Compound Security Systems Mosquito MK4 Additional Setup Instructions

Download this manual

mosquito-mk4-setup-instructions.indd 1

09/06/2017 14:00:50

Need help?

Do you have a question about the Mosquito MK4 and is the answer not in the manual?

Page 1 mosquito-mk4-setup-instructions.indd 1 09/06/2017 14:00:50...
Page 2: Additional Setup Instructions
Compound Security Systems Ltd. MOUNTING. The Mosquito MK4 housing has a louvered front (see below). It is VERY important to note when installing the Mosquito that the louvers project the sound down at a 45 degree angle. This means that if you mount the Mosquito directly on to a wall, the sound will project down at 45 degrees.
Page 3 Compound Security Systems Ltd. POWER CONNECTION Most people purchase a 15v AC power supply with their Mosquito MK4. If you have not ordered a power supply with your Mosquito, you can either obtain one from our website or purchase one from your local electrical wholesaler. If purchasing from a wholesaler, you must specify either a 15v AC or 24v DC power supply rated at 800mA.
Page 4: Dip Switch
Compound Security Systems Ltd. Compound Security Systems Ltd. DIPSWITCH #1. TRIGGER CONNECTION (WITH FUNCTION CHIP #3 FITTED) This is ONLY used when a PIR (movement sensor) or Remote Control is being used to If you wish to use a Pro. Remote control to trigger the activation / deactivation of the activate the Mosquito.
Page 5 Email: post@compoundsecurity.com www.compoundsecurity.com mosquito-mk4-setup-instructions.indd 8 09/06/2017 14:00:51...
