Description
1. Power: Indicator light. If this light is on and solid then the Zone Processor has power. If this light is flashing then the Zone Processor
is in Discovery Mode.
2. DC5V: Connect the supplied power supply to this port to provide power to the Zone Processor.
3. Serial Port: Connect a serial cable to this port to send RS232 commands to a compatible device.
4. IR (OUT): Connect an IR TX to the "IR (OUT)" to enable remote (IR) control of any AV device local to the Zone Processor.
5. LAN: Connect an Ethernet cable from your router to allow the Zone Processor access to the LAN.
6. WiFi: Connect the detachable WiFi aerial to connect to LAN over WiFi.
Enabling operation over WiFi:
The ZP1 ships with Ethernet mode active by default meaning that connection over WiFi will not automatically work. To enable WiFi
connectivity you must first connect the ZP1 to your LAN via an Ethernet cable and then use uControl to put the ZP1 into Discovery
Mode. Refer to "Power up & setup in uControl" instructions on page 14.
