- Page 1 Models 2001TRBP, 2001TRBP-480, and 2001TRBP KIT Transformer Rectifier Description and Specifications Manual 2561831 Rev. B2 1018 Printed in U.S.A. © Copyright 2013-2018 Federal Signal Corporation...
- Page 2 A copy of this limited warranty can also be obtained by written request to Federal Signal Corporation, 2645 Federal Signal Drive, University Park, IL 60484, email to info@fedsig.com or call +1 708-534-3400.
-
Page 3: Table Of Contents
Table 5 2001TRBP Kit Contents* ......................8 Table 6 2001TRBP and 2001TRBP-480 Contents ................. 8 Figures Figure 1 Models 2001TRBP and 2001TRBP-480 Transformer Rectifier ..........6 Figure 2 Schematic Diagram 2001TRBP ....................9 Figure 3 Schematic Diagram 2001TRBP-480 ..................10 Figure 4 Transformer Rectifier Wiring to Control Cabinet .............. -
Page 4: Safety Messages
Activating the sirens may not result in people taking the desired actions if those to be warned are not properly trained about the meaning of siren sounds. Siren users should follow FEMA recommendations and instruct those to be warned of correct actions to be taken. 2001TRBP, 2001TRBP-480, and 2001TRBP Kit Transformer Rectifier... - Page 5 Safety Messages • After installation, service, or maintenance, test the siren system to confirm that it is operating properly. Test the system regularly to confirm that it will be operational in an emergency. • If future service and operating personnel do not have these instructions to refer to, the siren system may not provide the intended audible warning and service personnel may be exposed to death, permanent hearing loss, or other bodily injury.
-
Page 6: General Description
The 2001TRBP is a high-power transformer rectifier for powering outdoor warning sirens. The 2001TRBP consists of an aluminum encased transformer with mounting bracket. The 2001TRBP can be used as the only source of power for mechanical sirens (AC operation). The 2001TRBP transformer operates from 208, 220, or 240 Vac, while the 2001TRBP-480 operates from 416, 440, or 480 Vac. -
Page 7: Features
Specifications Features The 2001TRBP and 2001TRBP-480 transformer rectifier has the following features. • High-powered transformer rectifier for powering mechanical sirens from nominal 220 Vac (2001TRBP) or nominal 440 Vac (2001TRBP-480) • Provides primary system power (46 Vdc) for DC sirens •... -
Page 8: Unpacking The Kit
7011A069-08 Brass washer 70700520 2 position buss bar 8402109A Buss bar rt angle 8402138A NOTE: The 2001TRBP Kit is for installations that already have an existing transformer. Table 6 2001TRBP and 2001TRBP-480 Contents 2001TRBP 2001TRBP-480 2001TRBP Service Description includes includes... -
Page 9: Locating The Transformer
Mount the transformer assembly as close as possible to the control unit to keep cabling distances as short as possible. See Figure 1 and Table 4 for size and weight of the 2001TRBP transformer. Mount the 2001TRBP to a structure that can support the transformer. -
Page 10: Figure 3 Schematic Diagram 2001Trbp-480
Figure 3 Schematic Diagram 2001TRBP-480 FUSED POWER SOURCE 115 VAC 440 VAC 46 VDC 480 VAC ~100 VAC 416 VAC ~50 VAC Figure 4 Transformer Rectifier Wiring to Control Cabinet F1F2 10 10 2001TRBP and 2001TRBP-480 2001TRBP, 2001TRBP-480, and 2001TRBP Kit Transformer Rectifier... -
Page 11: Troubleshooting
Troubleshooting Troubleshooting NOTE: It is normal for the 46 Vdc output of the transformer to have 20-30 Vrms of AC ripple without load. With load the AC ripple significantly decreases. If the 46 Vdc output of the transformer is about half of 46 Vdc, typical cause is a defective Diode Rectifier or Transformer. - Page 12 2645 Federal Signal Drive University Park, Illinois 60484-3167 www.fedsig.com Customer Support 800-548-7229 • +1 708 534-3400 Technical Support 800-524-3021 • +1 708 534-3400...
