Banana Bike LT Series Quick Manual

Thank you for choosing Banana Bike. A Banana Bike is a fantastic first bike and a great way for your
child to learn the basics of biking, learning to balance and steer whilst having massive fun!
For full instructions, please visit:
G
K
H
J
Attach the Forks & Handlebars to the Frame
A B
C
2
B
E
C
A
6
www.banana-bike.com
http://www.banana-bike.com/instructions
F
A
B
D
C
I
1. Lay the forks and frame on the floor
D
2. Slide the flat plastic washer (C) over
the fork shaft (E)
3. Slide the bearings (A & B) into the
D
frame head tube
4. Slide the forks through the bearings
and frame head tube
3
5. Slide the domed bearing (D) over the
forks to rest on the top of the
bearing (B)
6. Slide the aluminium hex clamp(G)
over the fork shaft
7. Slide the handlebars (F) into the fork
shaft
8. Applying a small amount of
downwards pressure to the hex
clamp (G), tighten the hex clamp (G),
using the hex tool (J) until it starts to
G
grip the forks and handlebars
9. Then ensure the forks and
handlebars are parallel
10. Fully tighten the aluminium hex
clamp (Important!)
11. The handlebars and forks should now
be fully joined and have a smooth
turning action
A & B – Bearings (Pair)
C – Flat Plastic Washer
D – Domed Plastic Washer
E – Forks
F – Handlebars
E
G – Aluminium Hex Clamp
H – Seat & Seat Post Unit
I – Spanner
J – Hex Key
K – Aluminium Hex Clamp
L – Frame
M - Wheels
L
5
D
B
A
C
4
F
7
8
G
E
M
1
