4. Technical data

Cutter bar length: ................................................................. 200 mm
Max. cutting length: .............................................................. 170 mm
Chain pitch: .................................................................. 3/8", 33 teeth
Chain thickness: ....................................................... (0.050") 1.3 mm
Sprocket wheel: ............................................................. 6 teeth, 3/8"
Cutting speed
at rated rpm: .........................................................................3.76 m/s
Oil tank capacity: .................................................................. 125 cm
Net weight without accessories: ............................................... 3.4 kg
Saw chain: ............................................................ Oregon 91P033X,
.....................................................................Kangxin 3/8 8050X33DL
Cutter bar: ...................................... Oregon 080NDEA041 (520089),
...................................................................... Kangxin AP08-33-507P
Important!
The equipment is supplied without batteries and without a charger is
allowed to be used only with the lithium-ion batteries of the PE-Pow-
er-X-Change series!
PE-Power-X-Change
•
18 V, 1.5 Ah 5 lithium-ion cells
•
18 V, 3.0 Ah 10 lithium-ion cells
•
18 V, 4.0 Ah 10 lithium-ion cells
The lithium-ion batteries of the PE-Power-X-Change series are allo-
wed to be charged only with the PE-Power-X charger.
