TP-Link TL-WR810N V3 Quick Installation Manual

Quick Installation Guide
300Mbps Wi-Fi Pocket Router/AP/
TV Adapter/Repeater
*TL-WR810N (European version) is used
for demonstration in this QIG.
Standard Wireless Router
Internet
C
Access Point
Internet
C
Wired Router
Operation Mode
Install the plug and choose the operation mode of the router as needed.
Mode Switch
A
B
LAN/WAN LAN
A
B
LAN/WAN
Operation Modes Application
Standard Wireless Router To share a wired (Ethernet) connection to wireless devices, when in a
hotel room, small office and so on.
Access Point To transform an existing wired (Ethernet) network to a wireless one.
Repeater To extend the range of an existing Wi-Fi network.
Client To enable your wired device (such as Blu-ray® players, smart TVs, or
game consoles) to connect to a Wi-Fi network.
1 Switch the Operation Mode to Router/AP and connect the hardware
according to Step A to C in the left diagram.
2 Connect your device to the router wirelessly or via an Ethernet
cable. The SSID (Network Name) and Wireless password are on the
router's label.
3 Launch a web browser and type http://tplinkwifi.net in the address
bar. Enter admin (in lowercase) for both username and password to
log in.
4 Click Next to start the Quick Setup. Select Standard Wireless
Router and click Next.
OR
5 Select the WAN Connection Type and follow the instructions. When
using the router in a hotel room or a small office, select Dynamic IP.
Note: If the router is successfully connected to internet, this step will be skipped.
6 On the Wireless page, either customize your Wireless Network
Name and Wireless Password or keep the default ones, and then
click Next.
7 Click Finish to complete the configuration.
1 Switch the Operation Mode to Router/AP and connect the hardware
according to Step A to C in the left diagram.
2 Connect your device to the router wirelessly or via an Ethernet
cable. The SSID (Network Name) and Wireless password are on the
router's label.
3 Launch a web browser and type http://tplinkwifi.net in the address
bar. Enter admin (in lowercase) for both username and password to
log in.
4 Click Next to start the Quick Setup. Select Access Point and click
Next.
5 Either customize your Wireless Network Name and Wireless
Password or keep the default ones, and then click Next.
6 Select the LAN IP type of the router or leave the default setting
Smart IP for most cases, and then click Next.
7 Click Reboot to complete the configuration.
