BELTTT BEP150S Manual

Product detail parameters
M O D E L BEP150S BEP300A BEP500SA
Rated Power 150W 300W 500W
Peak Power 300W 600W 1000W
Output
Frequency
WaveForm
Battery 12V / 24V
12V / 24V / 48V(Optional)
Voltage (Optional)
Voltage
10-15V(12V) / 20-30V(24V) / 40-60V(48V)
Range
Input 0.8A(12V) 0.8A(12V)
0.6A(12V)
No load
0.6A(24V) 0.6A(24V)
Current 0.3A(24V)
0.3A(48V) 0.3A(48V)
Efficiency
≥90%
11(12V) / 21V(24V) / 42V(48V)
Low Voltage Alarm
Battery low
10V±0.5V(12V) / 20V±0.5V21V(24V) / 40V±0.5V(48V)
Battery
voltage protection
input
Battery high
protection
15V±0.5V(12V) / 30V±0.5V21V(24V) / 60V±0.5V(48V)
voltage protection
Battery reverse
NO YES YES
polarity protection
Other protection
High temperature protection、Shortcircuit Protection、Overload Protection
5V / 500mA
USB
FAN
Smart fan,Automatic startup of high temperature and load
Operating
Temperature 0℃~40℃@100%load, Humidity 20%~90%RH,No refrigeration
environment
S ize ( mm )
160*95*55 172*150*58 260*150*78
W eight ( g )
530 910 1700
M O D E L BEP1000S BEP1500S BEP2000S BEP3000S BEP5000S
Rated Power 1000W 1500W 2000W
Peak Power 2000W 3000W 4000W
Output
50Hz / 60Hz(Optional)
Frequency
WaveForm Pure Sine Wave
Battery
12V / 24V / 48V(Optional)
Voltage
Voltage
10-15V(12V) / 20-30V(24V) / 40-60V(48V)
Range
Input 0.8A(12V) 1.8A(12V) 3.0A(12V)
No load
0.6A(24V) 1.0A(24V) 1.5A(24V)
Current
0.3A(48V) 0.5A(48V) 0.8A(48V)
Efficiency ≥90%
11(12V) / 21V(24V) / 42V(48V)
Low Voltage Alarm
Battery low
10V±0.5V(12V) / 20V±0.5V(24V) / 40V±0.5V(48V)
Battery
voltage protection
input
Battery high
protection
15V±0.5V(12V) / 30V±0.5V(24V) / 60V±0.5V(48V)
voltage protection
Battery reverse
NO
polarity protection
Other protection
High temperature protection、Shortcircuit Protection、Overload Protection
5V / 500mA
USB
FAN Smart fan,Automatic startup of high temperature and load
Operating
Temperature 0℃~40℃@100%load, Humidity 20%~90%RH,No refrigeration
environment
S ize ( mm )
367*150*76 452*150*142 454*180*142 529*180*142
W eight ( g )
2750 4000 4900
Remarks：Please select the corresponding parameters according to the
This series of pure sine wave inverter is suitable for :
Household appliances: TV, refrigerator, freezer, washing machine, air conditioner, power
amplifier, induction cooker, electric fan, electric cooker Lamps and lanterns, AV equipment......
Power tools: electric drills, pumps, cutting machines, motors, hand mills......
Office equipment: computers, printers, copiers, fax machines, network equipment......
On-board equipment：inverter can be connected to the car capacitor, suitable for all kinds
of on-board appliances.
BEP600S BEP800S
600W 800W 800W
WARNING
1200W 1600W
Inammable gas
●When connected to a battery, sparks are produced. Make sure there is no ammable
gas before connecting.
●The battery will produce ammable gas when charging and discharging. It should be
0.8A(12V) well ventilated and should not be stored in other places where it is ammable
0.6A(12V)
0.6A(24V)
0.3A(24V)
No parallel with city power
0.3A(48V)
The output can not be paralleled with the power supply, it will damage the inverter and
cause the danger of electric shock。
Minors are prohibited from using them
Can not be used by minors, inverter output is high voltage, may lead to electric shock
risk。
YES NO
No disassembly or assembly
Do not disassemble or modify the inverter without permission. Unauthorized removal
or modication of the inverter may result in a safety accident such as a malfunction,
re or electric shock。
Bar contacts are prohibited
Do not place bars or other metal objects at the opening or socket of the inverter. This
may touch the internal parts and cause electric shock and inverter damage
262*150*76 309*180*172
Wet hands, do not touch
1800 3050 Do not touch the body and plug with wet hands, which may cause electric shock and
personal safety
Keep away from re and high temperatures
Fire and explosion can occur in inverter and battery when running in ame and high
3000W 5000W
temperature region。
6000W 10000W
No throwing
Bumping the inverter can cause damage and other safety hazards.
12V / 24V
(Optional)
Medical equipment disabled
This inverter has not been tested and can not be used in medical equipment
3.8A(12V)
2.5A(24V)
2.0A(24V)
1.4A(48V)
Please connect the ground wire.
1.2A(48V)
In order to ensure the safety of use, please connect the ground wire.
Moisture proof and waterproof
Please pay attention to moisture proof
and waterproof. The inverter may cause
short circuit, re and electric shock due
to humidity or water inow。
585*180*167
6020 8000
Product characteristics
●The inverter is equipped with perfect protection circuit. Provide safe
automatic shutdown function, including overload protection, input
high-low voltage protection, to prevent damage to your inverter ;
●The inverter has advanced anti-interference technology, fully functional
protection circuit and soft start circuit, convenient operation mode;
●modify the string wave output, inverter provides AC, USBoutput interface;
●instantaneous power up to 1000W, efficiency as high as 94%.
To avoid harm to you and others, here are
some of the following security considerations.
Be sure to follow the meanings of the various
flags. See the following.
Please insert completely
Please insert the load device plug into
the inverter socket completely. If the
plug is fully inserted at the end, it may
lead to electric shock and overheating,
and even cause a re accident. Do not
use damaged plugs, power outlets,
electrical wires。
Power Inverter
Solar Power Generation System
BEP150S / BEP300A / BEP500SA
BEP600S / BEP800S / BEP1000S
BEP1500S / BEP2000S
BEP3000S / BEP5000S
Pure Sine Wave
Inverter Manual
To ensure reliable ser vice, the inverter must be used properly.
Please read the instruction manual before use. Par ticular
attention should be paid to the warning and attention of this
brochure. Caution for certain conditions and practices that may
cause damage to the inverter. Make clear warning statements
about certain conditions and practices that may cause bodily
harm. Please read all instructions before using the inverter.
Please read this instruction manual carefully so that it can be
used correctly. Remember to read the "safety precautions"
section before you use it to make sure it's safe to use. After
reading the instructions, please complete the warranty card for
safekeeping, to keep on for reference.
