After the chain saw mounting kit has been fi tted and when the equip-
ment is not being used, slip the cutter guard (Fig. 1/Item 18) over the
mounted cutter bar with saw chain in order to prevent injuries.
5.3 Fitting the chain saw mounting kit to the motor head (Fig.
12 – 13)
The cutter guard must be slipped over the mounted cutter bar with
saw chain in order to prevent injuries.
1. Position the chain saw mounting kit and the motor head such that
the arrows on both parts coincide.
2. Press the chain saw mounting kit against the motor head. This will
cause the lock button (R) to be pushed to the right. Turn the chain
saw mounting kit clockwise. The chain saw mounting kit will lock
onto the motor head and is then secured in place. This will cause
the lock button (R) to be pushed to the left.
5.4 Turning the chain saw mounting kit through 90° on the mo-
tor head (Fig. 14)
The cutter guard must be slipped over the mounted cutter bar with
saw chain in order to prevent injuries.
GB
1. Pull the lock button (R) to the right.
2. Turn the chain saw mounting kit 90° counter-clockwise. The chain
saw mounting kit will lock onto the motor head and is then secu-
red in place.
5.5 Removing the chain saw mounting kit from the motor head
(Fig. 12 – 13)
The cutter guard must be slipped over the mounted cutter bar with
saw chain in order to prevent injuries.
1. Pull the lock button (R) to the right.
2. Turn the chain saw mounting kit to the point where the arrows on
the motor head and chain saw mounting kit coincide, allowing the
mounting kit to be removed.
