Emerson COMX-CAR-610 COM Express Installation And Use Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Table of Contents
COMX-CAR-610 COM Express Carrier Board
Installation and Use
P/N: 6806800K26D
August 2011
Embedded Computing for
Business-Critical Continuity
TM

Advertisement

Table of Contents
loading

  Related Manuals for Emerson COMX-CAR-610 COM Express

No related manuals

  Summary of Contents for Emerson COMX-CAR-610 COM Express

  • Page 1 Embedded Computing for Business-Critical Continuity COMX-CAR-610 COM Express Carrier Board Installation and Use P/N: 6806800K26D August 2011...
  • Page 2 Emerson reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Emerson to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    3.4.6 Storage ..............41 COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 4 4.10 Watchdog Timer ..............56 COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 5 Related Documentation ............. . . 59 Emerson Network Power—Embedded Computing Documents ......59 Manufacturers’...
  • Page 6 Contents Contents Contents COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 7 P28, Trusted Platform Module (TPM) Header Pin Definition ..... . . 45 COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 8 Wake Events ..............57 Table A-1 Emerson Network Power, Embedded Computing Publications ....59 COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 9 Location of Product Serial Number ........20 Figure 3-1 COMX-CAR-610 COM Express Carrier Board Component Layout ....27 Figure 4-1 COM Express Type 6 Block Diagram .
  • Page 10 List of Figures COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 11: About This Manual

    Boot Device Selection Double Data Rate Driver Execution Environment EEPROM Electrically Erasable Programable Read-Only Memory eUSB Embedded Universal Serial Bus Gigabit Ethernet GPIO General Purpose Input Output HDMI High-Definition Multimedia Interface COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 12 Small Computer System Interface Serial Presence Detect Serial Peripheral Interface SODIMM Small Outline Dual In-line Memory Module Super I/O Super Input/Output Trusted Platform Module Universal Serial Bus Video Graphics Adapter Watchdog Timer COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 13 Repeated item for example node 1, node 2, ..., node Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) Logical OR COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 14 SPI Flash SF100 header" on page Table "P15 and P38, Jumper Configuration to Enable/Disable BIOS" on page Added Table "P17 Case Open Select Header" on page 48 Table "P40 PS_ON Select Jumper" on page COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 15: Introduction

    Introduction Features The COMX-CAR-610 COM Express Carrier Board is a Type 6 carrier board. This board is designed to support the COM Express Type 6 Specification and is compatible with COM Express Type 1 Specification. This board supports the following COM Express form factors: compact, basic, and extended.
  • Page 16 Wake-Up Events Power Button: S0, S3, S4, S5  KB: S0, S3  Mouse: S0, S3  PME: S0, S3, S4, S5  USB: S0, S3  Wake on LAN support  COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 17: Standard Compliances

    Introduction Standard Compliances Figure 1-1 Standard Compliances COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 18: Mechanical Data

    Introduction Mechanical Data Figure 1-2 COMX-CORE Series Mechanical Dimensions (Top View) COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 19: Ordering Information

    Introduction Figure 1-3 COMX-CORE Series Mechanical Dimensions (SideView) Ordering Information Table 1-2 Ordering Information Orderable Number Description COMX-CAR-610 Type 6 COM express carrier board UATX COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 20: Product Identification

    Introduction Product Identification The following figure shows the location of the board’s serial number. Figure 1-4 Location of Product Serial Number COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 21: Hardware Preparation And Installation

    0 to +55°C -40 to +85°C Shock 20 g 11 ms sine or saw Vibration 0.01g ^2/Hz at 5-500 Hz Random Vibration Air Flow 400 LFM at 0 to 55°C Humidity 10-90% (non-condensing) COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 22: Power Requirements

    ATX power 10 A VCC3 ATX power VCC1_5 VCC3 1.5 V 0.5 A 5VSB ATX power 5VDual VCC1_5 and 5VSB 10 A 3VDual VCC3 and 5VSB VCC1_8 VCC3 1.8 V 0.5 A COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 23: Unpacking And Inspecting The Board

