Arrowhead Alarm Products ELITE S V9 Program Manual

8/16 zone control communicator
Hide thumbs Also See for ELITE S V9:
Table of Contents

Advertisement

Quick Links

V9
ELITE S Version
(8/16 Zone Control Communicator)
Arrowhead
Alarm Products Ltd
Program Summary
Guide
Proudly D e si g n e d and Manufactur e d in N e w Z e aland

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELITE S V9 and is the answer not in the manual?

Questions and answers

Related Manuals for Arrowhead Alarm Products ELITE S V9

Summary of Contents for Arrowhead Alarm Products ELITE S V9

  • Page 1 ELITE S Version (8/16 Zone Control Communicator) Arrowhead Alarm Products Ltd Program Summary Guide Proudly D e si g n e d and Manufactur e d in N e w Z e aland...
  • Page 2 ELITE S PROGRAM SUMMARY GUIDE +++++Users+++++ Programming User Codes 1-100E User Code 1-100 - Default for User Code # 1 (P1E1E) = 123 Codes can be 1-6 or 4-6 digits (where 1E = User Code #1 to 100E = User Code #100) NOTE: The 100 Users can be keypad Code, Radio or Access key Users.
  • Page 3 Radio Pendant Panic Beeps to Keypad P11E 21-100E Radio # 21-100 Panic Beep to Keypad 1 = A Radio panic will Beep at Keypad # 1 (Default = All On) 2 = A Radio panic will Beep at Keypad # 2 3 = A Radio panic will Beep at Keypad # 3 4 = A Radio panic will Beep at Keypad # 4 5 = A Radio panic will Beep at Keypad # 5...
  • Page 4 +++++Miscellaneous Panel & Clock Settings+++++ Installer Code P25E Installer Code - ( Default = 000000) Duress Digit P25E Duress Digit - Value 1-9 (Default = 0 Duress Function Disabled) Dial Report Delay P25E Dial Report Delay - Value 0-255 seconds (Default = 0) Radio Detector Supervised Timer P25E Radio Detector Supervised Timer -...
  • Page 5 P28E Daylight Saving Start Month - Value 1-12 - Default = 9 Daylight Saving End Month - Value 1-12 - Default = 4 P29E Daylight Saving Start Hour - Value 0-23 - Default = 2 Daylight Saving End Hour - Value 0-23 - Default = 3 +++++Outputs+++++ Programming Output Options “A”...
  • Page 6 +++++Areas+++++ Area “A” & “B” Options A P45E 1-2E Area A&B Options A 1 = Arm Button Required Before Code to Set (1=Area “A”) (Default = All Off) 2 = Stay Button Required Before Code to Set Stay Mode (2=Area “B”) 3 = Code required to Set 4 = Code Required to Bypass Zones 5 = Spare...
  • Page 7 Area “A” & “B” Armed Mode Exit Delay Beeps to Keypad Area A&B Armed Exit Delay Beeps to Keypad - P58E 1-2E Value 1-8 (for Keypads 1-8) (1=Area “A”) (Default, Area A = All On, Area B = All Off) (2=Area “B”) Area “A”...
  • Page 8 6 = Receiver Fail Beeps Keypad Buzzer 7 = Turn Off Keypad LED’s when Armed 8 = Turn Off Keypad & Backlight LED’s on Mains Failure Keypad “ARM” Button Area Assignment P74E 1-8E Keypad “ARM” Button Area 1 = “ARM” Button assigned to Area “A” (Default = 1) 2 = “ARM”...
  • Page 9 “Panic” Button or “1&3” Alarm to Outputs P84E 1-8E Keypad “Panic” Button or “1&3” Alarm to Outputs (Default = 1,2) 1 = The Keypad “Panic” Button or “1&3” will turn on Output # 1 2 = The Keypad “Panic” Button or “1&3” will turn on Output # 2 3 = The Keypad “Panic”...
  • Page 10 Manually Operated Fire Alarm Beeps to Keypads P91E 1-8E Fire Alarm Beeps to Keypads (Default = All On) 1 = A Fire Alarm at the selected keypad will Beep KP # 1 2 = A Fire Alarm at the selected keypad will Beep KP # 2 3 = A Fire Alarm at the selected keypad will Beep KP # 3 4 = A Fire Alarm at the selected keypad will Beep KP # 4 5 = A Fire Alarm at the selected keypad will Beep KP # 5...
  • Page 11 +++++Zones+++++ Programming Zones to Areas P121E 1-16E Assigning Zones to Areas A or B 1 = Assigned to Area “A” (Default = 1) 2 = Assigned to Area “B” Programming Zone Options A P122E 1-16E Programming Zone Options A 1 = Zone is Active (Default Zone 1-4 = 1,6,7,8) 2 = Zone is N/O (Off = N/C) (Default Zone 5-8 = 1,7,8)
