- Page 1 D-Line MANUAL M A N U A L...
-
Page 2: Safety Regulations / Warranty
In no event will KS Digital be liable for more than the amount of the purchase price, not to exceed the current retail price of the product. KS Digital disclaims any other war- ranties, express or implied. -
Page 3: Table Of Contents
Table of Contents Safety regulations / Warranty........2 Table of Contents............3 D-Line conception and performance......4 Controls.................6 ......8 Signal path diagram............12 Recommended Speaker Set Up........13... -
Page 4: D-Line Conception And Performance
D-Line conception and performance Thank you very much for choosing a KSdigital monitor For nearly 20 years, KSdigital has been designing world-class studio monitors, with the goal of repro- ducing only the transparent, undistorted, true impulse of the music signal. KSdigital products can be found in the control rooms of top producers, broadcast studios, and mixing / mastering facilities world- wide. - Page 5 D-Line conception and performance The Chassis The principle design—the coaxial chassis—creates the ideal point source. It allows all frequencies to radiate from one location, without internal phase shifts and regardless of where you are located within the defined dispersion angle. The carbon fiber cone of the 8” mid / woofer in the D80 and D808 contributes to this maxim.
-
Page 6: Controls
Controls Controls on the back: Remote Control: Remote Control RJ45 socket to connect KSdigital‘s proprietary remote control RC-100 or FIR W-Lan remote control software (an exclusive KS 2-to-1 connection cable is used to connect two speakers to one remote control). Analog In: Analog signal input, XLR balanced with + 4dBv input sensitivity. - Page 7 Controls Controls on the front: High – adjust to compensate for shortcomings in the high frequency (treble) range of your room acoustics. This controller provides a range of +/- 6dB and is designed as a shelving fi lter (see the graphic on the back of the speaker for reference).
- Page 8 D606 Three-way Coaxial Studio Monitor is the #1 tool for covering ranges from midfi eld to main nearfi eld monitor. From the deepest, most accurate bass to brilliant, transparent treble, it also features the most accurate panoramic imaging available today. This is studio monitoring at the highest resolution! The most compact of the new D-Line, featuring fully digital linear phase FIRTEC™...
- Page 9 Technical Specifications: ZEITFILTER TECHNOLOGIE TECHNICAL SPECIFICATIONS:...
- Page 10 D808 Three-way Coaxial Reference Studio Monitor is the premier monitor in the D Line, which operates as the ultimate nearfi eld or midfi eld studio monitor, commanding an impressive presence even at extended listening distances. In every application, the -Coax performs with pinpoint precision, even at high volumes due to its immense membrane surface.
- Page 11 Technical Specifications: TECHNICAL ZEITFILTER TECHNOLOGIE SPECIFICATIONS:...
-
Page 12: Signal Path Diagram
Signal Flow Diagram lnput Stage +4dB stepless adjustable 28 Hz - LowCut Processing Filters for room equalisalion: RC-100 Shelv. adjustable 3 PEQ, High-Lowshelvig, DELAY,GAIN FIRTEC phase and frequency linear compensation Digitale Differenz-Crossover 1000Hz 18KHz-EQ Protection Protection 280W Amp 280W Amp 1“... -
Page 13: Recommended Speaker Set Up
Recommended Speaker Set Up THE OPTIMUM SPEAKER PLACEMENT - GUIDELINES FOR OPTIMAL INSTALLATION To ensure proper stereo imaging, for the speaker placement you should consider the following points: 1. Construction of an isosceles triangle between the speakers and listener, the “stereo triangle.” 2. - Page 14 Speaker set up 3. The greatest possible proportion of the sound energy to the ear should be formed by the direct sound. Do not choose a listening distance that is too large, and always choose one relative to the size of the speaker.
- Page 15 Speaker set up room will have the most problems with standing waves). With a separate subwoofer, it can be asymmetri- cally placed to help with this issue, but with a sub built into the speaker, bass trapping may be necessary, as well as offsetting the speakers as explained in this section.
- Page 16 D-LINE MANUAL KSdigital GmbH Altenkesselerstr. 17/D1, D-66115 Saarbrücken,...