    — Cable, LPT, 2X13PIN housing to DB25 PIN connector, with I/O panel, 300MM length — Cable, PS/2, MINI DIN6P to PS/2 connector, 300MM length — COMX-CAR-610 Carrier Board I/O Shield COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 24: Installation And Removal Of The Com Express Module

    3. Turn over the COM Express module and the COMX-CAR-610. 4. From the backside of the COMX-CAR-610, locate the screw holes. 5. Use the screws to fasten the COM Express module assembly to the COMX-CAR- 610. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 25 2. On the back of the COMX-CAR-610, locate the seven screws that connect the COM Express module to the COMX-CAR-610. 3. Loosen and remove the screws. 4. While holding the edges, pull the COM Express module from the COMX-CAR-610. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 26: Replacing The Onboard Battery

    When exchanging the on-board lithium battery, make sure that the new and the old  battery are exactly the same battery models. If the respective battery model is not available, contact your local Emerson sales  representative for the availability of alternative officially approved battery models.

  • Page 27: Controls, Leds, And Connectors

    Chapter 3 Controls, LEDs, and Connectors Carrier Board Layout Figure 3-1 COMX-CAR-610 COM Express Carrier Board Component Layout COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 28: Com Express Board-To-Board Connector

    SATA1_TX+ DDI1_PAIR6- DDI1_AUX- SATA0_TX- SATA1_TX- RSVD RSVD SUS_S4# SUS_STAT# RSVD RSVD SATA0_RX+ SATA1_RX+ PCIE_RX6+ PCIE_TX6+ SATA0_RX- SATA1_RX- PCIE_RX6- PCIE_TX6- GND(FIXED) GND(FIXED) GND(FIXED) GND(FIXED) SATA2_TX+ SATA3_TX+ PCIE_RX7+ PCIE_TX7+ SATA2_TX- SATA3_TX- PCIE_RX7- PCIE_TX7- COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 29 USB3+ DDI3_PAIR0- DDI2_PAIR1- USB_2_3_OC# USB_0_1_OC# DDI3_HPD DDI2_HPD USB0- USB1- RSVD RSVD USB0+ USB1+ DDI3_PAIR2+ DDI2_PAIR2+ VCC_RTC EXCD1_PERST# DDI3_PAIR2- DDI2_PAIR2- EXCD0_PERST# EXCD1_CPPE# RSVD RSVD EXCD0_CPPE# SYS_RESET# DDI3_PAIR3+ DDI2_PAIR3+ LPC_SERIRQ CB_RESET# DDI3_PAIR3- DDI2_PAIR3- COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 30 PEG_TX5- GND(FIXED) GND(FIXED) GND(FIXED) GND(FIXED) LVDS_A0+ LVDS_B0+ PEG_RX6+ PEG_TX6+ LVDS_A0- LVDS_B0- PEG_RX6- PEG_TX6- LVDS_A1+ LVDS_B1+ DDI1_CTRLDATA DDI1_CTRLCLK LVDS_A1- LVDS_B1- PEG_RX7+ PEG_TX7+ LVDS_A2+ LVDS_B2+ PEG_RX7- PEG_TX7- LVDS_A2- LVDS_B2- LVDS_VDD_EN LVDS_B3+ RSVD IDE_CBLID# COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 31 VGA_I2C_DAT VCC_12V RSVD RSVD PEG_ENABLE# VCC_12V RSVD PEG_RX14+ PEG_TX14+ VCC_12V RSVD PEG_RX14- PEG_TX14- GND(FIXED) GND(FIXED) GND(FIXED) GND(FIXED) VCC_12V VCC_12V PEG_RX15+ PEG_TX15+ VCC_12V VCC_12V PEG_RX15- PEG_TX15- VCC_12V VCC_12V VCC_12V VCC_12V VCC_12V VCC_12V COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 32: Leds