  • Page 12 Armed Zone Alarms to Outputs P128E 1-16E Armed Zone Alarms to Output (Default = 1,2) 1 = A Zone Alarm will Turn On Output # 1 2 = A Zone Alarm will Turn On Output # 2 3 = A Zone Alarm will Turn On Output # 3 4 = A Zone Alarm will Turn On Output # 4 5 = A Zone Alarm will Turn On Output # 5 6 = A Zone Alarm will Turn On Output # 6...
  • Page 13 24 Hour Zone Alarm Beeps to Keypads P136E 1-16E 24 Hour Zone Alarm Beeps to Keypads (Default = All On) 1 = A 24 Hour Zone Alarm will Beep Keypad #1 2 = A 24 Hour Zone Alarm will Beep Keypad #2 3 = A 24 Hour Zone Alarm will Beep Keypad #3 4 = A 24 Hour Zone Alarm will Beep Keypad #4 5 = A 24 Hour Zone Alarm will Beep Keypad #5...
  • Page 14 Armed Zone Entry Delay Times Armed Zone Entry Delay Times - P144E 1-16E Value 0-9999 seconds (Default Zone # 1 = 20 Seconds, Zones # 2-16 = 0) Stay Mode Entry Delay Times Stay Mode Entry Delay Times - P145E 1-16E Value 0-9999 seconds (Default Zones # 1-4 = 20 Seconds, Zones # 5-16 = 0) Zone Re-trigger Count...
  • Page 15 Sensor-Watch Timer P163E 1-16E Sensor-Watch Timer - 0-9999 Minutes (Default = 7200 minutes [120 Hours]) Enrolling Radio Zone Codes P164E 1-16E Learn Radio Zone Codes Delete a Specific Radio Zone Code P165E 1-16E Delete a Specific Radio Zone Code Find Radio Zone memory Location P166E 0E This will find the zone # of any Radio Zone code stored in the panel Only press 0E when using LED Keypad.
  • Page 16 Dialler Programming Options 2 P175E 2E Dialler options 2 (Default = 1) 1 = Step number on each call 2 = Upload/Download use callback 3 = Upload/Download only if disarmed 4 = Test calls only if armed 5 = Test Time Period is in days 6 = Hold line open following Domestic/Voice report for DTMF control 7 = First to Open Last to Close Reporting 8 = Answer After 1 ring for Two Way Voice Call-back Mode...
  • Page 17 P176E 9E “Duress Alarm” Voice Message Number - Value 0-99 (Default = 0) P176E 10E “Latchkey Disarm” Voice Message Number - Value 0-99 (Default = 0) P176E 11E “Manual Test Initiated” Voice Message Number - Value 0-99 (Default = 0) +++++Telephone Numbers+++++ Programming Telephone Numbers P181E 1-8E...
  • Page 18 Divert Area Events P192E 1-2E Divert Area Events (1=Area A) (Default = All Off) 1 = Dial on away arm (2=Area B) 2 = Dial on away disarm 3 = Dial on stay arm 4 = Dial on stay disarm 5 = Dial if Key-switch activation 6 = Dial if Time zone activation 7 = Dial if DTMF or PC activation...
  • Page 19 Keypad “Fire” Alarm 4+2 Restore Reporting Code P195E 20E Keypad Fire Alarm Restore 4+2 Code - Two digit value from 00-FF Keypad “Medical” Alarm 4+2 Reporting Code P195E 21E Keypad Medical Alarm 4+2 Code - Two digit value from 00-FF Keypad “Medical”...
  • Page 20 Contact ID Reporting Code Summary In addition to the programmable Contact ID Event Code assignments defined at P157E, P158E, P159E, P175E (10E-12E) there are a number of fixed event codes. The programmable and fixed event codes are all listed in the table below. Associated with the fixed and programmable event codes, there are a number of extension codes, that are also listed below.
  • Page 21 SIA Reporting Code Summary Most of the SIA Event Codes are fixed within the panel but some locations such as zones at P196E (1-16E) and Panic/Fire/ Medical at P197E (1-3E) can have a user defined report code from the table below. To follow are the default SIA reporting codes. Event Type SIA Alarm Code SIA Restore Code...
  • Page 22 Software change Update Notice Software Update V9.03 August 2006 The following new features have been added in V9.03 1– Code required to View memory P4E option 8 and P25E option 1 2– Radio pendant only works during entry delay for disarm P8E option 4 3–...
  • Page 23 Software Update V9.08.12B Feb 2011 1 - ELITE S & ELITE S-LITE panels with the “B” at the end of the software version number V9.08.12 have had a default change. These new defaults were released in February 2011. The miscellaneous Domestic/Voice reporting options at P176E 1E - 11E were all defaulted to “1”...
