System Settings - YSI ProDSS Manual

cover and attempt to charge the unit
again. If the unit still will not turn
on, the battery pack may need to be
replaced. (Before ordering a new
battery pack, call YSI at
800.765.4974 and troubleshoot
problems with a ProDSS tech.)
e) If a new battery pack has been
ordered, refer to the YSI manual for
battery removal/disposal and
replacement.

System settings

Date/Time
If the date and time are inaccurate, press the
system button
, go to the Date/Time
submenu option, scroll down to Date and hit
Enter. In the numeric entry screen, use the
arrow keys to maneuver around. If entire date
needs to be corrected, click the
entry key
. If not, use the
to partially correct the date. After
correcting the date, hit Enter. Scroll down to
Time and hit Enter, then follow similar
instructions as for date correction to correct the
time. When finished, hit the Esc. or left arrow
button until you are back to the Run screen.
Logging Data
If the logging settings are inaccurate, press the
system button , scroll down to the logging
submenu option, go to the Continuous Mode,
and uncheck the box by pressing Enter. The
box should become unchecked
Esc button to return the Run Screen. In the
green bar at the top of the screen it should now
read "Log One Sample".
Sensor Display Details
If there is a parameter not displayed on the
Run Screen, either the sensor is not installed
correctly, or it is not working properly. To
check if the sensor is installed properly, refer to
the above section on Sensor, Port Plug,
Guard Installation and carefully examine the
sensors.
Field Procedures
If the units do not match on the Run Screen, go
to the
Display submenu and hit Enter. Scroll down
and select the desired parameter. A submenu
will appear with multiple parameter unit
options; select the proper unit (see protocol
above) and return to the Run Screen.
Cleaning the bulkhead & probes
The bulkhead, probe guard, and calibration cup
can all be cleaned with a mild detergent. A
bottle brush works well for cleaning the
calibration cup; remove the locking ring and
gasket and scrub the inside of the chamber
well. Remove the bottom of the cup to clean it
as well, particularly the threads which can get
full of grit. Use a bottle brush to clean the
probe guard, removing it from the bulkhead
and unscrewing the bottom of the guard to
delete entire
clean it. Clean any dirt off of the bulkhead and
backspace key
sides of the probes using a toothbrush. Don't
scrub the faces of the probes with a brush, as
this could cause damage. Be sure to rinse
everything well with tap water after you've
cleaned it.
. Press the
8
probe button
and scroll down to
YSI ProDSS
th
18 Edition, 2016