    Thermal Trip ON: CPU is hot; system needs to be shut down Suspend Status ON: Suspend Status Mini-CD SW OK ON: USB and PCI-E have both switched to mini PCI-E slot COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 33: Connectors

    Table 3-4 P6, LVDS Connector Pin Definition Signal Signal LVDSA_DATA0_P LVDSB_DATA0_P LVDSA_DATA0_N LVDSB_DATA0_N LVDSA_DATA1_P LVDSB_DATA1_P LVDSA_DATA1_N LVDSB_DATA1_N LVDSA_DATA2_P LVDSB_DATA2_P LVDSA_DATA2_N LVDSB_DATA2_N LVDSA_DATA3_P LVDSB_DATA3_P LVDSA_DATA3_N LVDSB_DATA3_N LVDSA_CLK_P LVDSB_CLK_P LVDSA_CLK_N LVDSB_CLK_N LVDS_I2C_CLK LVDS_I2C_DATA COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 34: Vga

    The 12 V DC LVDS power supply is configured through the 3-pin header P35 Table 3-6 P35, LVDS Power Supply Jumper Configuration Jumper Setting Configuration P35 (1-2) P35 (2-3) NC (Default) 3.4.1.2 Table 3-7 J5, VGA Connector Pin Definition Signal Signal CRT_R CRT_G CRT_B COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 35: Hdmi

    Table 3-8 J5, HDMI Connector Pin Definition Signal Signal OUT_D2+ OUT_D2- OUT_D1+ OUT_D1- OUT_D0+ OUT_D0- TLC- SCL_IN SDA_IN HPD_IN 3.4.1.4 Display Port Table 3-9 J3 and J4, Display Port Connector Pin Definition Signal DP_0_P DP_0_N COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 36: Audio

    DP_AUX_N DP_HPD VCC_3 2,5,8,11,14,16,19 3.4.2 Audio Table 3-10 J16, Audio Jack Connector Pin Definition Signal Signal LIN_L LIN_JD AGND LIN_R LOUT_L LOUT_JD AGND LOUT_R AGND MIC1L MIC1_JD AGND MIC1R MH1~MH4 AGND COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 37: Lan

    Signal 1.8V LAN1_MID3_N LAN2_MID0_P LAN1_MID2_P LAN2_MID1_N GBE0_CTREF 1.8V LAN1_MID1_N LAN2_MID2_P LAN1_MID0_P LAN2_MID3_N GBE0_CTREF LAN1_MID3_P LAN2_MID0_N GBE0_CTREF 1.8V LAN1_MID2_N LAN2_MID1_P LAN1_MID1_P LAN2_MID2_N GBE0_CTREF 1.8V LAN1_MID0_N LAN2_MID3_P LAN1_LED_LINK_N LAN2_LED_LINK_N LAN1_LED_LINK_P LAN2_LED_LINK_P LAN1_LED_ACT_N LAN2_LED_ACT_N COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 38: Pci Express

    Jumper Setting Configuration P24 (1-2) x4 PCI-E slot P24 (2-3) PCI-E Mini Card (Default) Table 3-15 P25 Jumper Setting Jumper Setting Configuration P25 (1-2) x4 PCI-E slot P25 (2-3) LAN (Default) COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 39: Usb

    5VDUAL USB _N USB_P P39, another USB 2.0 header could be used for PCI Express Mini Card applications. Table 3-18 P39, USB 2.0 Header Pin Definition Signal Signal 5VDUAL USB _N COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 40: Usb 3.0

    Table 3-20 J14 and J15, USB 3.0 Connector Pin Definition Signal Signal USB_P0 _N USB_P0 _P USB0_SSRX _N USB0_SSRX _P USB0_SSTX _N USB0_SSTX _P USB_P1 _N USB_P1 _P USB1_SSRX_N USB1_SSRX _P USB1_SSTX _N USB1_SSTX _P COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 41: Storage

