALLATION MANUAL MMk-736 GSM/M2M Gateway for Lifts...
  • Page 2 GSM/M2M Gateway for Lifts General information The GSM Gateway MMk-736 is a device especially designed for the lift industry, which provides analogue emergency phones with mobile telephone lines. It is manufactured with cutting-edge technology and is in line with current security standards. The manual herein lists the mandatory instructions for the correct connection and commissioning of the equipment.

  • Page 3: Table Of Contents

    Example 2: Notify an excessive number of calls ............... 16 6.2.3. Example 3: Notify incidents in the equipment power supply and battery ....... 16 6.3. Restore factory settings ..........................16 Rev. M1.0.3 - F1.0.3 © Merak. All rights reserved Installation Manual 3 of 16...

  • Page 4: General Characteristics

    GSM/M2M Gateway for Lifts GENERAL CHARACTERISTICS The GSM gateway MMk-736 is a device especially designed for the lift industry, which provides analogue emergency phones with mobile telephone lines. It manages voice calls and transmits data through mobile IP technology for remote monitoring and home automation applications (M2M).

  • Page 5: Characteristics

    MMk-736 MERak GSM/M2M Gateway for Lifts 1.3. Characteristics The main features of the MMk-736 are listed below:  It transmits data for remote monitoring and home automation applications (M2M)  Internal security battery which works in the event of power failure ...

  • Page 6: Installation And Commissioning

    GSM/M2M Gateway for Lifts INSTALLATION AND COMMISSIONING The following steps need to be carried out for the commissioning of the MMk-736: 2.1. Installation of the SIM card Before starting up the equipment, it is necessary to install a SIM card so that it can make calls.
  • Page 7 Once registered, the status indicator will switch off and flicker every two seconds. Furthermore, once registered, the coverage indicators will light up, indicating the signal level received. Rev. M1.0.3 - F1.0.3 © Merak. All rights reserved Installation Manual 7 of 16...

  • Page 8: Status Indicators, Battery And Coverage

    MMk-736 MERak GSM/M2M Gateway for Lifts STATUS INDICATORS, BATTERY AND COVERAGE The MMk-736 has 5 luminous status indicators. LED 1: STATUS INDICATOR  Steady light: operating equipment, NOT registered in the GSM network.  Slow flicker (2 sec.): operating, registered in the GSM network and on standby.

  • Page 9: Connections

    GSM/M2M Gateway for Lifts CONNECTIONS The MMk-736 has a group of communication ports that provide remote access to various types of devices, allowing for it to be monitored and controlled (for more information regarding how to access these ports, refer to the M2M Communication Manual).

  • Page 10: Can2

    3-pin terminal block (pitch 3.5mm). It allows the control panel to be connected to the device to remotely access it via CSD and/or GPRS connections. For more information, refer to the MMk-736 - M2M Communication Manual. 4.5. CAN1 3-pin terminal block (pitch 3.5mm).

  • Page 11: Operation

    When the equipment connected to this output picks up, the call origin can transmit characters associated to the set of DTMF tones (0..9, *, #, A, B, C, D), which the MMk-736 converts into audible DTMF tones in the simulated analogue telephone line output.
  • Page 12 MMk-736 MERak GSM/M2M Gateway for Lifts The following diagram shows the behaviour of the MMk-736 and the possible application of these diversions. Figure 4.1: Flow of outgoing calls Rev. M1.0.3 - F1.0.3 © Merak. All rights reserved Installation Manual 12 of 16...

  • Page 13: Control Of Excessive Number Of Calls

    MMk-736 will send a notification of an excessive number of calls. Once this limit is surpassed, the MMk-736 will send an SMS alert each time that a call is made from the equipment.

  • Page 14: Programming The Call Diversion Table

    6.1. Programming the call diversion table The MMk-736 can be instructed to divert a call dialled by the tele-alarm, to a different number, according to the number dialled. It is even possible to activate an unconditional diversion so that, independently of the number dialled, all calls are made to the desired phone number.

  • Page 15: Example 1: Diversion Of A Single Voice Call Number

    93631428: This is indicated with the symbol * in register number 1. PROGGSM s 0000 1:* 2:93933631428 6.2. Programming the activation of notifications It is possible to configure the MMk-736 to send a notification by SMS when one of the following events takes place: ...

  • Page 16: Example 2: Notify An Excessive Number Of Calls

    PROGGSM s 0000 47:0 6.2.2. Example 2: Notify an excessive number of calls We tell the MMk-736 to send an SMS to the number 630888343 when more than 20 calls are made in 1440 minutes (one day). PROGGSM s 0000 31:630888343 54:20 55:1440...
