HS Long-Range Handheld Transmitter Master Development System
Quick Start Reference
Remove Contents
1
Remove the decoder board, transmitters, antenna and
battery.
2
Install the antenna and battery onto the
decoder board.
Press Buttons on the Transmitter to Enable Decoder Board
4
Set Up the Decoder Board
Decoder Board
Turn On Power
3
Turn on the power to the
board.
LEDs
Revised 7/31/2015