    Controls, LEDs, and Connectors 3.4.6 Storage Table 3-21 P10—P13, SATA Socket Pin Definition Signal SATA_TX_P SATA_TX_N SATA_RX_N SATA_RX_P 3.4.7 Super I/O 3.4.7.1 Table 3-22 P3 and P27, Fan Header Pin Definition Signal TACH COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 42: Lpt Port

    Table 3-23 P26, PS/2 (Keyboard and Mouse) Connectors Pin Definition Signal KB_DATA KB_CLK MS_DATA MS_CLK 3.4.7.3 LPT Port Table 3-24 P32, LPT Header Pin Definition Signal Signal STB_N ACK_N BUSY_N PE_N SLCT_N AFD_N ERR_N INIT_N SLIN_N 18—25 COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 43: Serial Ports

    You need to set jumpers P34 and P41 to configure the serial ports defined above as RS-232 or RS-422/485 ports. Table 3-27 Set Jumpers P34 and P41 Jumper Setting Configuration P34/P41 (1-2) RS232 (Default) P34/P41 (3-4) RS422 P34/P41 (5-6) RS485 COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 44: Power

    S3 and Type VI 3.4.8 Power Table 3-29 ATX Power Supply Connector Pin Definition Signal +12V +12V Headers 3.5.1 Table 3-30 P29, Low Pin Count (LPC) Header Pin Definition Signal CLK_33M RST_N FRAME_N 3.3V COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 45: Trusted Platform Module (Tpm)

    Table 3-31 P28, Trusted Platform Module (TPM) Header Pin Definition Signal Signal CLK_33M FRAME_N RST_N 3.3V SMB_CLK SMB_DATA 3VDUAL INT_SERIRQ CLKRUN_N 3.3V DRQ0_N 3.5.3 GPIO Table 3-32 P30, GPIO Header Pin Definition Signal GPO0 COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 46: Miscellaneous I/O

    Table 3-32 P30, GPIO Header Pin Definition (continued) Signal GPI0 GPO1 GPI1 GPO2 GPI2 GPO3 GPI3 3.3V 3.5.4 Miscellaneous I/O Table 3-33 P16, Miscellaneous I/O Header Pin Definition Signal Signal HD_LED POWER_LED HD_LED# POWER_LED# EXT_PWRBTN_N PM_SYSRST_N COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 47: Spi Flash

    Use Jumper P15 to enable or disable the BIOS on the COM Express module Table 3-36 P15 and P38, Jumper Configuration to Enable/Disable BIOS P15 Jumper Setting Configuration P15 (1-2) Enable BIOS on the module (Default) COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 48: Eeprom

    P17 Setting Configuration P17 (1-2) Disable the case open select header (Default) P17 (2-3) Enable the case open select header 3.5.6 EEPROM Table 3-38 P31, EEPROM Header Pin Definition Signal I2C_CLK I2C_DATA COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 49: Functional Description

    Functional Description Block Diagram Figure 4-1 COM Express Type 6 Block Diagram Video The COMX-CAR-610 supports dual-independent displays using the Mobile Intel processor Integrated Graphics Controller. This carrier supports following graphic interfaces: COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 50: Lvds

    High-Definition Multimedia Interface (HDMI). The integrated HDMI requires a 1.5 V CODEC. For information on pin assignments, see Table 3-10 on page 36 Table 3-11 on page COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 51: Lan

    PCI Express Graphics (PEG). There are also two x4 PCI-E slots. One of the x4 slots can be used for other applications by using PCI-E multiplexer devices. For information on pin assignments, see Table 3-13 on page Figure 4-2 PCI Express Block Diagram COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 52: Pci Express Mini Card

    USB 3.0 Enhanced Host Controller Interface (EHCI). For information on pin assignments, see Table 3-20 on page Storage There are four SATA sockets on the carrier board for connecting to internal SATA 2.0 devices. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 53: Super I/O

    COM Express module and its environment. Voltage and thermal values are read by the management engine, and alerts are reported to the management engine. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 54: Fan Control

    Two of the six COM ports from the Super I/O can be configured as RS-232 ports, or as RS-422 or RS-485 ports by setting a 6-pin, dual-row jumper. For information on pin assignments, see Table 3-25 on page 43 Table 3-26 on page COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 55: Spi Flash

    The COMX-CAR-610 also provides two 3-pin jumpers (P15 and P38) to determine whether enable or disable the BIOS on the module. For information on pin assignments, see Table 3-36 on page COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 56: 4.10 Watchdog Timer

    The RTC supports two lockable memory ranges. By setting bits in the configuration space, two 8-byte ranges can be locked to read and write accesses. This prevents unauthorized reading of passwords or other system security information. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 57: 4.12 Wake Events

    The management engine supports Wake-on-LAN (WOL) using wired LAN. Power button If the power button is pressed for more than four seconds, it causes an unconditional transition to the S5 state. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 58 Functional Description COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 59: Related Documentation

    The publications listed below are referenced in this manual. You can obtain electronic copies of Emerson Network Power, Embedded Computing publications by contacting your local Emerson sales office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 60 Related Documentation COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 61: Safety Notes

    Emerson and our suppliers take significant steps to make sure that there are no bent pins on the backplane or connector damage to the boards prior to leaving the factory. Bent pins caused by improper installation or by inserting boards with damaged connectors could void the Emerson warranty for the backplane or boards.
  • Page 62 Use only shielded cables when connecting peripherals to assure that appropriate radio frequency emissions compliance is maintained. Installed blades must have the face plates installed and all vacant slots in the shelf must be covered. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 63 Before touching the product make sure that your are working in an ESD-safe environment or wear an ESD wrist strap or ESD shoes. Hold the product by its edges and do not touch any components or circuits. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 64 When exchanging the on-board lithium battery, make sure that the new and the old battery are exactly the same battery models. If the respective battery model is not available, contact your local Emerson sales representative for the availability of alternative officially approved battery models.

  • Page 65: Sicherheitshinweise

    Anwendungen, lebenserhaltenden Geräten oder in Flugzeugen verwendet werden. Einbau, Wartung und Betrieb dürfen nur von durch Emerson ausgebildetem oder im Bereich Elektronik oder Elektrotechnik qualifiziertem Personal durchgeführt werden. Die in diesem Handbuch enthaltenen Informationen dienen ausschließlich dazu, das Wissen von Fachpersonal zu ergänzen, können dieses jedoch nicht ersetzen.
  • Page 66 Sie sicher, dass ausreichend Schutz vor Störstrahlung vorhanden ist. Die Blades müssen mit der Frontblende installiert und alle freien Steckplätze müssen mit Blindblenden abgedeckt sein. Änderungen, die nicht ausdrücklich von Emerson erlaubt sind, können Ihr Recht das System zu betreiben zunichte machen. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 67 Elektrostatische Entladung und unsachgemäßer Ein- und Ausbau des Produktes kann Schaltkreise beschädigen oder ihre Lebensdauer verkürzen. Bevor Sie das Produkt oder elektronische Komponenten berühren, vergewissern Sie sich, daß Sie in einem ESD-geschützten Bereich arbeiten. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 68 Wenn SIe die Lithium-Batterie auf dem Produkt austauschen, stellen Sie sicher, dass die alte und die neue Batterie vom gleichen Typ sind. Ist der Batterietyp nicht verfügbar, wenden Sie sich an Emerson um herauszufinden, welcher Batterietyp offiziell alternativ verwendet werden darf.
  • Page 69 Sicherheitshinweise Umweltschutz Umweltverschmutzung Falsche Entsorgung der Produkte schadet der Umwelt. Entsorgen Sie alte Produkte gemäß der in Ihrem Land gültigen Gesetzgebung und den Empfehlungen des Herstellers. COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 70 Sicherheitshinweise COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)

  • Page 71: Index

    Installation Module installing COM Express module installing COM Express module power requirements removing COM Express module onboard battery removing COM Express module removing onboard battery requirements environmental power shipment contents COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
  • Page 72 Index COMX-CAR-610 COM Express Carrier Board Installation and Use (6806800K26D)
